Quick Details
-
Max. Loading Capacity:
-
2500L
-
Weight (KG):
-
1000 KG
-
Place of Origin:
-
Jiangsu province
-
Brand Name:
-
YeKeey
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1250*1250*2960mm
-
Power (kW):
-
15 kW
-
Product name:
-
Vacuum Emulsifying Mixer
-
Usage:
-
Chemical Industry
-
Raw material:
-
SS304/SS316
-
Application scope:
-
High Viscosity Product
-
Stirrer type:
-
Scraper
-
Function:
-
Emulsification
-
Machine Type:
-
Dispersing disc
-
Capacity:
-
500L-20000L
-
Packing:
-
Wooden Case Packing
-
Keyword:
-
Vacuum Emulsifying Mixer
Quick Details
-
Barrel Volume (L):
-
2500
-
Max. Loading Volume (L):
-
2500 L
-
Range of Spindle Speed(r.p.m):
-
1 - 2800 r.p.m
-
Max. Loading Capacity:
-
2500L
-
Weight (KG):
-
1000 KG
-
Place of Origin:
-
Jiangsu province
-
Brand Name:
-
YeKeey
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1250*1250*2960mm
-
Power (kW):
-
15 kW
-
Product name:
-
Vacuum Emulsifying Mixer
-
Usage:
-
Chemical Industry
-
Raw material:
-
SS304/SS316
-
Application scope:
-
High Viscosity Product
-
Stirrer type:
-
Scraper
-
Function:
-
Emulsification
-
Machine Type:
-
Dispersing disc
-
Capacity:
-
500L-20000L
-
Packing:
-
Wooden Case Packing
-
Keyword:
-
Vacuum Emulsifying Mixer
SPA-2500 Vacuum Emulsifying Mixer With External Circulation Emulsifier
Product Description
- The vacuum emulsifying mixer with external circulation can be divided into 2 classifications SPA & SPC. SPC is the sole equipment with jacking system with SPA more suitable for engineering installation.
- The equipmet is equipped with an internal/external circulation high shear homogenizer, featuring bottom-mounted.
- The emulsifying tank comes with a two-way stirring paddle with a scraped wall as per the standards.
- Regarding the emulsifying effect, it can be the same as ZJR Series of multi-functional vacuum emulsifying machine & Laboratory emulsifying machine.
Essential Adavantage
- SS316 is optional.
- Various kinds of operation modes are optional.
- Easy to clean & maintain for the internal structure.
- Available to choose to mount CIP cleaning system.
- It is simple, reliable and cost-effective in equipment structure.
- Other functions can be customized as well.
Technology Parameter
| Model # | Design Vol. | Max. working Vol. | Min. Working Vol. | Dimens(L*W*H) |
| SPA-650 | 650L | 110L | 520L | 1250*1250*2960MM |
| SPA-1300 | 1300L | 200L | 1000L | 1500*1500*3610MM |
| SPA-2000 | 2000L | 350L | 1500L | 1720*1720*3940MM |
| SPA-3000 | 3000L | 500L | 2500L | 1970*1970*4570MM |
| SPA-4000 | 4000L | 650L | 3000L | 2150*2150*4700MM |
| SPA-5000 | 5000L | 800L | 4000L | 2270*2270*5000MM |
| SPA-6000 | 6000L | 1000L | 5000L | 2270*2270*5220MM |
