Quick Details
-
Brand Name:
-
Huajing
-
Material:
-
ABS fire retardant/non-retardant
-
Color:
-
white
-
Size(mm):
-
160*48*16
-
Function:
-
FTTH
-
Feature:
-
Small&light
-
Usage:
-
indoor
-
Weight(g):
-
35.5
Quick Details
-
Type:
-
Fast Connector
-
Model Number:
-
Adapter type
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
Huajing
-
Material:
-
ABS fire retardant/non-retardant
-
Color:
-
white
-
Size(mm):
-
160*48*16
-
Function:
-
FTTH
-
Feature:
-
Small&light
-
Usage:
-
indoor
-
Weight(g):
-
35.5
Product Paramenters
Description:
After splicing, the butterfly drop cable with shrinkable protection tube is placed in the box, which enables the splice to be
better protected. compared with that in the cold products, it can improve the optical performance of the connector, so as to
enable the effective connection rate up to 100%, prolong its service life, lower the maintenance costs.
Features:
1.The built-in fiber splice in heat shrinkable sleeve greatly improves the reliability of the product.
2.With the entire visual place, the pass rate for the splicing is 100%, which saves the construction time.
3.The cable splice can achieve high optical performance, an average insertion loss rate≤0.03 dB, return loss rated ≥ 60 dB.
4.The product is not affected by the environment during usage, n failure rate, long service life, lower late maintenance cost.
5.Special optical fiber tail intensifies structure makes the cable tensile resistance > 60 N.
6.With simple and quick operation, operators doesn't need professional skills
|
Specification:
|
|
|
|
Model No.
|
Adapter type
|
|
|
Dimension (mm): L*W*H
|
160*48*16
|
|
|
Weight（g）
|
35.5
|
|
|
Connection type
|
Adapter
|
|
|
Cable diameter
|
Φ 3mm or Drop cable(2*3mm)
|
|
|
Adapter type
|
SC simplex (1pc)
|
|
