Aluminum evaporator is of 3 times higher heat exchange efficiency than other steel [SUS304, galvanized steel], so ice block can be completely frozen faster. In this way, it can produce more ice blocks with lower power consumption.
- Product Details
- {{item.text}}
Quick Details
-
Ice storage capacity:
-
Other
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KOLLER
-
Dimension(L*W*H):
-
5880mm x 1700mm x 2380mm
-
Weight:
-
3500 KG
-
Warranty:
-
12months
-
ice shape:
-
block ice
-
ice size:
-
25kg, 123mm x 350mm x 710mm
-
the freezing time:
-
6Hours for 25kg ice block
-
ice maker:
-
aluminum plate
-
Refrigerant:
-
R404a/R507/R449
-
electrical components:
-
LG/LS
-
control system:
-
HP/LP switch with automatic reset
-
refrigeration components:
-
Danfoss /Castel
-
wildly use:
-
ice plant, hotel, restaurant, bar and so on
-
cooling way:
-
water/air-cooling
Quick Details
-
Ice Shape:
-
ICE BLOCK
-
Voltage:
-
380V~440V,50HZ,3P/220V,60HZ,3P
-
Power:
-
18.5KW
-
Ice storage capacity:
-
Other
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KOLLER
-
Dimension(L*W*H):
-
5880mm x 1700mm x 2380mm
-
Weight:
-
3500 KG
-
Warranty:
-
12months
-
ice shape:
-
block ice
-
ice size:
-
25kg, 123mm x 350mm x 710mm
-
the freezing time:
-
6Hours for 25kg ice block
-
ice maker:
-
aluminum plate
-
Refrigerant:
-
R404a/R507/R449
-
electrical components:
-
LG/LS
-
control system:
-
HP/LP switch with automatic reset
-
refrigeration components:
-
Danfoss /Castel
-
wildly use:
-
ice plant, hotel, restaurant, bar and so on
-
cooling way:
-
water/air-cooling
Product Information
CE Approved 5 tons Ice Maker Machine Directly Cooling Aluminum Plate Ice Block Making Machine Chinese Factory Price
Model: DK50
Capacity: 5tons/day
Ice shape: block ice
Ice size: 50kg/piece
Ice dimension:
163mm*405mm*920mm
Ice freezing time: 12 hours per batch
Ice freezing time: 12 hours per batch
3. Models and technical parameters:
Daily capacity from 500 kg to 3 tons.
|
Model
Item |
|
DK04
|
DK05
|
DK10
|
DK20
|
DK30
|
|||||
|
Capacity (Ton/24hrs)
|
|
0.4
|
0.5
|
1
|
2
|
3
|
|||||
|
Compressor Brand
|
|
Copeland
|
Copeland
|
Copeland
|
Copeland/Bit zer/Refcomp
|
Bit zer/Refcomp
|
|||||
|
Compressor Power (kw)
|
|
3
|
4
|
6
|
10 (9)
|
18 (14)
|
|||||
|
Refrigerant
|
|
R22/R404A/R507
|
|
|
|
|
|||||
|
Ice Size
|
|
3kg/5kg
|
3kg/5kg
|
5kg/10kg
|
5kg/10kg
|
10kg/25kg
|
|||||
|
Dimension
(mm) |
Length
|
1250
|
1250
|
3080
|
3780
|
4780
|
|||||
|
|
Width
|
1050
|
1050
|
1100
|
1120
|
1140
|
|||||
|
|
Height
|
1620
|
1620
|
1780
|
1950
|
1950
|
|||||
|
Cooling Way
|
|
Air Cooling
|
|
|
|
|
|||||
|
Ice Harvest Way
|
|
Automatic
|
|
Manual Forklift
|
|
|
|||||
Daily capacity from 5 tons to 30 tons
|
Model
Item |
|
DK50
|
DK80
|
DK100
|
DK150
|
DK200
|
DK300
|
||||||
|
Capacity (Ton/24hrs)
|
|
5
|
8
|
10
|
15
|
20
|
30
|
||||||
|
Compressor Brand
|
|
Bit zer/Refcomp
|
Bit zer/Refcomp
|
Bit zer/Refcomp
|
Bit zer/Refcomp
|
Bit zer/Refcomp
|
Bit zer/Refcomp
|
||||||
|
Compressor Power (kw)
|
|
34 (28)
|
68 (56)
|
68 (56)
|
88 (68)
|
132 (102)
|
146
|
||||||
|
Refrigerant
|
|
R22/R404A/R507
|
|
|
|
|
|
||||||
|
Ice Size
|
|
10kg/25kg
|
10kg/25kg
|
25kg/30kg/50kg
|
25kg/30kg/50kg
|
25kg/30kg/50kg
|
25kg/50kg
|
||||||
|
Dimension
(mm) |
Length
|
5200
|
7500
|
8600
|
10890
|
11800
|
15500
|
||||||
|
|
Width
|
1700
|
2300
|
2500
|
2300
|
2200
|
3000
|
||||||
|
|
Height
|
2100
|
2500
|
2500
|
2500
|
2500
|
2700
|
||||||
|
Cooling Way
|
|
Air/Water Cooling
|
Water Cooling
|
Water Cooling
|
Water Cooling
|
Water Cooling
|
Water Cooling
|
||||||
|
Ice Harvest Way
|
|
Manual Forklift
|
Manual Forklift
|
Manual Forklift
|
Auto Rise/Fall
|
Auto Rise/Fall
|
Auto Rise/Fall
|
||||||
Ice size for choice. It also can be customized according to your need.
|
Ice Size/pc
|
Ice Dimension (mm)
(Thickness*Width*Height) |
Freezing Time
(Hours) |
Ice Making
Frequency (Times) |
|
5KG
|
95*130*500
|
3
|
7
|
|
10KG
|
95*260*500
|
3
|
7
|
|
15KG
|
123*300*500
|
6
|
4
|
|
|
123*215*710
|
6
|
4
|
|
20KG
|
123*285*710
|
6
|
4
|
|
25KG
|
123*350*710
|
6
|
4
|
|
|
155*280*710
|
8
|
3
|
|
30KG
|
155*335*710
|
8
|
3
|
About The Details
Faster Ice Making and Lower Power Consumption
Clean ice Block and Eco-friendly
Koller direct cooling ice block machine can make ice block directly without brine or any other material, so it can produce clean ice blocks even for human consumption. Also it won't produce any pollution to the environment.
Longer service life
Without salt or other material's corrosion, Koller direct cooling ice block machine can have longer service life and you need just clean the ice moulds regularly. The future maintenance investment is lower.
Less Space Requirement
For Koller direct cooling ice block machine is integrated design, it takes less space than the brine type ice block machine for the same capacity.
Labor saving
Equipped with Siemens PLC system, Koller direct cooling ice block machine only only your labor cost to add the water and take the ice blocks out, all other process is automatically finished.
