Quick Details
-
Warranty:
-
30 years
-
Brand Name:
-
LONGI
-
Model Number:
-
LONGI Hi-MO 5/6/7
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2278*1134*35mm
-
Maximum static load on the front:
-
5400Pa
-
Maximum static load on the back:
-
2400Pa
-
Hail test:
-
Diameter 25 mm, impact speed 23 m/s
-
Certificate:
-
CE/TUV/VDE
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, N-TYPE, TOPCON, HPBC
-
Panel Efficiency:
-
23.2%
-
Warranty:
-
30 years
-
Brand Name:
-
LONGI
-
Model Number:
-
LONGI Hi-MO 5/6/7
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2278*1134*35mm
-
Maximum static load on the front:
-
5400Pa
-
Maximum static load on the back:
-
2400Pa
-
Hail test:
-
Diameter 25 mm, impact speed 23 m/s
-
Certificate:
-
CE/TUV/VDE
About LONGi
Picture of Longi Taizhou Solar Panels Factory
Founded in 2000, LONGi Green Energy Technology Co., Ltd. (LONGi) is committed to being the most valuable solar technology company
in the world.Longi's shipment volume is far ahead of its peers, ranking first in 2020, 2021, and 2022, among the few in the world.
in the world.Longi's shipment volume is far ahead of its peers, ranking first in 2020, 2021, and 2022, among the few in the world.
Certificate of Authorized Company
LONGi
×
SOLAR
MAN
Product Description
|
LONGi Hi-MO
7
LR5-72HGD 560-590M
|
|
|
|
|
||||
|
Module model
|
LR5-72HGD-
570M
|
LR5-72HGD-
575M
|
LR5-72HGD-
580M
|
LR5-72HGD-
585M
|
||||
|
Maximum power (Pmax/W)
|
570
|
575
|
580
|
585
|
||||
|
Open circuit voltage (Voc/V)
|
51.19
|
51.30
|
51.41
|
51.52
|
||||
|
Short circuit current (Isc/A)
|
14.05
|
14.14
|
14.22
|
14.30
|
||||
|
Peak power voltage (Vmp/V)
|
43.00
|
43.11
|
43.22
|
43.33
|
||||
|
Peak power current (Imp/A)
|
13.26
|
13.34
|
13.42
|
13.51
|
||||
|
Module efficiency(%)
|
22.1
|
22.3
|
22.5
|
22.6
|
||||
|
Standard test conditions
|
STC：AM1.5 1000W/m² 25℃
|
|
|
|
||||
|
Packing
|
36pcs per pallet / 180pcs per 20'GP / 720pcs per 40'HC
|
|
|
|
||||
|
LONGi Hi-MO
6
Scientist LR5-72HTH 590-600M
|
|
|
|
|||
|
Module model
|
LR5-72HTH-590M
|
LR5-72HTH-595M
|
LR5-72HTH-600M
|
|||
|
Maximum power (Pmax/W)
|
580
|
595
|
600
|
|||
|
Open circuit voltage (Voc/V)
|
52.51
|
52.66
|
52.81
|
|||
|
Short circuit current (Isc/A)
|
14.33
|
14.40
|
14.46
|
|||
|
Peak power voltage (Vmp/V)
|
44.36
|
44.51
|
44.66
|
|||
|
Peak power current (Imp/A)
|
13.31
|
13.37
|
13.44
|
|||
|
Module efficiency(%)
|
22.8
|
23.0
|
23.2
|
|||
|
Standard test conditions
|
STC：AM1.5 1000W/m² 25℃
|
|
|
|||
|
Packing
|
36pcs per pallet / 180pcs per 20'GP / 720pcs per 40'HC
|
|
|
|||
|
LONGi Hi-MO
6
Scientist LR5-54HTH 440-450M
|
|
|
|
|||
|
Module model
|
LR5-72HTH-440M
|
LR5-72HTH-445M
|
LR5-72HTH-450M
|
|||
|
Maximum power (Pmax/W)
|
440
|
445
|
450
|
|||
|
Open circuit voltage (Voc/V)
|
39.83
|
40.03
|
40.23
|
|||
|
Short circuit current (Isc/A)
|
14.15
|
14.23
|
14.31
|
|||
|
Peak power voltage (Vmp/V)
|
33.56
|
33.76
|
33.96
|
|||
|
Peak power current (Imp/A)
|
13.12
|
13.19
|
13.27
|
|||
|
Module efficiency(%)
|
22.5
|
22.8
|
23.0
|
|||
|
Standard test conditions
|
STC：AM1.5 1000W/m² 25℃
|
|
|
|||
|
Packing
|
36pcs per pallet / 216pcs per 20'GP / 936pcs per 40'HC
