Pixel Pitch（mm)
|
P0.93
|
P1.25
|
P1.56
|
P1.53
|
|
LED Type
|
SMD
|
SMD
|
|
|
|
LED Size (mm)
|
606
|
1010
|
1010
|
1010
|
|
Pixel Density（Pixel/㎡）
|
113778
|
640000
|
|
|
|
Module Size (mm)
|
150*168.75
|
150*168.75
|
150*168.75
|
320*160
|
|
Module Resolution (Dot)
|
160*180
|
120*135
|
120*135
|
|
|
Cabinet Size (mm)
|
600*337.5*32.5
|
600*337.5*32.5
|
600*337.5*32.6
|
640*480*32.7
|
|
Cabinet Resolution (Dot)
|
640*368
|
480*270
|
384*216
|
416*312
|
|
Cabinet Weight (Kg)
|
3.5
|
3.5
|
3.5
|
4.5
|
|
Cabinet Material
|
Die-casting Alumium
|
Die-casting Alumium
|
Die-casting Alumium
|
Die-casting Alumium
|
|
Maintenance Way
|
Front
|
Front
|
Front
|
Front
|
|
IP Rating
|
IP 65
|
IP 66
|
IP67
|
IP68
|
|
Brightness (Cd/㎡）
|
300-500
|
500-700
|
500-800
|
500-800
|
|
Color Temperature （K)
|
1000-9800（Adjustable)
|
1000-9800（Adjustable)
|
1000-9800（Adjustable)
|
1000-9800（Adjustable)
|
|
Viewing Angle (W-H)
|
170°(W)-170°（H）
|
170°(W)-170°（H）
|
170°(W)-170°（H）
|
170°(W)-170°（H）
|
|
Contrast
|
>10000:1
|
>10000:1
|
>10000:1
|
>10000:1
|
|
Max Consumption(W/㎡)
|
< 300W
|
< 300W
|
< 600W
|
< 600W
|
|
Average Consumption (W/㎡)
|
< 100W
|
< 100W
|
< 200W
|
< 200W
|
|
Input Voltage DC (V)
|
110V-220V
|
110V-220V
|
110V-220V
|
110V-220V
|
|
Drive Mode
|
|
|
|
|
|
Refresh Rate (Hz)
|
> 2880 Hz
|
> 3840 Hz
|
> 3840 Hz
|
> 3840 Hz
|
|
Gray Scale (Bit)
|
14Bit-16Bit
|
14Bit-16Bit
|
14Bit-16Bit
|
14Bit-16Bit
|
|
LED ave life (Hrs)
|
> 10000
|
> 10000
|
> 10000
|
> 10000
|
