Quick Details
-
Model Number:
-
LP064-1700-F(18650)
-
OEM/ODM:
-
Accepted
-
Capacity:
-
1700mAh
Quick Details
-
Anode Material:
-
LFP
-
Application:
-
Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
QUAWIN/OEM
-
Model Number:
-
LP064-1700-F(18650)
-
OEM/ODM:
-
Accepted
-
Capacity:
-
1700mAh
Quick Detail:
Brand Name:QUAWIN/OEM
Model Number:LP064-1700-F(18650)
Type:LiFePO4 battery
Place of Origin:Guangdong China (Mainland)
Composed Type:2S1P
Nominal Voltage:6.4V
Nominal Capacity:1700mAh
Maximal Charging Current:3A(Adjust)
BMS:
PCM-L02S02-F64
Output interface:P+ / P- / SC / SD
Constant Discharge Current:3A(Adjust)
Over Charger Protection Voltage(V):7.3V±0.1V
Over Discharge Protection Voltage(V):4V
Cell:domestic 1700mAh Battery
Certificate:CE,ROHS,UN38.3 REACH
Pack:Black PVC Shrink tube
Size:38(T) x 19(W) x 73(H)mm
Weight:90±5g
Charging temperature(ºC):0ºC~45ºC;32oF~113oF
Discharging temperature(ºC):-20ºC~60ºC;-4oF~149oF
Storage temperature(ºC):-20ºC~45ºC;-4oF~113oF
Protection Temperature(ºC):70ºC±5ºC
Cycle life:2000~3000 times
Warranty:12 months
Packaging & Delivery :
.
Netural labels,Polybag,PVC,Color box,Customised package
.
Netrual packing/Cartoon box with less than 10KGS
.
Delivery Detail:sample within 7 work days,20~
30
days for bulk order
| Recommended C harger: | QW064-005-F |
| C harger input: | 100V~240VAC 50-60Hz |
| C harging mode: | constant voltage constant current (CC/CV) |
| C harging voltage: | 7.3V±0.2V |
| C harging current: | 0.5±0.1A |
| C harging time: | 3-4 hrs(standard) |
| C harger working instruction: | Be in charging the red light,be full of charging the green light; |
1). Green product
2). Long standby time
3). One year warranty
4). Excellent safety performance
5). Excellent storage performance and low self-discharge rate
6). Short circuit testing passed
7). Overcharge testing passed
8). Over discharge testing passed
9). 150 ºC thermal shock test passed
10).1.2m drop testing passed
Spotlight:
1).Provide both single cells and battery packs
2).100% inspection before delivery
3).Inspects inner resistance,discharge platform and self-discharge
4). manufacturer of 18650 lifepo4 battery etc.
5).tablished quality control systems under ISO9001
6).Customized packs, tags,labels,plugs,connectors,over current protection, temperature contol protection are available
Shipping terms:
1).Samples checking: sending by Express ( DHL/UPS/FEDEX/TNT,by air)
2).Bulk production: sending out by cargo shipping / air freight / Express(DHL/UPS/FedEx/TNT),or we can accept other shipping terms according to your requirements.
3).We are not responsible for any accidents, delays or other issues that are caused by the shipping.
Safety Precaution:
1).Do not throw battery into water or make it wet;
2).Keep the battery away from heat source(like fire or heater);
3).Do not throw the battery into fire or heat the battery;
4).Forbid to hammer to trample the battery;
5).Forbid disassembling the battery in anyway
Call us to know more details datasheet.
