Quick Details
-
Tent Frame:
-
Hard pressed extruded aluminium alloy 6061/T6
-
Roof Cover:
-
850g/sqm double PVC-coated polyester textile
-
Side Wall:
-
PVC walls,glass wall,ABS wall,sandwich panel wall,etc.
-
Eave Connection:
-
Hot-dip galvanized twin plate;expansion bolts to fix tent
-
Fixing Solution:
-
Ground anchor, Expandable bolt, Weight plate, etc.
-
Certificates:
-
CFM,TUV,CE,BV
-
Ground Situation:
-
Grassland,earth land,asphalt ground,cement ground
-
Wind Resistance:
-
100km/h
-
Span Width:
-
3m-80m
Quick Details
-
Brand Name:
-
KENTEN
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
Party tent
-
Tent Frame:
-
Hard pressed extruded aluminium alloy 6061/T6
-
Roof Cover:
-
850g/sqm double PVC-coated polyester textile
-
Side Wall:
-
PVC walls,glass wall,ABS wall,sandwich panel wall,etc.
-
Eave Connection:
-
Hot-dip galvanized twin plate;expansion bolts to fix tent
-
Fixing Solution:
-
Ground anchor, Expandable bolt, Weight plate, etc.
-
Certificates:
-
CFM,TUV,CE,BV
-
Ground Situation:
-
Grassland,earth land,asphalt ground,cement ground
-
Wind Resistance:
-
100km/h
-
Span Width:
-
3m-80m
|
Frame
|
4 channels, hard pressed extruded
aluminium alloy
6061/T6.
(Surface anodized finish. Anti rust.)
|
|
|
|
|||
|
Roof Cover
|
Opaque(or transparent), water proof, 850g/m². Flame retardant.
PVC-coated Polyester
.
|
|
|
|
|||
|
Side Wall
|
1) 650g/m² PVC-coated Polyester
2) glass wall
3) ABS wall |
|
|
|
|||
|
Wind Resistance
|
80~140km/h
|
|
|
|
|||
|
Snow Load
|
25kg/sqm
|
|
|
|
|||
|
Fixing Solution
|
Ground anchor, expandable bolt, weight plate, etc.
|
|
|
|
|||
|
Service Life
|
More than
15 years
|
|
|
|
|||
|
Applicable temperature range
|
-30 degree Celsius ~ +70 degree Celsius
|
|
|
|
|||
|
Ground Situation
|
Grassland,earth land,asphalt,cement ground,marble,etc
|
|
|
|
|||
|
Connectors
|
Hot-dip galvanized twin plate;expansion bolts to fix tent
|
|
|
|
|||
|
A STRUCTURE TENT
|
|
|
|
|
||||
|
Item
|
Width
|
Eave Height
|
Ridge Height
|
Main Profile
|
||||
|
Villa Series K1
|
3m
|
2.79m
|
3.21m
|
100×48×3mm
|
||||
|
Villa Series K1
|
6m
|
2.79m
|
3.86m
|
100×48×3mm
|
||||
|
Villa Series K2
|
9m
|
2.6m
|
4.28m
|
120×48×3×5.5mm
|
||||
|
Villa Series K2
|
12m
|
2.6m
|
4.82m
|
120×48×3×5.5mm
|
||||
|
Villa Series K2
|
15m
|
2.6m
|
5.37m
|
120×48×3×5.5mm
|
||||
|
Temple Series K3
|
40'
|
10'
|
16.55'
|
166×88×3mm
|
||||
|
Temple Series K3
|
50'
|
10'
|
18.18'
|
166×88×3mm
|
||||
|
Temple Series K3
|
60'
|
10'
|
19.82'
|
166×88×3mm
|
||||
|
Temple Series K4
|
10m
|
3.5m
|
5.15m
|
150×120×3×5mm
|
||||
|
Forum Series K5
|
18m
|
4m
|
6.94m
|
200×120×4×4.5mm
|
||||
|
Forum Series K5
|
20m
|
4m
|
7.27m
|
200×120×4×4.5mm
|
||||
|
Forum Series K6
|
25m
|
4m
|
8.12m
|
250×120×4×6mm
|
||||
|
Forum Series K6
|
30m
|
4m
|
8.93m
|
250×120×4×6mm
|
||||
|
Arena Series K7
|
30m
|
4m
|
9.05m
|
300×120×5×7mm
|
||||
|
Arena Series K8
|
40m
|
6m
|
12.57m
|
350×120×5×7mm
|
||||
|
Arena Series K8
|
50m
|
6m
|
14.18m
|
350×120×5×7mm
|
||||
|
Stadia Series K9
|
60m
|
6m
|
15.85m
|
420×120×6×8mm
|
||||
|
Stadia Series K10
|
70m
|
6m
|
17.5m
|
500×120×6×8mm
|
||||
|
Stadia Series K10
|
80m
|
6m
|
19.12m
|
500×120×6×8mm
|
||||
|
3m to 80m span width available to be customized.
|
|
|
|
|
||||
