Quick Details
-
Warranty:
-
1year
-
Brand Name:
-
Sunniest Solar
-
Model Number:
-
SUNFD-500W
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2583*1292*1mm
-
CIGS Flexible Panel Power:
-
500W
-
Operating voltage (Vmp):
-
62.4V
-
Operating current (Imp):
-
8.03A
-
Open circuit voltage (Voc):
-
77.2V
-
Short circuit current (Isc):
-
9.07A
-
Solar cells:
-
224 CIGS cells
-
Cell type:
-
CIGS
-
Junction box:
-
IP67
Quick Details
-
Cell size:
-
125mmx125mm
-
Type:
-
BIPV, Flexible
-
Panel Efficiency:
-
16.8%
-
Warranty:
-
1year
-
Brand Name:
-
Sunniest Solar
-
Model Number:
-
SUNFD-500W
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2583*1292*1mm
-
CIGS Flexible Panel Power:
-
500W
-
Operating voltage (Vmp):
-
62.4V
-
Operating current (Imp):
-
8.03A
-
Open circuit voltage (Voc):
-
77.2V
-
Short circuit current (Isc):
-
9.07A
-
Solar cells:
-
224 CIGS cells
-
Cell type:
-
CIGS
-
Junction box:
-
IP67
Detail Images
Products Description
Product Paramenters
|
Size (LxMxH mm)
|
Power (W)
|
Voc (V)
|
Isc (A)
|
Vmp (V)
|
Imp (A)
|
Without Adhesive Weight (kg)
|
With Adhesive Weight (kg)
|
|||
|
1709x348x20
|
60W
|
Customization Needed Under 75W
|
|
|
|
1.2kg
|
1.8kg
|
|||
|
|
75W
|
23.30
|
4.07
|
18.30
|
4.09
|
1.2kg
|
1.8kg
|
|||
|
|
80W
|
23.80
|
4.74
|
18.80
|
4.26
|
|
|
|||
|
2583x348x20
|
110W
|
35.40
|
4.66
|
27.80
|
3.96
|
1.9kg
|
2.8kg
|
|||
|
|
115W
|
36.00
|
4.69
|
28.30
|
4.06
|
|
|
|||
|
|
120W
|
36.50
|
4.71
|
28.80
|
4.16
|
|
|
|||
|
|
125W
|
37.00
|
4.75
|
29.30
|
4.27
|
|
|
|||
|
1709x973x20
|
210W
|
22.70
|
13.90
|
17.50
|
11.99
|
2.9kg
|
4.0kg
|
|||
|
|
220W
|
23.30
|
13.95
|
18.20
|
12.12
|
|
|
|||
|
|
230W
|
24.20
|
14.04
|
18.80
|
12.25
|
|
|
|||
|
|
240W
|
24.20
|
14.04
|
19.40
|
12.38
|
|
|
|||
|
|
250W
|
24.70
|
14.08
|
20.00
|
12.52
|
|
|
|||
|
1709x1292x20
|
280W
|
47.30
|
8.91
|
38.10
|
7.35
|
3.7kg
|
4.9kg
|
|||
|
|
290W
|
48.00
|
9.01
|
38.30
|
7.57
|
|
|
|||
|
|
300W
|
48.10
|
9.10
|
38.40
|
7.81
|
|
|
|||
|
|
310W
|
48.20
|
9.21
|
38.50
|
8.04
|
|
|
|||
|
|
320W
|
48.30
|
9.34
|
38.60
|
8.29
|
|
|
|||
|
2583x973x20
|
340W
|
37.00
|
13.70
|
29.30
|
11.53
|
4.3kg
|
5.9kg
|
|||
|
|
350W
|
37.20
|
13.78
|
29.6
|
11.83
|
|
|
|||
|
|
360W
|
37.30
|
13.88
|
29.80
|
12.07
|
|
|
|||
|
|
370W
|
37.60
|
13.98
|
30.10
|
12.31
|
|
|
|||
|
|
380W
|
37.60
|
14.10
|
30.30
|
12.55
|
|
|
|||
|
|
390W
|
37.80
|
14.31
|
30.50
|
12.80
|
|
|
|||
|
2583x1292x20
|
440W
|
74.60
|
8.84
|
59.40
|
7.41
|
5.7kg
|
7.5kg
|
|||
|
|
460W
|
74.80
|
9.09
|
59.60
|
7.72
|
|
|
|||
|
|
480W
|
74.90
|
9.20
|
59.90
|
8.02
|
|
|
|||
|
|
490W
|
75.00
|
9.25
|
60.00
|
8.16
|
|
|
|||
|
|
500W
|
75.10
|
9.32
|
60.20
|
8.31
|
|
|
|||
|
|
510W
|
75.20
|
9.42
|
60.20
|
8.47
|
|
|
|||
