30A 250V 4Pin 2 Pole KCD4 Heavy Duty Rocker Switch ON OFF DPST 30 Amp Car Bus RV Illuminated Rocker Switch with
30A 250V 4Pin 2 Pole KCD4 Heavy Duty Rocker Switch ON OFF DPST 30 Amp Car Bus RV Illuminated Rocker Switch with
30A 250V 4Pin 2 Pole KCD4 Heavy Duty Rocker Switch ON OFF DPST 30 Amp Car Bus RV Illuminated Rocker Switch with
30A 250V 4Pin 2 Pole KCD4 Heavy Duty Rocker Switch ON OFF DPST 30 Amp Car Bus RV Illuminated Rocker Switch with
30A 250V 4Pin 2 Pole KCD4 Heavy Duty Rocker Switch ON OFF DPST 30 Amp Car Bus RV Illuminated Rocker Switch with
30A 250V 4Pin 2 Pole KCD4 Heavy Duty Rocker Switch ON OFF DPST 30 Amp Car Bus RV Illuminated Rocker Switch with
30A 250V 4Pin 2 Pole KCD4 Heavy Duty Rocker Switch ON OFF DPST 30 Amp Car Bus RV Illuminated Rocker Switch with
30A 250V 4Pin 2 Pole KCD4 Heavy Duty Rocker Switch ON OFF DPST 30 Amp Car Bus RV Illuminated Rocker Switch with

30A 250V 4Pin 2 Pole KCD4 Heavy Duty Rocker Switch ON OFF DPST 30 Amp Car Bus RV Illuminated Rocker Switch with "O I" Mark T125

FOB Reference Price: Get Latest Price
≥100 Pieces
US $0.5
≥500 Pieces
US $0.47
≥1000 Pieces
US $0.43
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Model Number:
KCD2-201N-B
Max. Current:
30A
Mechanical Life:
10000 Cycles
Item Number:
KCD2-201N-B
Button Color:
Transparent Red/Green/Yellow/Blue
Function:
ON-OFF
Contact Configuration:
DPST
Rating:
30A 250VAC
Contact Resistance:
35mΩ max
Insulation Resistance:
500 VDC 100MΩ
Dielectric Strength:
1500VAC 1 minute
Electrical Life:
100,000 cycles
Certification::
CE, CQC, SGS
Certification:
CE, CQC, SGS

Quick Details

Max. Voltage:
250VAC
Place of Origin:
Zhejiang, China
Brand Name:
DAIER
Model Number:
KCD2-201N-B
Max. Current:
30A
Mechanical Life:
10000 Cycles
Item Number:
KCD2-201N-B
Button Color:
Transparent Red/Green/Yellow/Blue
Function:
ON-OFF
Contact Configuration:
DPST
Rating:
30A 250VAC
Contact Resistance:
35mΩ max
Insulation Resistance:
500 VDC 100MΩ
Dielectric Strength:
1500VAC 1 minute
Electrical Life:
100,000 cycles
Certification::
CE, CQC, SGS
Certification:
CE, CQC, SGS
Products Description
Product Name
KCD4 30A 250VAC 4Pin ON OFF Illuminated Heavy Duty Rocker Switches with "O I" Mark
Rating
30A 125VAC
Funtion
ON-OFF Waterproof Lighted 16A 250V Rocker Switch
Material
Nylon 66
Contact Configuration
DPST
Housing Color
Standard black and white
Button Color
Transparent Red/Green/Yellow/Blue
Lamp Volt
3V/12V/24V/110V/220V
OEM or ODM
Available
—— Products Details ——


KCD2(KCD4) Series Rocker Switch

Rating: 30A 125VAC;16A 250VAC

Contact Resistance: 35mΩ max

Insulation Resistance :500VDC 100M Ω min

Dielectric Strength: 1500VAC,1 Minute

Operating Temperature: -25℃~+85 ℃

Electrical Life: >=10000 Cycles

Product function

We have single pass, double pass, single pass spacing ≥ 3mm, double pass ≥ 3mm, double pass without pause, double pass with pause and single pass with reset,c hoose our products you like~

DPST Rocker Switch

It's a DPST 4Pin ON/OFF Rocker Switch, Double Pole Single Throw design, and T85 Temperature Degree(-25C to +85C).

120V Lighted Rocker Switch

The input voltage for the lamp of the switch should be 110V to 250V. The Switch Lamp will light up to indicate the operating status of the device when the switch is turned ON.
Workshop
Yueqing Daier Electric Co., Ltd. was established in 2003,the company covers an area of 2,500 square meters. Daier is a collection of scientific research, production and domestic and international trade company. The company mainly develops, produces and sells Round Rocker Switch and other accessories. The company has more than 200 employees, and has a highly qualified engaged in electronic components and international trade experience decades of research and development, production and sales team. Daier owns a powerful technical staff, advanced production equipment,and perfected quality control system.Most of our products have CE,CQC,TUV.Rohs and UL Certificate. All production, processing and sales are in strict accordance with ISO9001:2015.
30A 250V 4Pin KCD4 Heavy Duty Rocker Switch ON OFF DPST Illuminated Rocker Switch 30 Amp with "O I" Mark
Product Certified
Exhibition
Our team
FAQ
1.Q: Could I put my own logo on the products?
A: Sure, your logo can be put on every product, either by laser, or by moulds.

2.Q: Could I put my own designs of label on the products?
A: Of course, you can send us your design, we'll follow your design.

3.Q: Can I have some samples before formal order?
A: Yes. we can send you some free samples for your test before your order.

4.Q: How long is the lead time?
A: Normally we keep stock for most products, the lead time is 1-5 days as soon as the payment is released.
For customized products, it takes longer.

5.Q: How about the after-sale service? What's the Warranty terms?
A: We offer 12 months for every products we sold. If you meet any problems after sales, pis contact us freely,
we'll help solving the problems within 24 hours.

6.Q: Are you manufacturer or just dealer?
A: We're manufaturer, we do produce all products by ourself. Welcome to visit our plant at any time.

7.Q: What's the payment terms? Can I pay after you got the products?
A: Normally we accept TT and western union. L/C is also accepted if the order quantity is large. For old customers,
we'll guanartee monthly payment after good cooperationship.

8.Q: I couldn't find the products I want in your catalogue, can you develop it for me?
A: Yes. we have a research & development dept.
