Quick Details
-
Keyword:
-
Folding Container Houses
-
Type:
-
Folding Container House
-
Advantage:
-
Fast Install
-
Certification:
-
CE
-
Structure:
-
Steel Frame
-
Door:
-
Steel Security Door
-
Window:
-
Steel Security Window
-
Life span:
-
10 Years
Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Kowin House
-
Product name:
-
Foldable Portable Mobile House
-
Keyword:
-
Folding Container Houses
-
Type:
-
Folding Container House
-
Advantage:
-
Fast Install
-
Certification:
-
CE
-
Structure:
-
Steel Frame
-
Door:
-
Steel Security Door
-
Window:
-
Steel Security Window
-
Life span:
-
10 Years
Products Description
|
Product specifications |
External dimension (mm)
|
5800 *2480 *2560
|
|
|
Internal dimension (mm)
|
5640*2320*2400
|
|
|
Folding state (mm)
|
5800 *2480 *400
|
|
|
Total mass (kg) |
1000~1300 Including doors and Windows and simple indoor electrical switch socket [1*40HQ It holds 10 sets]
|
|
Main body frame |
Top frame |
Top main beam: Rectangular square tube60×80×1.3mm
|
|
|
|
Top bearing bottom: Rectangular square tube40×40×1.3mm
|
|
|
|
Internal ceiling: Color steel veneerV930*0.25㎜
|
|
|
|
Insulating glass wool: Glass wool roll 50mm (unit weight 16kg)
|
|
|
|
External roof panel: Galvanized sheet0.5mm
|
|
|
|
Protective coating for integral frame: Electrostatic spray/high gloss
|
|
|
|
Hanging head: 155*110*（6mm)
|
|
|
Bottom frame |
Bottom main beam: Rectangular square tube 60×140×1.3mm
|
|
|
|
Bottom bearing: Rectangular square tube 40×40×1.3mm
|
|
|
|
Front and rear main beams: Rectangular square tube60×80×1.3mm
|
|
|
Stand column |
Side wall frame: Rectangular square tube40×60×1.3mm
|
|
|
|
Galvanized buckle groove: 50mm
|
|
|
|
Fold hinge: Galvanized hinge 13mm
|
|
Floor
|
Floor board
|
Fireproof glass magnesium floor18mm
|
|
Door
|
High grade steel door
|
High-quality security door（Warm white）930mm*1970mm
|
|
Window |
The anti-theft window
|
930*930Plastic steel anti-theft integrated window、Glass thickness4mm（Warm white）
|
|
Simple electric distribution |
Simple electric distribution |
Electrical wiring，Install in strict accordance with moisture-proof specifications，All electricalAll electrical products shall
comply with ce certification. Connect the circuit according to the circuit engineering specification，indoor: coil in4²National standard flexible copper wire, 20 Acircuit breaker 1, Socket incoming line 2.5², three-hole single socket3pcs，2 lamps. |
|
Wallboard |
Model |
50mm Composite plate0.23mm+Basalt rock wool(unit weight50kg）+0.23mm
|
|
Optional Accessories |
Optional Accessories
|
Furniture, sanitary, kitchen, A/C, electrical appliance for accomodation, office, dormitory, toliet, kitchen, bathroom, shower,
steel roof, cadding panels, decorative material, etc. |
|
Load bearing/level |
Roof bearing capacity
|
≧50kg/m²
|
|
|
Aisle bearing capacity
|
≧200kg/m²
|
|
|
Floor load bearing
|
≧150kg/m²
|
|
|
Wall side pressure
|
≧80kg/m²
|
|
|
Wall deformation coefficient
|
≦300kg/m²
|
|
|
Fire protection level
|
Class A
|
|
|
Seismic grade
|
Level 10
|
|
|
Wind resistance rating
|
Level 11
|
