Quick Details
-
Place of Origin:
-
Shandong, China
-
Machine Weight:
-
900 kg
-
Drive type:
-
Tracked
-
After-sales Service Provided:
-
After-sales Service
-
Color:
-
Customer's Requiement
Quick Details
-
Engine Brand:
-
Briggs/ Rato/ Yanmar
-
Power:
-
17.2 kw, 10 KW
-
Brand Name:
-
youtop
-
Place of Origin:
-
Shandong, China
-
Machine Weight:
-
900 kg
-
Drive type:
-
Tracked
-
After-sales Service Provided:
-
After-sales Service
-
Color:
-
Customer's Requiement
WHY CHOOSE US
1.
20 years of production
, export and sales experience
2. Two factories covering an area of
100,000 square meters
and
200 employees
3. Passed
ISO, CE
and other certifications
4. The machine uses
imported hydraulic accessories
to make it more durable.
|
ITEMS
|
SPECIFICATIONS
|
ITEMS
|
SPECIFICATIONS
|
|
Engine Brand
|
KOOP/BRIGGS/RATO
|
Height at Maximum Extension/mm
|
2450
|
|
Rated Power/HP
|
12-13.5HP
|
Height To the the bucket pin /mm
|
1870
|
|
Rated Speed/rpm
|
3000
|
Vehicle height
|
1300
|
|
Number of cylinders
|
1
|
Maximum Height as Lay the bucket flat/mm
|
1810
|
|
Air intake way
|
Naturally Aspirated
|
Total length without appendages/mm
|
1450
|
|
Displacement/cc
|
420
|
Length With standard bucket /mm
|
2100
|
|
Emissions Standards
|
EUR 5-EPA
|
Maximum height unloading Angle
|
34°
|
|
Rated Operating Capacity/Kg
|
200
|
Dumping Height/mm
|
1510
|
|
Maximum Operating Capacity/Kg
|
300
|
Discharge Distance/mm
|
450
|
|
Maximum Breakout Force/KN
|
3.5
|
The flip Angle of the bucket on the ground
|
27°
|
|
Bucket Capacity/m3
|
0.12
|
Bucket flip Angle at highest Pos.
|
114°
|
|
Driving Speed/ km/h
|
0-6
|
Wheel Base/mm
|
850
|
|
Total Cycling Time/s
|
9
|
Ground Clearance/mm
|
150
|
|
System Operating Pressure /bar
|
17-21
|
Tail Length/mm
|
280
|
|
Fuel Tank Capcity/L
|
5
|
Wheel base
(standard tire) /mm |
720
|
|
Operating Weight/Kg
|
900
|
Vehicle width
(standard tire) /mm |
880
|
|
Track
|
|
Bucket width/mm
|
1000
|
|
Machine Rating
|
|
Dimensions
|
|
||
|
ITEMS
|
SPECIFICATIONS
|
ITEMS
|
SPECIFICATIONS
|
||
|
Engine Brand
|
BRIGGS/RATO/KOOP
|
Height at Maximum Extension/mm
|
2450
|
||
|
Rated Power/HP
|
23HP
|
Height To the the bucket pin /mm
|
1870
|
||
|
Rated Speed/rpm
|
3600
|
Vehicle height
|
1350
|
||
|
Number of cylinders
|
2
|
Maximum Height as Lay the bucket flat/mm
|
1810
|
||
|
Air intake way
|
Naturally Aspirated
|
Total length without appendages/mm
|
1680
|
||
|
Displacement/cc
|
639
|
Length With standard bucket /mm
|
2206
|
||
|
Emissions Standards
|
EUR 5-EPA
|
Maximum height unloading Angle
|
34
|
||
|
Rated Operating Capacity/Kg
|
300
|
Dumping Height/mm
|
1510
|
||
|
Maximum Operating Capacity/Kg
|
400
|
Discharge Distance/mm
|
450
|
||
|
Maximum Breakout Force/KN
|
450
|
The flip Angle of the bucket on the ground
|
27
|
||
|
Bucket Capacity/m3
|
0.12
|
Bucket flip Angle at highest Pos.