|
|
|
|||
|
LONGi Hi-MO
6
Explorer LR5-72HTH 565-585M
|
|
|
|
|
||||
|
Module model
|
LR5-72HTH-
570M
|
LR5-72HTH-
575M
|
LR5-72HTH-
580M
|
LR5-72HTH-
585M
|
||||
|
Maximum power (Pmax/W)
|
570
|
575
|
580
|
585
|
||||
|
Open circuit voltage (Voc/V)
|
51.91
|
52.16
|
52.21
|
52.36
|
||||
|
Short circuit current (Isc/A)
|
14.07
|
14.14
|
14.20
|
14.27
|
||||
|
Peak power voltage (Vmp/V)
|
43.76
|
43.91
|
44.06
|
44.21
|
||||
|
Peak power current (Imp/A)
|
13.03
|
13.10
|
13.17
|
13.24
|
||||
|
Module efficiency(%)
|
22.1
|
22.3
|
22.5
|
22.6
|
||||
|
Standard test conditions
|
STC：AM1.5 1000W/m² 25℃
|
|
|
|
||||
|
Packing
|
36pcs per pallet / 180pcs per 20'GP / 720pcs per 40'HC
|
|
|
|
||||
|
LONGi Hi-MO
6
Explorer LR5-54HTB 415-435M
|
|
|
|
|
||||
|
Module model
|
LR5-72HTB-
420M
|
LR5-72HTB-
425M
|
LR5-72HTB-
430M
|
LR5-72HTB-
435M
|
||||
|
Maximum power (Pmax/W)
|
420
|
425
|
430
|
435
|
||||
|
Open circuit voltage (Voc/V)
|
39.03
|
39.23
|
39.43
|
39.63
|
||||
|
Short circuit current (Isc/A)
|
13.85
|
13.93
|
14.00
|
14.08
|
||||
|
Peak power voltage (Vmp/V)
|
32.76
|
32.96
|
33.16
|
33.36
|
||||
|
Peak power current (Imp/A)
|
12.83
|
12.90
|
12.97
|
13.05
|
||||
|
Module efficiency(%)
|
21.5
|
21.8
|
22.0
|
22.3
|
||||
|
Standard test conditions
|
STC：AM1.5 1000W/m² 25℃
|
|
|
|
||||
|
Packing
|
36pcs per pallet / 216pcs per 20'GP / 936pcs per 40'HC
|
|
|
|
||||
|
LONGi Hi-MO
5m
LR5-72HPH 545-565M
|
|
|
|
|
||||
|
Module model
|
LR5-72HPH-
550M
|
LR5-72HPH-
555M
|
LR5-72HPH-
560M
|
LR5-72HPH-
565M
|
||||
|
Maximum power (Pmax/W)
|
550
|
555
|
560
|
565
|
||||
|
Open circuit voltage (Voc/V)
|
49.80
|
49.95
|
50.10
|
50.30
|
||||
|
Short circuit current (Isc/A)
|
13.98
|
14.04
|
14.10
|
14.16
|
||||
|
Peak power voltage (Vmp/V)
|
41.95
|
42.10
|
42.25
|
42.42
|
||||
|
Peak power current (Imp/A)
|
13.12
|
13.19
|
13.26
|
13.32
|
||||
|
Module efficiency(%)
|
21.3
|
21.5
|
21.7
|
21.9
|
||||
|
Standard test conditions
|
STC：AM1.5 1000W/m² 25℃
|
|
|
|
||||
|
Packing 1
|
36pcs per pallet / 180pcs per 20'GP / 720pcs per 40'HC
|
|
|
|
||||
|
Packing 2
|
31pcs per pallet / 155pcs per 20'GP / 620pcs per 40'HC
|
|
|
|
||||
|
LONGi Hi-MO
5
LR5-72HBD 540-560M
|
|
|
|
|
||||
|
Module model
|
LR5-72HBD-
545M
|
LR5-72HBD-
550M
|
LR5-72HBD-
555M
|
LR5-72HBD-
560M
|
||||
|
Maximum power (Pmax/W)
|
545
|
550
|
555
|
560
|
||||
|
Open circuit voltage (Voc/V)
|
49.65
|
49.80
|
49.95
|
50.10
|
||||
|
Short circuit current (Isc/A)
|
13.92
|
13.99
|
14.05
|
14.10
|
||||
|
Peak power voltage (Vmp/V)
|
41.80
|
41.95
|
42.10
|
42.25
|
||||
|
Peak power current (Imp/A)
|
13.04
|
13.12
|
13.19
|
13.26
|
||||
|
Module efficiency(%)
|
21.1
|
21.3
|
21.5
|
21.7
|
||||
|
Standard test conditions
|
STC：AM1.5 1000W/m² 25℃
|
|
|
|
||||
|
Packing 1
|
36pcs per pallet / 180pcs per 20'GP / 720pcs per 40'HC
|
|
|
|
||||
|
Packing 2
|
31pcs per pallet / 155pcs per 20'GP / 620pcs per 40'HC
|
|
|
|
||||
Packaging and container loading
Projects cases
Longi Factory Industrial and Commercial Solar Power Station
Industrial and Commercial Solar Power Station 10MW
Household Solar Power Station 30KW
