Quick Details
-
Voltage:
-
Based on the Model
-
Power:
-
Based on the Model
-
Dimension(L*W*H):
-
As your requiement
-
Weight:
-
About 1200 kg
-
Warranty:
-
12 months
-
Certification:
-
API
-
Size:
-
We can design as your need.
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JINTAN
-
Model Number:
-
ZJ30/ZJ40/ZJ50/ZJ70
-
Voltage:
-
Based on the Model
-
Power:
-
Based on the Model
-
Dimension(L*W*H):
-
As your requiement
-
Weight:
-
About 1200 kg
-
Warranty:
-
12 months
-
Certification:
-
API
-
Size:
-
We can design as your need.
API Stadard Rig Tower/Drill Tower
1.Products Description:
The mast type is generally classified as A type, K type, tower type and mast type etc.
- A type mast, its leg section is rectangular or triangle shape, with better loading capacity and stability,connected with pins between sections, installed at low level and erected or lowered down integrally by drawworks and A-frame.
- K type mast, namely front opening mast, its transverse section is a shape truss structure, its both sides are composed of several pieces or segments, its back is rigid frame or pole system of truss, connected with pins or bolts between segments and members, may be installed at low level and erected or lowered down integrally by drawworks or hydraulic cylinder, has the advantages of convenient installation and teardown, excellent rigidity.
2.We Can Produce The Belows:
3.The Details:
|
Technical specifications and parameters |
|||||||||
|
Model |
135 /31.5 |
225 /43 |
315 /43-II |
315 /43 |
450 /45 |
450 /45S |
450 /45K |
585 /45 |
|
|
Maximum static load
|
1350 |
2250 |
3150 |
3150 |
4500 |
4500 |
4500 |
5850 |
|
|
Working height(m) |
31.5 |
43 |
43 |
45 |
45 |
45 |
45 |
45 |
|
|
Top span distance(m) |
1.7 |
1.8 |
1.8 |
1.8 |
2.1 |
Facad: 2.1
|
2.1 |
2.4 |
|
|
Bottom span distance(m) |
6 |
7.5 |
8 |
9 |
9 |
9 |
9 |
9 |
|
|
Working height of racking platform |
17.5
|
26.5
|
26.5
|
26.5
|
26.5
|
26.5
|
26.5
|
26.5
|
|
|
Setback capacity |
2500 |
4000 |
5000 |
6050 |
6500 |
7280 |
7280 |
9200 |
|
|
Height of A-frame(m) |
5 |
7.565 |
7.2 |
7.5 |
7.9 |
9.4 |
9.4 |
8.0 |
|
|
Anti-wind capacity |
Non-working state (no setback & hooking load)
|
172 |
180 |
180 |
180 |
170 |
172 |
172 |
172 |
|
Non-working state
|
130 |
130 |
130 |
130 |
130 |
130 |
130 |
130 |
|
|
Lift and release mast KM/h |
30 |
30 |
20 |
20 |
30 |
30 |
30 |
30 |
|
|
Weight(Kg) |
25640 |
36963 |
37420 |
47193 |
51540 |
72967 |
93440 |
120150 |
|
4.Our Service:
Before sale: Reasonable solution based on the cu stomer requirement.
Order service: Fax contract and transfer contract is avai lable.
After sale: 1 year quality warranty and training of installing and debugging for free.
Fund service: Inner customer.48 hours arrive below 1000 km .72 hours arrive over 1000km.
Foreign customer: We will arrived the destination as soon as possible .
Parts service: Every product parts has the stock to supply customer as soon as possible.
