Quick Details
-
Voltage:
-
380V
-
Power:
-
22KW, 380V/50Hz
-
Dimension(L*W*H):
-
1580mm*1000mm*1250mm
-
Weight:
-
790 kg
-
Model:
-
JADE-900CR
-
Motor:
-
22kW
-
Current:
-
44.3A
-
Inverter:
-
22 kW
-
Gear Box:
-
Planetary Gear
-
Width:
-
850mm
-
Grinder disc:
-
340mm
-
Phases:
-
3ph
-
Operation:
-
Re-control
Quick Details
-
Marketing Type:
-
Hot Product 2023
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JADEITE
-
Voltage:
-
380V
-
Power:
-
22KW, 380V/50Hz
-
Dimension(L*W*H):
-
1580mm*1000mm*1250mm
-
Weight:
-
790 kg
-
Model:
-
JADE-900CR
-
Motor:
-
22kW
-
Current:
-
44.3A
-
Inverter:
-
22 kW
-
Gear Box:
-
Planetary Gear
-
Width:
-
850mm
-
Grinder disc:
-
340mm
-
Phases:
-
3ph
-
Operation:
-
Re-control
Product Paramenters
|
Product Model
|
JADE-900CR
|
|
|
||
|
Power Of Motor
|
22Kw
|
Walking Mode
|
Self-Driven (750w/3000rpm Servo Motor X2)
|
||
|
Rated Voltage/Frequency
|
AC380V/50Hz
|
Walking Reducer
|
High-Strength Three-Stage Gear Reducer
|
||
|
Rated Current
|
44.3A
|
Speed Ratio Of Walking Reducer
|
1:125
|
||
|
Inverter Power
|
22Kw
|
Walking Speed (Max)
|
20m/min
|
||
|
Working Width
|
850mm
|
Work Efficiency (Max)
|
800㎡/h
|
||
|
Gear Box Type
|
Disc
|
Control Mode
|
Remote Control (Waist-Slung Can Bus Control)
|
||
|
Shock Absorption Form
|
Butterfly
|
Applicable Ground
|
Concrete, Natural Stone, Terrazzo Floor, Etc.
|
||
|
Milling Disc Type
|
Circular
|
Function
|
Milling, Roughening, Grinding And Polishing At The Grass-Roots Level
|
||
|
Milling Disc Specification
|
342.5mm
|
Overall Weight
|
790Kg
|
||
|
Number Of Millstones
|
4
|
Power Supply Wiring
|
10㎣
|
||
|
Number Of Grinding Discs
|
3X4/6X4
|
Operating Ambient Temperature
|
-10～40℃
|
||
|
Grinding Motor Speed
|
300～1800r/min
|
Main Body Size (Length X Width X Height, Excluding Handrails)
|
1500X910X1250mm
|
||
|
Water Tank Volume
|
70L
|
Handrail Extension Length
|
1200mm
|
||
|
Dustproof Cooling Mode
|
High-Pressure Atomizing Water Spraying
|
Packing Size
|
100X950X1400mm
|
||
