Quick Details
-
Product name:
-
Silicon Carbide Ceramic Membrane
-
Material:
-
Silicon Carbon
-
Diaphragm Shape:
-
Flat Membrane
-
Filtration Type:
-
Outside Suction Inner Suction filter method
-
Structures:
-
Asymmetric
-
Hardness:
-
HIGH HARDNESS
-
Heat Resistance:
-
800℃
-
Running Pressure:
-
1-2bar
-
Pure water through performance:
-
40 m3/(m2-d) (100 kPa, 25℃)
-
Maximum Allowable Positive Pressure:
-
100bar
Quick Details
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
Wanan
-
Model Number:
-
SICCM-04-2ff1
-
Product name:
-
Silicon Carbide Ceramic Membrane
-
Material:
-
Silicon Carbon
-
Diaphragm Shape:
-
Flat Membrane
-
Filtration Type:
-
Outside Suction Inner Suction filter method
-
Structures:
-
Asymmetric
-
Hardness:
-
HIGH HARDNESS
-
Heat Resistance:
-
800℃
-
Running Pressure:
-
1-2bar
-
Pure water through performance:
-
40 m3/(m2-d) (100 kPa, 25℃)
-
Maximum Allowable Positive Pressure:
-
100bar
High Quality ceramic ultrafiltration membrane
1. Application Field:
Industrial wastewater, domestic sewage, reverse osmosis system (RO) pretreatment, solid-liquid separation, material clarification of the filter Wide Application Field
Uses: MBR, suspended solids / bacteria removal, water recycling reuse
2. Advantages of Ceramic plate membrane module
2.1 Strengthened Membrane
A variety of solvent, oil and chemical substances in industrial wastewater treatment.
Removal of solid suspended solids (SS).
Simplify Pretreatment of membrane filtration.
2.2 High reliability
No membrane damage.
Deterioration caused by medicine effect or heat is less, and longer life than organic film.
Save Space
High flow and stable filtration, smaller setting area compare to organic flat film.
2.3 Energy Saving
The rising water flow formed by the membrane cleaning gas can effectively remove the dirt adhering to the film surface.
In the MBR system, the amount of membrane cleaning gas can be reduced according to the shape of the flat film and the unique dispersion system, realizing energy savings.
2.4 Easy to maintain
Routine maintenance can be exempt through backwashing and the use of online liquid cleaning automation.The dirt attached to surface of the membrane can be easily removed by high pressure water.
2.5 Environmental friendly
The Ceramic plate membrane can be recycled for other ceramic products, thereby reducing waste.
3. Comparison
Compare with organic film
|
Shape |
Plate |
Hollow Fiber Film |
|
|
Material |
Ceramic |
(PVDF,PE) |
(PVDF) |
|
Shelf Life |
+++ |
++ |
+ |
|
Filtration Performance |
++ |
++ |
++ |
|
Energy-saving |
++ |
+ |
+ |
|
Maintenance |
+++ |
++ |
+ |
|
Recycling |
+++ |
━ |
━ |
4. Specification
|
Diaphragm Shape |
Flat Membrane |
|
Filtration Type |
Outside Suction Inner Suction filter method |
|
Material |
Ceramic Part:Al 2 O 3 |
|
Standard Aperture |
0.1μm |
|
Dimensions |
W280×H1046×T12 mm |
|
Quality (dry) |
2.2 kg |
|
Effective membrane area |
0.5 m 2 |
|
Pure water through performance |
40 m 3 /(m 2 -d) (100 kPa, 25 ℃ ) |
|
Particle capture performance |
0.1μm Particle capture rate over 95% |
|
Use pH range |
2 - 12 |
|
Use the upper temperature limit |
80 ℃ |
(*1) Specification of Membrane Components
|
Type |
CH250-1000TM50-U1J |
CH250-1000TM50-U2J |
|
Diaphragm Qty. |
50 |
100 Pieces (2 Section) |
|
Effective Membrane Area |
25 m 2 |
50 m 2 |
|
Water Treatment (*2) |
25 m 3 /d |
50 m 3 /d |
|
Dimensions(mm) |
W754 x H1616 x D320 |
W754x H2820 x D320 |
|
Weight(dry) |
181 kg |
364 kg |
(*1) The specifications of the unit can be negotiated separately
(*2) This value is the value obtained by the identification test, not the guarantee value
PACKAGE:
Standard packing or as customer request .
DELIVERY TIME:
Within 7 days if instock, or according to the Order QTY and we'll detail you the date of shipment.
