Quick Details
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P40
-
Pixel Pitch:
-
40mm, 40mm, 40mm
-
Specification:
-
Other
-
Brightness:
-
1875 cd/sqm
-
Pixel Density:
-
625 dots/sqm
-
Viewing Angle:
-
120°(H)/120°(V)
-
Operation Power:
-
AC100~240V
-
Operating Temperature:
-
-20℃~45℃
-
Operating Humidity:
-
10%~90%RH
-
Operating Life:
-
≥100,000 hours
-
Warranty:
-
2 Years
-
Screen Dimension:
-
Customized
Quick Details
-
Application:
-
Indoor, Outdoor, Other
-
Type:
-
LED
-
Panel Size:
-
customized, customized
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P40
-
Pixel Pitch:
-
40mm, 40mm, 40mm
-
Specification:
-
Other
-
Brightness:
-
1875 cd/sqm
-
Pixel Density:
-
625 dots/sqm
-
Viewing Angle:
-
120°(H)/120°(V)
-
Operation Power:
-
AC100~240V
-
Operating Temperature:
-
-20℃~45℃
-
Operating Humidity:
-
10%~90%RH
-
Operating Life:
-
≥100,000 hours
-
Warranty:
-
2 Years
-
Screen Dimension:
-
Customized
Products Description
Specification
|
Pixel Information
|
FB-P35
|
FB-P40
|
FB-P50
|
FB-P80
|
FB-P100
|
||||
|
Pixel Pitch (mm)
|
35
|
40
|
50
|
80
|
100
|
||||
|
Physical Density (dot/m2)
|
816
|
625
|
400
|
156
|
100
|
||||
|
Brightness
|
2448 cd/sqm
|
1875 cd/sqm
|
1200 cd/sqm
|
468 cd/sqm
|
300 cd/sqm
|
||||
|
Unit Power Consumption
|
0.45 W/DOT
|
0.45 W/DOT
|
0.45 W/DOT
|
0.45 W/DOT
|
0.45 W/DOT
|
||||
|
Max.Power Consumption
|
367 W/sqm
|
281 W/sqm
|
180 W/sqm
|
70 W/sqm
|
45 W/sqm
|
||||
|
Ave.Power Consumption
|
122 W/sqm
|
93 W/sqm
|
60W/sqm
|
23 W/sqm
|
15 W/sqm
|
||||
|
Stand module
|
One standard module contains 8 led stripes, each stripe contains a maximum of 128pcs of led dots.(can be customized)
|
|
|
|
|
||||
|
DOT Size
|
20(W)X25(L)X18(H) mm
|
|
|
|
|
||||
|
DOT Weight
|
<6g
|
|
|
|
|
||||
|
LED Type
|
RGB 3in1 SMD2727/3535
|
|
|
|
|
||||
|
Viewing Angle
|
120°(H)/120°(V)
|
|
|
|
|
||||
|
Gray Scale
|
8-12bit
|
|
|
|
|
||||
|
Display Scale
|
68.7 Billion
|
|
|
|
|
||||
|
Refresh Rate
|
≥1920Hz
|
|
|
|
|
||||
|
Control System
|
Mooncell, slavery controller output(400W/DC7.5V)
|
|
|
|
|
||||
|
Operation Power
|
AC100~240V, 50/60Hz
|
|
|
|
|
||||
|
Working Environment
|
Temperature: -20℃~45℃
Humidity: 10~90%RH
|
|
|
|
|
||||
|
IP Rating
|
IP65 for led pixels, IP54 for controller box.
|
|
|
|
|
||||
|
Operating Life
|
≥100,000 hours
|
|
|
|
|
||||
