KIPOR power diesel engine  12HP air-cooled for sale 188F
KIPOR power diesel engine  12HP air-cooled for sale 188F
KIPOR power diesel engine  12HP air-cooled for sale 188F
KIPOR power diesel engine  12HP air-cooled for sale 188F
KIPOR power diesel engine  12HP air-cooled for sale 188F
KIPOR power diesel engine  12HP air-cooled for sale 188F
KIPOR power diesel engine  12HP air-cooled for sale 188F
KIPOR power diesel engine  12HP air-cooled for sale 188F

KIPOR power diesel engine 12HP air-cooled for sale 188F

FOB Reference Price: Get Latest Price
≥1 Sets
US $220
≥30 Sets
US $200
≥72 Sets
US $180
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Place of Origin:
Jiangsu, China
Brand Name:
KIPOR POWER
Weight:
50
Rated power/speed:
12HP/3000RPM
Marketing Type:
New Product 2024
Engine Model:
188F
Fuel:
Diesel Enigne
Starting system:
Recoil Start+Electric Start
Brand:
KIPOR POWER
Quality:
High-Quality
Cooling System:
Air Colled
Type:
4 Stroke Diesel Engine
After Warranty Service:
Provide 1 Year

Quick Details

Displacement:
456CC, 456cc
Emission Standard:
Other
Power:
12HP
Place of Origin:
Jiangsu, China
Brand Name:
KIPOR POWER
Weight:
50
Rated power/speed:
12HP/3000RPM
Marketing Type:
New Product 2024
Engine Model:
188F
Fuel:
Diesel Enigne
Starting system:
Recoil Start+Electric Start
Brand:
KIPOR POWER
Quality:
High-Quality
Cooling System:
Air Colled
Type:
4 Stroke Diesel Engine
After Warranty Service:
Provide 1 Year
Product Description

KIPOR power diesel engine  12HP air-cooled for sale 188F

The 4-stroke, air cooled, Diesel Engine 188F can be widely used in many application such as the construction site by powering the Road Roller, Tamping Rammer, Scarifying Machine, Concrete Cutter, Power Trowel; And can also be used as the power in diesel  generator, diesel water pumps, diesel power tillers etc.

Model
KP173F(E)
KP178F(E)
KP186FA(E)
KP188F(E)
KP192F(E)
Type
Single cylinder, vertical, 4-stroke, air cooled
Bore*stroke (mm)
73*58
78*62
86*72
88*75
92*75
Displacement (L)
0.243
0.296
0.418
0.456
0.498
Combustion system
Direct injection
Rated output KW (HP) /rpm
3.5(4.8)/3000
3.8(5.2)/3600
3.8(5.1)/3000
4.4(5.9)/3600
5.7(7.8)/3000
6.6(8.9)/3600
6.1(8.2)/3000
7.3(9.8)/3600
7.5(10.2)/3000
8.5(11.5)/3600
Max output KW (HP) /rpm
3.8(5.2)/3000
4.05(5.5)/3600
4.0(5.36)/3000 4.9(6.6)/3600
6.3(8.6)/3000
7.3(9.9)/3600
6.83(9.2)/3000
8.2(11.0)/3600
8.0(10.9)/3000
9.0(12.2)/3600
Direction of rotation
Counterclockwise, facing PTOshaft
Fuel
0# (summer) /-10# (winter)
Fuel tank capacity (L)
2.5
3.5
5.5
5.5
5.5
Lubricating oil capacity (L)
0.75
1.1
1.65
1.65
1.8
Lubricating system
Pressure splashed
Starting system
Manual/Electric start
Packing size (L*W*H) mm
420*380*460
480*460*510
520*455*550
Net weight (KG)
27
35
48
49
50
Packaging & Shipping
FAQ

1  Q: Where is the loading port?

A   SHANGHAI Sea port( our factory located in Shanghai,China)

2 Q: Is it all right to make customer's own brand name?

A: Sure, we can be your OEM manufacturer with your authorization of brand.

3 Q: How long is your warranty?

A: Guarantee for one year or 1000 hours (accord to whichever reach first) from E x- F actory date.

4 Q:What is the deli v ery time?

A: 10 ~ 2 0 days after receiving your deposit according to production line is busy or free
