- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
NANFENG
-
Voltage:
-
380
-
Power:
-
22KW
-
Dimension(L*W*H):
-
21X0.84X1.56
-
Weight:
-
5 KG
-
Spindle:
-
192
-
After-sales Service Provided:
-
Online support
Quick Details
-
Application:
-
STAPLE Fiber
-
Production Capacity:
-
300kgs-400kgs
-
Memory Capacity:
-
1
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
NANFENG
-
Voltage:
-
380
-
Power:
-
22KW
-
Dimension(L*W*H):
-
21X0.84X1.56
-
Weight:
-
5 KG
-
Spindle:
-
192
-
After-sales Service Provided:
-
Online support
Product Description
Specification
|
Machine type
|
Double side single layer
|
|
Spindle speed
|
MAX : 10000r/min
|
|
Twist Range
|
156-2027TPM
|
|
Twist direction
|
S or Z
|
|
Winding dia
|
Ø250
|
|
Winding speed
|
<=100m/min
|
|
Power
|
Servo motor:1.88kw x 1
|
|
|
Gearing motor:2.2kwx1
|
|
|
Main motor:22kw x1
|
|
Dimension
L*W*H |
L:2060+2045X9 +250 W:840MM H:1560mm
|
|
Start model
|
Inverter start
|
|
Automatic move up
|
Automatic move up
|
|
Yarn cross angle
|
Any angle setting by computer
|
|
Feeding bobbin
|
Ø37.2xØ43.5x230mm
|
|
Take up bobbin
|
170mm~175mm
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
