Quick Details
-
Place of Origin:
-
Guangdong, China
-
Voltage:
-
220/380V 50/60 HZ
-
Power:
-
2200W
-
Dimension(L*W*H):
-
1100*265*920 mm
-
Weight:
-
95 KG
-
Machinery Function:
-
Fruit Juice Making
-
Output product name:
-
Fruit Juice
-
Capacity:
-
500 KG/H
-
Screw diameter:
-
87.5 mm
-
The filter aperture:
-
0.6 MM
-
GW:
-
110 KG
-
Packing size:
-
1160*420*920 MM
-
After Warranty Service:
-
Spare parts
-
Local Service Location:
-
None
-
After-sales Service Provided:
-
Free spare parts
-
Certification:
-
CE
Quick Details
-
Raw material:
-
Fruit
-
Model Number:
-
CY-0.5
-
Brand Name:
-
Chuangyu
-
Place of Origin:
-
Guangdong, China
-
Voltage:
-
220/380V 50/60 HZ
-
Power:
-
2200W
-
Dimension(L*W*H):
-
1100*265*920 mm
-
Weight:
-
95 KG
-
Machinery Function:
-
Fruit Juice Making
-
Output product name:
-
Fruit Juice
-
Capacity:
-
500 KG/H
-
Screw diameter:
-
87.5 mm
-
The filter aperture:
-
0.6 MM
-
GW:
-
110 KG
-
Packing size:
-
1160*420*920 MM
-
After Warranty Service:
-
Spare parts
-
Local Service Location:
-
None
-
After-sales Service Provided:
-
Free spare parts
-
Certification:
-
CE
2.2KW automatic industrial carrot spiral screw tomato juicer
Installation operation and maintenance
1. The machine must be installed horizontally and fixed with anchor screws.
2. Operation: When the equipment is started, the indenter should be adjusted to maximize the annular gap, and then the gap will gradually decrease. After the process requirements are met,
Use the brake to fix the position of the handwheel bearing seat.
3. The feed must be uniform, and it is strictly forbidden to enter the hopper with hard foreign objects to avoid damage to the screen.
4. Maintenance: The filter screen must be washed with water and brush after each shift. If the juice with more fiber is refined, it depends on the production situation
In addition, wash the net once in a while, and wash all the machines with hot water after pressing.
5. The bearings are regularly replaced and filled with clean grease. The normal use temperature of the bearings is less than 75 degrees.
| Model | CY-0.5 |
| Capacity | 500KG/H |
| Screw diameter | Φ87.5mm |
| The filter aperture | 0.6mm |
| Power | 2200w |
| Voltage | 380V 50Hz |
| NW | 200kg |
| Juice Power | 1.5kw |
| Broken power | 0.75kw |
| Dimensions | 1100*350*1280mm |
