Quick Details
-
Brand Name:
-
Yuanda Boiler
-
Dimension(L*W*H):
-
Depends on boiler capacity
-
Weight:
-
Depends on boiler capacity
-
Rated heat power 1:
-
1400kW, 1.4MW
-
Rated working pressure:
-
0bar, 7bar, 10bar
-
Rated out/return water temperature:
-
85/60 degree, 95/70 degree
-
Boiler efficiency:
-
above 80%
-
Factory history:
-
since 1956
-
Control system:
-
Digital automatic
-
Voltage:
-
50/60HZ available
-
Product name:
-
1.4mw 1.4 mw 1400kw pellets burning furnace stoves heater
Quick Details
-
Core Components:
-
boiler body
-
Steam Production:
-
0.35-14MW
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Yuanda Boiler
-
Dimension(L*W*H):
-
Depends on boiler capacity
-
Weight:
-
Depends on boiler capacity
-
Rated heat power 1:
-
1400kW, 1.4MW
-
Rated working pressure:
-
0bar, 7bar, 10bar
-
Rated out/return water temperature:
-
85/60 degree, 95/70 degree
-
Boiler efficiency:
-
above 80%
-
Factory history:
-
since 1956
-
Control system:
-
Digital automatic
-
Voltage:
-
50/60HZ available
-
Product name:
-
1.4mw 1.4 mw 1400kw pellets burning furnace stoves heater
1.4mw 1.4 mw 1400kw coal biomass fired hot water heating boiler
General introduction:
1. Product description/name:hot water boiler
2. Rated capacity: thermal power 0.7mw 1.4mw 2.8mw 4.2mw 5.6mw 7mw 10.5mw 14mw 21mw 29mw etc.
3. Rated working pressure: 0.7 Mpa, 1.0Mpa
4. Rated hot water temperature :85℃,95°C or 115 °C
5. Fuel: coal ,biomass
6. Model: DZL
7. Boiler Applicable Industry/Function: greenhouse, house/apartment, hotel, school, large and medium-sized enterprise and company, factory, apartment and so on use it for heating,bathing and shower.
|
Parameters
|
Unit | DZL0.7 | DZL1.4 | DZL2.8 | DZL4.2 | DZL5.6 | DZL7 | DZL10.5 | DZL14 |
| Rated thermal power | MW | 0.7 | 1.4 | 2.8 | 4.2 | 5.6 | 7 | 10.5 | 14 |
| Rated working pressure | Mpa | 0.7 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 |
| Rated output water temperature | ℃ | 95/115 | |||||||
|
Rated return water temperature |
℃ | 70 | |||||||
|
Thermal efficiency |
% | >82 | |||||||
|
Fuel Type |
coal/biomass | ||||||||
| Fuel consumption | Kg/h | 151 | 302 | 596 | 880 | 1160 | 1380 | 2030 | 2700 |
| Exhaust gas temperature | ℃ | <130 | |||||||
| Max transportation size | mm |
5230×2000 ×2841 |
5950×2400 ×3186 |
7070×2700 ×3470 |
7300×3200 ×3600 |
7350×3350 ×3600 |
7600×3350 ×3600 |
8350×3380 ×3650 |
8900×3380 ×3670 |
| Max transportation weight | t | 13.1 | 24.2 | 28.5 | 36.1 | 39.7 | 25.2 | 17.6 | 19.8 |
| Note: 1. Special schemes can be provided according to local environmental requirements; 2. When fuel calorific value and chemical composition change, some parameters in the table will change accordingly; 3. Due to continuous innovation and improvement of technology, technical parameters are subject to change without notice. | |||||||||
