Quick Details
-
Weight (KG):
-
350
-
Voltage:
-
220V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Soonpack
-
Dimension(L*W*H):
-
850*1100*1900mm
-
Product name:
-
Flow packing machine
-
Keyword:
-
Pillow Packaging Machine
-
Sealing Type:
-
Back Sealing/3 Side/4
-
Speed:
-
30-250bags/min
-
Usage:
-
Food packing
-
Packing material:
-
POF PVC PP PE
-
Advantage:
-
Easy Operation
Quick Details
-
Function:
-
FILLING, Wrapping, Sealing
-
Packaging Type:
-
Bags
-
Packaging Material:
-
Plastic, Paper
-
Weight (KG):
-
350
-
Voltage:
-
220V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Soonpack
-
Dimension(L*W*H):
-
850*1100*1900mm
-
Product name:
-
Flow packing machine
-
Keyword:
-
Pillow Packaging Machine
-
Sealing Type:
-
Back Sealing/3 Side/4
-
Speed:
-
30-250bags/min
-
Usage:
-
Food packing
-
Packing material:
-
POF PVC PP PE
-
Advantage:
-
Easy Operation
Details Images
This machine suitable for baking food, candy, daily necessities,hardware parts, paper box or tray and other solid objects with regular size.
1. Food: noodles, egg rolls, sausages, squid, bread, moon cakes,preserved fruit, soft candy, etc.
2. chemical categories: soap, tape, etc.
3. electrical switch: plug board, switch, etc.
4. Other categories: pocket notepad, boxed pen, etc.
2. chemical categories: soap, tape, etc.
3. electrical switch: plug board, switch, etc.
4. Other categories: pocket notepad, boxed pen, etc.
|
Machine Model
|
SP-100
|
SP-300
|
SP-80X
|
SP-280X
|
|
Bag Size
|
L：100-500mm
|
L：60-300mm
|
L：90-450mm
|
L：120-500mm
|
|
|
W：35-140mm
|
W：35-160mm
|
W：35-200mm
|
W：35-250mm
|
|
|
W：5-60mm
|
W：5-60mm
|
W：5-80mm
|
W：5-80mm
|
|
Packaging Speed
|
30~160bags/min
|
30~150bags/min
|
30~100bags/min
|
25~120bags/min
|
|
Film Width
|
Max.400mm
|
Max.400mm
|
Max.500mm
|
Max.600mm
|
|
Machine Weight
|
350KG
|
350KG
|
750KG
|
560KG
|
Control System
The flow packing machine incorporates a control system, which manages and coordinates the different components of the machine. It ensures synchronization between the feeding system, film unwind mechanism, sealing mechanism, cutting mechanism, and other functions. The control system allows for precise adjustments and settings to achieve desired packaging outcomes.
Feeding System
This component of the machine is responsible for delivering the products to be packaged. It can involve a conveyor belt, an indexing system, or other mechanisms to move the products into the packaging area.
Film Unwind Mechanism
The flow packing machine uses a continuous roll of packaging film, which is unwound and fed into the machine. This mechanism ensures a steady supply of film for the packaging process.
Forming Tube or Plate
The packaging material is shaped into a tube using a forming tube or plate. The tube is formed around the product or group of products and will enclose them completely.
Sealing Mechanism
he sealing mechanism is responsible for sealing the edges of the packaging material together to create individual packages. It typically uses heat or pressure to create a secure seal.
Cutting Mechanism
Once the sealing process is complete, the cutting mechanism separates the continuous flow of packages into individual units. This can be achieved through various methods such as rotary blades, reciprocating blades, or hot wire cutting.
FAQ
Q1:Do you have manual or operation video for us to know more about the machine?
A1:Yes, not only manual or operation video, 3D drawing also available to make as per your design,also the video we can make of testing the material from our packaging machine if your packing goods easier for us to find from our local market.
Q2:How can I trust you for the first time business ?
A2:Please note our above business license and certificate. And if you don't trust us, then we can use Alibaba trade assurance service, guarantee your money, and guarantee your machine's on-time delivery and machine quality.
Q3:Is engineer available to serve oversea?
A3:Yes, but the travel fee is paid by you. So actually to save your cost, we will send you a video of full details machine installation and assist you till the end.
Q4:How can we make sure about the machine quality after we put the order?
A4:Before delivery, we will send you the pictures and videos for you to check the quality, and also you can arrange for quality checking by yourself or by your contacts in China.
Q5:Will you provides the door to door service?
A5:Yes. Please offer us your final destination, we will check with our agent to see if it available, and most of the area is ok for us to clearing and sending in your countries.
A1:Yes, not only manual or operation video, 3D drawing also available to make as per your design,also the video we can make of testing the material from our packaging machine if your packing goods easier for us to find from our local market.
Q2:How can I trust you for the first time business ?
A2:Please note our above business license and certificate. And if you don't trust us, then we can use Alibaba trade assurance service, guarantee your money, and guarantee your machine's on-time delivery and machine quality.
Q3:Is engineer available to serve oversea?
A3:Yes, but the travel fee is paid by you. So actually to save your cost, we will send you a video of full details machine installation and assist you till the end.
Q4:How can we make sure about the machine quality after we put the order?
A4:Before delivery, we will send you the pictures and videos for you to check the quality, and also you can arrange for quality checking by yourself or by your contacts in China.
Q5:Will you provides the door to door service?
A5:Yes. Please offer us your final destination, we will check with our agent to see if it available, and most of the area is ok for us to clearing and sending in your countries.
