E Series 32V 48V 350 Amp 9001E Red Selector Battery Isolation Switch Single Dual Battery Operation 3 Position with AFD for Boat

E Series 32V 48V 350 Amp 9001E Red Selector Battery Isolation Switch Single Dual Battery Operation 3 Position with AFD for Boat

FOB Reference Price: Get Latest Price

≥100 Pieces

US $12

≥200 Pieces

US $11.5

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: senreach

Model Number:: 9001E 9002E 3 Position Manual Battery Switch

Max. Current:: 350Amps DC

Product Name:: RV Marine Boat 32V 350A Single Dual 9001E Manual Battery Switch

Rated Voltage:: 32V 48V DC

Rated Current:: 350A DC

Material:: Plastic+Copper

Stud:: 3/8''-16

Operation Type:: On-Off

Electrical Life:: 10000 Times

Switch Type:: Manual Battery Switch

Certification:: ROHS, ROHS

Application:: RV, Yacht, Van, Truck, Caravan, Vehicle

Quick Details

Whether the smart:: Yes

Max. Voltage:: 48V DC

Place of Origin:: Guangdong, China

Brand Name:: senreach

Model Number:: 9001E 9002E 3 Position Manual Battery Switch

Max. Current:: 350Amps DC

Product Name:: RV Marine Boat 32V 350A Single Dual 9001E Manual Battery Switch

Rated Voltage:: 32V 48V DC

Rated Current:: 350A DC

Material:: Plastic+Copper

Stud:: 3/8''-16

Operation Type:: On-Off

Electrical Life:: 10000 Times

Switch Type:: Manual Battery Switch

Certification:: ROHS, ROHS

Application:: RV, Yacht, Van, Truck, Caravan, Vehicle

The Description of 32V 48V DC 300A 350A Single Dual Circuit E Series E Systems 9001E 9002E Red Manual Main Battery Isolator Cutoff Switch 3 Position 4 Position IP66 Waterproof for Truck RV Marine Boat

E Series 32V 48V 300Amp 350 Amp 9001E 9002E Red Selector Main Manual Battery Isolation Cutoff Switch Alternator Disconnect Single Dual Battery Operation 3 Position 4 Position IP66 Waterproof Ignition Protected with AFD for RV Boat

•IGNITION PROTECTED BATTERY SWITCH

• DURABLE ALUMINUM CASE

• ADVANCED MULTI STAGE CHARGING

• BUILT IN SAFETY FEATURES

-Applied to RV, travel trailer, marine, boat, camper, truck, ATV, UTV, etc.

- Selector 3 Position. Switches isolated battery banks to all loads or combines battery banks to all loads. Includes AFD (Alternator Field Disconnect)

Durable Made for Safety Use/ Built To Prolong Battery Tin-plated/ Copper Studs for Maximum Conductivity and Corrosion Resistance/ Lifespan/ Prevent the Start Battery from Being Run Down/ Waterproof Shockproof Withstand Harsh Weather

The Details of 32V 48V 300A 350A Single Dual Circuit E Series E Systems 9001E 9002E Red Manual Main Battery Isolator Cutoff Switch Alternator Disconnect 3 Position 4 Position IP66 Waterproof Ignition Protected Shockproof Dust-resistance for Truck Marine Boat 5 Wheels SUV Boat RV Camper Yacht Car Watercraft Off-Road Vehicle Vans

Rated Current	350Amps DC
Rated Voltage	32V 48V DC
Continuous Rating	350Amps DC
Model Number	E series 9001E 9002E
Type	Manual Battery Switches
Material	Plastic+Copper
Stud Material	Tinned Copper
Color	Red
Terminal Stud Torque	140 in-lb (15.82 Nm)
Cable Clearance For 4/0 AWG Cables	10in (27.94 mm)
Cable Size to Meet Ratings	4/0 AWG (120mm²)
Terminal Stud Size	3/8" - 16 (M10)
Mounting	Recessed or Surface
Mounting Holes	Accept 1/4" (M6) Screw
Switch Positions	3
Battery Inputs	2
Intermittent Rating	600A (5 Min)
Cranking Rating	30 Sec 1200A
Dielectric Strength	1500VAC/1min
Lifespan	1000 Times
Operation Type	On-Off
Contact Resistance	50m ohm Max
Insulation Resistance	DC 1500V 100M ohm Min
Operation Temperature	-30°C~+60°C
IP Rating	IP66 waterproof
Feature	Ignition Protected—Sfe for Installation Aboard Gasoline Powered Boats
Application	Vans, Trucks, RVs, Yacht, Motorhomes, ATV, UTV, Boats, Marine, etc
Certification	ROHS, ISO 8846 and meets ABYC requirements

