Quick Details
-
Positioning Accuracy (mm):
-
0.03 mm
-
Travel (X Axis)(mm):
-
600 mm
-
Travel (Y Axis)(mm):
-
900 mm
-
Repeatability (X/Y/Z) (mm):
-
0.03 mm
-
Spindle Motor Power(kW):
-
1.5
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Beta
-
Voltage:
-
AC220V/60Hz,1PH
-
Dimension(L*W*H):
-
600*900*120mm
-
Power (kW):
-
4.5
-
Weight (KG):
-
200
-
Color:
-
white
-
Working area:
-
600*900*120mm
-
Spindle:
-
1.5kw Water Cooling Spindle
-
Inver:
-
Fuling Inverter
-
Transmission:
-
Ball screw
-
Motor and driver:
-
Stepper Motor & Driver
-
Control system:
-
NC studio
-
Software:
-
Artcam
-
OEM:
-
YES
-
Weight:
-
200kg
Quick Details
-
Working Table Size(mm):
-
600×900
-
Machine Type:
-
CNC Router
-
Range of Spindle Speed(r.p.m):
-
1 - 24000 rpm
-
Positioning Accuracy (mm):
-
0.03 mm
-
Travel (X Axis)(mm):
-
600 mm
-
Travel (Y Axis)(mm):
-
900 mm
-
Repeatability (X/Y/Z) (mm):
-
0.03 mm
-
Spindle Motor Power(kW):
-
1.5
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Beta
-
Voltage:
-
AC220V/60Hz,1PH
-
Dimension(L*W*H):
-
600*900*120mm
-
Power (kW):
-
4.5
-
Weight (KG):
-
200
-
Color:
-
white
-
Working area:
-
600*900*120mm
-
Spindle:
-
1.5kw Water Cooling Spindle
-
Inver:
-
Fuling Inverter
-
Transmission:
-
Ball screw
-
Motor and driver:
-
Stepper Motor & Driver
-
Control system:
-
NC studio
-
Software:
-
Artcam
-
OEM:
-
YES
-
Weight:
-
200kg
Beta CNC Router Machine Kit 4 Axis Woodworking Metal Engraver Milling Machine Nema23 stepper motor CNC with small budget
What is the Features of cnc router 6090?
♦ 600x900x120mm working size
♦ 1.5kw water cooling spindle
♦ T-slot aluminum working table
♦ HIWIN Linear guide
♦ NC studio control system
♦ Stepper motor and driver
♦ Beta interver
♦ Drive System Ball screw
♦ Automatic Tool Calibration
♦ ArtCam software
Option:
♥ Vacuum System
♥ Dust Collector system
♥ Stepper motors
♥ HSD Spindle
♥ Rotary Axis
What is the Advantage of mini cnc router6090?
♦ Multi-function cnc router machine with heavy duty welded structure.
♦ 1.5kw water cooling spindle with 24000r/min .
♦ Fast speed and high precision.
♦ NC studio controller, PC operation ;dustproof design,is very convenient.
♦ HIWIN linear rail from Taiwan for 3 aixs, more stable, it's lifetime is 10 times longer than common rail way.
Technical Parameters of cnc router6090
|
NO. |
Items |
Parameters |
Option |
||
|
1 |
Working Area |
XYZ |
600*900*120mm |
≤200mm |
|
|
3 |
Table Type |
T-Slot aluminum |
Vacuum table |
||
|
4 |
Accuracy |
Working Accuracy |
±0.03/300mm |
||
|
Repositioning Accuracy |
±0.03/300mm |
||||
|
6 |
Drive system |
X,Y with Rack and Pinion Z with lead screw |
|||
|
7 |
Speed |
MAX Traveling Speed |
32000mm/min |
||
|
MAX Working Speed |
15000mm/min |
||||
|
8 |
Spindle |
Spindle Power |
1.5KW water cooling spindle |
Italian HSD Spindle |
|
|
Spindle Speed |
0-24000r/min Stepper |
Servo |
|||
|
10 |
Drive and Motor |
||||
|
12 |
Working Voltage |
AC380V/50Hz |
AC220V/60Hz |
||
|
14 |
Operating System |
NC Studio |
|
||
|
15 |
Net Weight/Gross Weight |
200KG/300 KG |
|||
|
16 |
Packing size |
1200*1400*1000mm
|
|||
What is the Benefits of smart cnc router 6090?
♥ Decoration industries: 3d woodworking,screens, wave boards, large-size wall hangings, advertising boards and sign making.
♥ Arts & Crafts industries: Engrave on artificial woods, bamboos, organic boards, double-color boards and so on for achieveing effects of exquisite patterns and characters.
♥ Processing material: engraving, milling and cutting processing for acrylic, PVC, density boards, artificial stones, organic glass, plastics and soft metal sheets such as copper and aluminum.
Customer in our factory from all over the world:
What is our packaging?
Why choose us?
Payment:
T/T,30% deposit and the balance 70% should be paid before shipment
Our main product:
CNC routers, CNC Engravers, laser engravers, plasma cutting machines, and knife cutting machines in China
Advantage of our company
1.Experience and professional
2.Talented and passionate work team
3.high tech products
4.perfect after-sale service
To provide you detailed quotation, we need to confirm the following detailes :
1.what is raw material
2.the size of material
3.Your other requirement
