Quick Details
-
Brand Name:
-
YOUYOU
-
Model Number:
-
DN50
Quick Details
-
Warranty:
-
3 years
-
Type:
-
Multi-jet meters, Compound meters, Turbine meters, Electromagnetic meters, Ultrasonic meters, Prepaid water meters
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
YOUYOU
-
Model Number:
-
DN50
· Type: Dry dail, Detachable, Horizontal
· Standard: ISO4064(R100)
· Water Pressure: 1.0Mpa(1.6Mpa oc request)
· Register may be rotated through 360°
· Magnet-drive, dry dial, protected by the steel cover
· Large number rollers on the dry dial counter ensure the readability of the numbers at all times.
- Removable mechanism is easy to replace or fix and not required detaching the body from the pipeline
- Pulse emitter can be installed to this type for remote reading(option)
Maximum Permissible Error
a) In the lower zone: Q1≤Q≤Q2 is ±5%
b) In the upper zone: Q2≤Q≤Q4 is ±2%
| Type | LXLC-50B | |
| Size | 50MM | |
| 2" | ||
| Class of measurement | Q3/Q1 |
R100
6.3 |
| Q2/Q1 | ||
| Commonly used flow | (Q3)m³/h |
25 |
| Min reading | m³ |
0.01 |
| Max reading |
99999999 |
|
| Length | mm |
200 |
| Width |
185 |
|
| Height |
250 |
|
Related products:
| Type | Size | Class of measurement | Commonly used flow | Min reading | Max reading | Length | Width | Height | ||
| Q3/Q1 | Q2/Q1 | (Q3)m³/h | m³ | mm | ||||||
| LXLC-250B | 250MM | 12' | R50 | 6.3 | 630 | 0.01 | 99,999,999 | 450 | 470 | 660 |
| LXLC-350B | 350MM | 14" | 1400 | 0.1 | 999,999,999 | 500 | 590 | 750 | ||
| LXLC-400B | 400MM | 16" | 1600 | 0.1 | 999,999,999 | 600 | 631 | 750 | ||
| LXLC-500B | 500MM | 20" | 2500 | 0.1 | 999,999,999 | 800 | 740 | 840 | ||
| LXLC-600B | 600MM | 24" | 4000 | 0.1 | 999,999,999 | 500 | 780 | 900 | ||
