•10C/20C High discharge
•Over 25,000 duty cycles
•Ultra-low internal resistance
•Support -50~+60°C working
•Ultra-high-power performance
•More safe than Lifepo4 battery
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
66160
-
Battery Size:
-
2.3V 30/35/40Ah/45Ah
-
Place of Origin:
-
GUA
-
Weight:
-
1.25kg
-
The charging ratio:
-
1-10C
-
The discharge rate:
-
10/20c
-
Product name:
-
66160 Yinlong LTO Cells
-
Voltage:
-
2.3V
-
Capacity:
-
30Ah/35Ah/40Ah
-
Type:
-
Lto Lithium Titanate Battery
-
Features:
-
Long cyclelife/High Rate Capability/Safety
-
Cycle life:
-
30000 times
-
Keywords:
-
yinlong lto,yinglong lto battery,yinlong 35ah,yinlong 40ah
-
Warranty:
-
10 Years
-
Stock:
-
100000pcs in stock
Quick Details
-
Anode Material:
-
LTO
-
Application:
-
Power Tools, Home Appliances, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
Yinlong
-
Model Number:
-
66160
-
Battery Size:
-
2.3V 30/35/40Ah/45Ah
-
Place of Origin:
-
GUA
-
Weight:
-
1.25kg
-
The charging ratio:
-
1-10C
-
The discharge rate:
-
10/20c
-
Product name:
-
66160 Yinlong LTO Cells
-
Voltage:
-
2.3V
-
Capacity:
-
30Ah/35Ah/40Ah
-
Type:
-
Lto Lithium Titanate Battery
-
Features:
-
Long cyclelife/High Rate Capability/Safety
-
Cycle life:
-
30000 times
-
Keywords:
-
yinlong lto,yinglong lto battery,yinlong 35ah,yinlong 40ah
-
Warranty:
-
10 Years
-
Stock:
-
100000pcs in stock
Product Description
•10C/20C High discharge
•Over 25,000 duty cycles
•Ultra-low internal resistance
•Support -50~+60°C working
•Ultra-high-power performance
Specification
|
Item/Model
|
Yinlong 2.3V 30Ah lithium Titanium Oxide LTO Battery cell
|
Yinlong 66160 2.3V 35Ah LTO Battery cell
|
Yinlong 2.3V 40Ah LTO cell 66160
|
Yinlong 2.3V 45Ah 66160 LTO Battery cell
|
|||
|
Working temperature range (° C)
|
-50~65
|
|
|
|
|||
|
Cell's Rated Capacity (AH)
|
30
|
35
|
40
|
45
|
|||
|
Energy density (Wh/kg)
|
59
|
68
|
79
|
86
|
|||
|
Continuous/Peak current
|
300/600A
|
350/700A
|
400/800A
|
450/900A
|
|||
|
Diameter * Height (mm)
|
66X160
|
|
|
|
|||
|
Cell's weight(kg)
|
≤1.25
|
|
|
|
|||
|
Cycle Life (100% DOD) Times@25 ° C
|
≥25000(начальная мощность 80%） ≥25000(80% of initial capacity)
|
|
|
|
|||
|
Проект / модель
|
30AH LTO цилиндрический элемент 30AH LTO cylindrical cell
|
35AH LTO цилиндрический элемент 35AH LTO cylindrical cell
|
40AH LTO цилиндрический элемент 40AH LTO cylindrical cell
|
45AH LTO цилиндрический элемент 45AH LTO cylindrical cell
|
|||
|
диапазон рабочих температур(°C） Operating Temperature Range
|
-50~65
|
|
|
|
|||
|
номинальная емкость батареи(AH） Cell's Rated Capacity
|
30
|
35
|
40
|
45
|
|||
|
плотность энергии(Wh/kg) Energy Density
|
59
|
68
|
79
|
86
|
|||
|
Непрерывный / пиковый ток
|
300/600A
|
350/700A
|
400/800A
|
450/900A
|
|||
|
диаметр * высота(mm) Diameter * Height
|
66X160
|
|
|
|
|||
|
клеточный вес(kg） Cell's Weight
|
≤1.25
|
|
|
|
|||
|
срок службы (100% МО) Times@25°C Cycle Life(100%DOD)Times@25°C
|
≥25000(начальная мощность 80%） ≥25000(80% of initial capacity)
|
|
|
|
|||
