Quick Details
-
Holding Stength:
-
300kg
-
Voltage:
-
DC12V
-
Special Design:
-
Adjust Lock-tongue to NO style
-
Suitable for:
-
Narrow Wooden Door,Narrow Metal Door
-
Function:
-
Built-out MOV
-
Strike structure:
-
Zinc die-casting
-
Certification:
-
CE/MA
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YLI
-
Lock Size:
-
250Lx25Wx28.85H(mm)
-
Holding Stength:
-
300kg
-
Voltage:
-
DC12V
-
Special Design:
-
Adjust Lock-tongue to NO style
-
Suitable for:
-
Narrow Wooden Door,Narrow Metal Door
-
Function:
-
Built-out MOV
-
Strike structure:
-
Zinc die-casting
-
Certification:
-
CE/MA
Product Description
Product Application
YM-60 is a mini single door electric lock, it is designed for showcase, cabinet door and easy to install . The holding force is 120lbs.
|
Lock Size
|
250Lx25Wx28.5H(mm) (YS-134ELK)
|
|
|
||
|
Strike Structure
|
Zinc die-casting
|
|
|
||
|
Holding Force
|
300kg
|
|
|
||
|
Voltage
|
DC12V （Available DC24V）
|
|
|
||
|
Current
|
12V/280mA ; 24V/160mA
|
|
|
||
|
Special Design
|
Adjust Lock-tongue to NO style
|
|
|
||
|
Suitable For
|
Narrow Wooden Door,Narrow Metal Door
|
|
|
||
|
Suitable Temperature
|
-10~+55℃(14-131F)
|
|
|
||
|
Operating Humidity
|
0～95%(non-condensing)
|
|
|
||
|
Face plate Housing
|
Surface by coating nickel
|
|
|
||
|
Function
|
Built-out MOV
|
|
|
||
|
Certificate
|
MA CE-EMC CE-LVD FCC-VOC REACH WEEE
|
|
|
||
|
Weight
|
0.35kg
|
|
|
||