|
114
|
||
|
Driving Speed/ km/h
|
0-6
|
Wheel Base/mm
|
850
|
||
|
Total Cycling Time/s
|
9
|
Ground Clearance/mm
|
150
|
||
|
System Operating Pressure /bar
|
17-21
|
Tail Length/mm
|
280
|
||
|
Fuel Tank Capcity/L
|
10
|
Wheel base
(standard tire) /mm |
720
|
||
|
Operating Weight/Kg
|
1000
|
Vehicle width
(standard tire) /mm |
1000
|
||
|
Track
|
|
Bucket width/mm
|
1000
|
||
|
Machine Rating
|
|
Dimensions
|
|
||
|
ITEMS
|
SPECIFICATIONS
|
ITEMS
|
SPECIFICATIONS
|
||
|
Engine Brand
|
Yanmar380
|
Height at Maximum Extension/mm
|
2450
|
||
|
Rated Power/HP
|
25HP
|
Height To the the bucket pin /mm
|
1870
|
||
|
Rated Speed/rpm
|
3000
|
Vehicle height
|
1330
|
||
|
Number of cylinders
|
3
|
Maximum Height as Lay the bucket flat/mm
|
1810
|
||
|
Air intake way
|
Naturally Aspirated
|
Total length without appendages/mm
|
1680
|
||
|
Displacement/cc
|
639
|
Length With standard bucket /mm
|
2206
|
||
|
Emissions Standards
|
EPA
|
Maximum height unloading Angle
|
34°
|
||
|
Rated Operating Capacity/Kg
|
350
|
Dumping Height/mm
|
1510
|
||
|
Maximum Operating Capacity/Kg
|
480
|
Discharge Distance/mm
|
450
|
||
|
Maximum Breakout Force/KN
|
550
|
The flip Angle of the bucket on the ground
|
27°
|
||
|
Bucket Capacity/m3
|
0.12
|
Bucket flip Angle at highest Pos.
|
114°
|
||
|
Driving Speed/ km/h
|
0-6
|
Wheel Base/mm
|
850
|
||
|
Total Cycling Time/s
|
9
|
Ground Clearance/mm
|
150
|
||
|
System Operating Pressure /bar
|
17-21
|
Tail Length/mm
|
280
|
||
|
Fuel Tank Capcity/L
|
13
|
Wheel base
(standard tire) /mm |
720
|
||
|
Operating Weight/Kg
|
1000
|
Vehicle width
(standard tire) /mm |
1000
|
||
|
Track
|
|
Bucket width/mm
|
1000
|
||
|
Engine
|
Engine model
|
Yanmar380
|
|
|
No. of cylinders
|
3 cylinder
|
|
|
Net Power
|
17.8kw
|
|
Dimensions
|
Operating height
|
2900mm
|
|
|
Height to bucket hinge pin
|
2160mm
|
|
|
Height to top
|
1540mm
|
|
|
Overall length with GP bucket
|
2700mm
|
|
|
Overall length without bucket
|
2100mm
|
|
|
Wheelbase
|
1180mm
|
|
|
Overall width
|
980mm
|
|
|
Mini ground clearance
|
130mm
|
|
|
Angle of departure
|
23°
|
|
|
Rated loading capacity
|
400kgs
|
|
|
Machine weight
|
1200kgs
|
|
Hydraulic system
|
working system pressure
|
250 bar
|
|
|
working system Flow rate
|
62.4 L/min
|
|
|
Driving System pressure
|
250 bar
|
|
|
Driving system Flow rate
|
62.4 L/min
|
|
|
Working pressure
|
18mpa
|
|
|
Fuel tank
|
30L
|
|
|
Walking speed
|
3km/h
|