Installation Instruction

Working Principle:

The 9001E 9002E Manual Battery Isolator Switch is a mechanical switch that is used to disconnect the battery from the electrical system of a vehicle or equipment. It works by interrupting the flow of current between the battery and the electrical system. The manual switch has two main positions, on and off. When the switch is turned on, it allows the flow of current from the battery to the electrical system. This enables the electrical system to power various components such as lights, radio, and other electrical devices. When the manual switch is turned off, it interrupts the flow of current from the battery to the electrical system, thereby disconnecting the battery from the electrical system. This ensures that no electrical power flows to any of the components, preventing them from consuming any energy. The 9001E 9002E Manual Battery Isolator Switch also has a third position, which is the "start" position. In this position, the switch allows the flow of current from the battery to the starter motor, which is used to start the engine of the vehicle or equipment. The manual switch is operated by a lever or knob, which is moved to the desired position. When the switch is moved, it either connects or disconnects the circuit depending on the position.

The Product Size of 32V 48V 300Amp 350Amp Single Dual Circuit E series E Systems 9001E 9002E Red Manual Main Battery Isolator Cutoff Switch Alternator Disconnect 3 Position IP66 Waterproof Ignition Protected for Heavy Duty Motorhomes

The Feature of 32V 48V 300Amp 350Amp Single Dual Circuit E series E Systems 9001E 9002E Red Manual Main Battery Isolator Cutoff Switch Alternator Disconnect 3 Position IP66 Waterproof Ignition Protected for Heavy Duty Motorhomes Vans Trucks RVs Motorhomes ATV UTV Boats Off Road Vehicles Yacht Marine Boats

【Easy to install】 The E series 9001E 9002E red manual main battery isolator cutoff switch is designed for easy installation and can be mounted in a variety of locations. It comes with mounting hardware and an instruction manual that makes installation quick and straightforward. 【High current capacity】 The E series 9001E 9002E manual main battery isolator switch alternator disconnect has a high current capacity, allowing it to handle large currents without overheating or malfunctioning. This makes it suitable for use in heavy-duty applications. 【Durable construction】 The 3 position E series 9001E 9002E manual main battery isolator switch is built with durable materials, including a rugged housing and high-quality electrical contacts. This ensures that it can withstand harsh environments and rough handling. Tin-plated copper studs for maximum conductivity and corrosion resistance. 【Three-position operation】 The E series 9001E 9002E IP66 waterproof manual main battery isolator switch has three positions - on, off, and start. This makes it easy to operate and provides additional functionality, such as allowing the user to start the engine of the vehicle or equipment. 【Versatile applications】 The E series 9001E 9002E ignition protected manual battery isolator switch can be used in a wide range of applications, including cars, trucks, boats, RVs, and other equipment that use a battery.

Why Choose Us/Our Advantages

The Senreach ignition protected manual battery isolator switch are compact, weather proof and light weight designed. The highly visible manual reset switch allows for a clear fault indication. Ignition protection and flame resistant materials makes these breakers ideal for installation in gasoline powered vehicles and engine compartments. The terminal studs are front facing for ease of installation and covered with protective caps to prevent short circuits and current jumps.

Application

Widely Application: The E series 9001E 9002E red ignition protected IP66 waterproof main battery isolator cutoff switch alternator disconnect 3 position is universal type, can be wiely used in Heavy Duty, Car, Vehicles, P assenger Cars, Tractors, Professional Racing Cars, Truck, Vans, Trucks, RVs, Motorhomes, ATV, UTVs, 5 Wheels SUV, Boats, Off Road Vehicles,Campers, Yacht, Marine, Caravan, Construction Equipment, Excavators, Bulldozers, etc.
