> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25years, 25 Years Output Power Guarantee
-
Brand Name:
-
BLUESUN
-
Model Number:
-
BSM380M-72
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1956*992*40mm
-
Certificate:
-
TUV CE ETL
-
Solar cell:
-
Mono 156*156 Cell
-
Junction Box:
-
IP65 Rated
-
Frame:
-
Anodized Aluminium Alloy
-
Connector:
-
PV Compatible Connector
-
Color:
-
Blue Ad Black
-
OEM Order:
-
Acceptable
-
Front Cover:
-
3.2mm High transmission, low Iron
Quick Details
-
Cell size:
-
125mmx125mm
-
Type:
-
PERC
-
Panel Efficiency:
-
18.8%
-
Warranty:
-
25years, 25 Years Output Power Guarantee
-
Brand Name:
-
BLUESUN
-
Model Number:
-
BSM380M-72
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1956*992*40mm
-
Certificate:
-
TUV CE ETL
-
Solar cell:
-
Mono 156*156 Cell
-
Junction Box:
-
IP65 Rated
-
Frame:
-
Anodized Aluminium Alloy
-
Connector:
-
PV Compatible Connector
-
Color:
-
Blue Ad Black
-
OEM Order:
-
Acceptable
-
Front Cover:
-
3.2mm High transmission, low Iron
Contact Me
Product Description
|
Moduel
|
BSM330M-72
|
BSM340M-72
|
BSM350M-72
|
BSM355M-72
|
BSM360M-72
|
||||
|
Rated Maximum Power at STC
|
330W
|
340W
|
350W
|
355W
|
360W
|
||||
|
Open CircuitVoltage(Voc/V)
|
46.34
|
46.91
|
46.9
|
47
|
47.2
|
||||
|
Maximum Power Voltage(Vmp/V)
|
37.57
|
38.17
|
38.5
|
38.7
|
38.9
|
||||
|
Short Circuit Current(Isc/A)
|
9.29
|
9.41
|
9.55
|
9.69
|
9.79
|
||||
|
Maximum Power Current(Imp/A)
|
8.78
|
8.91
|
9.07
|
9.17
|
9.26
|
||||
|
Module Efficiency(%)
|
17.02
|
17.54
|
18.00
|
18.3
|
18.5
|
||||
|
Power Tolerance
|
-0~+5W
|
|
|
|
|
||||
|
Standard Test Condition(STC)
|
Irradiance 1000W/m2,Cell Temperature 25℃,Air Mass1.5
|
|
|
|
|
||||
Detailed
Glass
Solar Cell
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
Frame
> Conventional frame
> Silver or black frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength
> Seal-lip designglue injection
Junction box
> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life
Packing & Delivery
Project
250KW on grid solar project in Malta,EU
60KW on grid solar project in Guatemala,South America
1.2MW solar power plant in Ecuador,South America
144KW on grid solar project in California,USA
150KW on grid solar project in Japan
