Advantage
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25 Years, 25 years
-
Brand Name:
-
Anhui Power
-
Model Number:
-
AKY072623
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1724x1134x30mm
-
Product name:
-
Mono Solar Panel 410-435w
-
Solar Cell Material:
-
Monocrystalline cells
-
Bus Bar:
-
12BB
-
Dimension:
-
1724x1134x30mm
-
Module Efficiency:
-
22.3%
-
Open circuit voltage:
-
38.44V
-
Short Circuit Current:
-
14.43A
-
Weight:
-
22.1kg
-
Tolerance:
-
0+3%
-
Certificate:
-
CE/TUV NORD/RoHS/ISO/COC
Quick Details
-
Cell size:
-
182*91mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, HJT, N-TYPE
-
Panel Efficiency:
-
22.3%
-
Warranty:
-
25 Years, 25 years
-
Brand Name:
-
Anhui Power
-
Model Number:
-
AKY072623
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1724x1134x30mm
-
Product name:
-
Mono Solar Panel 410-435w
-
Solar Cell Material:
-
Monocrystalline cells
-
Bus Bar:
-
12BB
-
Dimension:
-
1724x1134x30mm
-
Module Efficiency:
-
22.3%
-
Open circuit voltage:
-
38.44V
-
Short Circuit Current:
-
14.43A
-
Weight:
-
22.1kg
-
Tolerance:
-
0+3%
-
Certificate:
-
CE/TUV NORD/RoHS/ISO/COC
Product Paramenters
|
Photovoltaic Modules
|
|
|
|
|
|
|
||||||
|
Encapsulation
|
Glass/EVA/Cell/EVA/Backsheet
|
|
|
|
|
|
||||||
|
Size and Number of cells
|
166mm*83mm 120/6*20pcs
|
|
|
|
|
|
||||||
|
Maximum Power P
mp
(W)
|
360
|
365
|
370
|
375
|
380
|
|
||||||
|
Maximum Power Voltage V
mp
(W)
|
40.60
|
40.80
|
41.00
|
41.20
|
41.40
|
|
||||||
|
Maximum Power Current I
mp
(A)
|
11.30
|
11.37
|
11.45
|
11.54
|
11.60
|
|
||||||
|
Open-circuit Voltage V
oc
(V)
|
33.52
|
33.72
|
33.92
|
34.12
|
34.32
|
|
||||||
|
Short-circuit Current I
sc
(A)
|
10.75
|
10.83
|
10.92
|
11.00
|
11.08
|
|
||||||
|
Module Efficiency (%)
|
19.76%
|
20.04%
|
20.31%
|
20.59%
|
20.86%
|
|
||||||
|
Tolerance
|
0+3%
|
|
|
|
|
|
||||||
|
Max System Open Circuit Voltage
|
1000/1500V
|
|
|
|
|
|
||||||
|
Max Series Fuse Rating
|
25A
|
|
|
|
|
|
||||||
|
Junction Box (Protection Degree)
|
IP68
|
|
|
|
|
|
||||||
|
Dimension(W'D*L)
|
1755*1038*35mm
|
|
|
|
|
|
||||||
|
Weight
|
20.0 kg
|
|
|
|
|
|
||||||
|
Frame Color
|
Black/Silver
|
|
|
|
|
|
||||||
