Quick Details
-
Keyword:
-
container
-
Structure:
-
Steel Structure Frame Welded
-
Size:
-
3m*6m*2.75m(H)
-
Usage:
-
office, home, dormirory
-
Window:
-
Aluminum Window
-
Door:
-
metal Security
-
Certification:
-
CE ISO
-
Product name:
-
Prefabricated House
-
Name:
-
Fast House
-
Type:
-
Customizable
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GUIZU
-
Product Type:
-
Prefab House
-
Keyword:
-
container
-
Structure:
-
Steel Structure Frame Welded
-
Size:
-
3m*6m*2.75m(H)
-
Usage:
-
office, home, dormirory
-
Window:
-
Aluminum Window
-
Door:
-
metal Security
-
Certification:
-
CE ISO
-
Product name:
-
Prefabricated House
-
Name:
-
Fast House
-
Type:
-
Customizable
Products Description
|
Technical Parameters
|
Description
|
|
|
||
|
Product name
|
Prefab house
|
|
|
||
|
Country of Origin
|
Guandong, China
|
|
|
||
|
Color
|
customized
|
|
|
||
|
Design
|
Flexible design
|
|
|
||
|
Materials
|
Steel and sandwich panel
|
|
|
||
|
Transportation
|
By sea
|
|
|
||
|
Brand
|
GUIZU
|
|
|
||
|
uses
|
residential and commercial
|
|
|
||
|
Frame
|
Welded/ Hot rolled H beam
|
|
|
||
|
Type
|
packing container, shipping container reconstruction or customized
|
|
|
||
|
Interior decoration
|
customized
|
|
|
||
|
Certification
|
CE
|
|
|
||
|
Wall and Roof
|
EPS or glass wool panel
|
|
|
||
|
Window
|
PVC or Aluminum Alloy
|
|
|
||
|
Steel standard
|
Q235
|
|
|
||
|
Wind load
|
<35m/s
|
|
|
||
|
Earthquake resistance
|
7 fission resistant
|
|
|
||
Product Paramenters
Specification of Raw Materials
|
item
|
EPS
|
Glass Wool
|
TPS Board
|
Rock Wool
|
|
waterproof
|
★★★★★
|
★★★
|
★★★★★
|
★★★
|
|
fireproof
|
★★
|
★★★★★
|
★★★★★
|
★★★★★
|
|
Heat Insulation
|
★★★
|
★★★★
|
★★★★
|
★★★★
|
|
Sound Insulation
|
★★★★
|
★★★★
|
★★★★★
|
★★★★
|
|
Price Comparison
|
★★
|
★★★
|
★★
|
★★★★
|
|
Density Range
|
10-14kg/m3
|
100-120kg/m3
|
40-200kg/m3
|
100-250kg/m3
|
|
Accessories Name
|
Description
|
|
Ground Beam
|
14#/16# H-beam, 12# channel steel;
100*100*3.0 /150*75*3.0 / 120*60*3.0galvanized steel tube; 120*120*3.0 / 150*150*3.0 bending parts |
|
Pillar/Column
|
100*100*3.0 /150*75*3.0 / 120*60*3.0galvanized steel tube;
120*120*3.0 / 150*150*3.0 bending parts |
|
Floor beam
|
100*100*3.0 / 150*75*3.0 / 120*60*3.0 / 60*60*2.0 galvanized steel tube;
60*60*3.0 / 120*120*3.0 / 150*150*3.0 bending parts |
|
Floor Purlin
|
8# channel steel;
80*80*2.0 / 50*100*2.0 / 40*80*2.0 galvanized steel tube |
|
Stairs
|
150*30 C-type steel
|
|
Walkway Board
|
anticorrisive woods
|
|
External Wall
|
0.8mm/1.5mm/2.0mm Corrugated galvanized steel board;
0.46mm pre-painted galvanized steel board |
|
Internal Wall
|
0.46mm / 0.36mm / 0.26mm pre-painted galvanized steel board
|
|
Roof Panel
|
0.8mm/1.5mm/2.0mm Corrugated galvanized steel board;
0.46mm pre-painted galvanized steel board |
|
Edge
|
PVC capping seal, bamboo and woods fiber capping seal
|
|
Floor
|
Glass magnesium board, PVC composition tile, ceramic tiles
|
|
Window
|
Sliding window, casement window, hanging window, double-glazed glass window（thickness can be customized)
|
|
Door
|
Security door, plastic steel door, steel door, stainless steel door
|
