Electrical and general specification
|
|
|
|
|
||||
|
Max.current/voltage rating
|
|
200mA 24VAC/DC
|
|
|
||||
|
Switch resistance ON
|
|
10Ω max.
|
|
|
||||
|
Switch resistance OFF
|
|
5MΩ max.
|
|
|
||||
|
Operating force
|
|
5-10N
|
|
|
||||
|
Life expectancy
|
|
50 million cycles
|
|
|
||||
|
LED consumption
|
|
Illuminated dot:10mA - illuminated ring:20mA
|
|
|
||||
|
Environmental specification
|
|
|
|
|
||||
|
Sealing
|
|
IP68/IP69K
|
|
|
||||
|
Vibration resistance
|
|
10-500 Hz/10 g
|
|
|
||||
|
Operating temperature
|
|
-40℃ ~ 75℃
|
|
|
||||
|
Material
|
|
|
|
|
||||
|
Case
|
|
Aluminium Alloy, stainless steel
|
|
|
||||
|
Wire
|
|
section 0.22 mm² length 300 mm
|
|
|
||||
|
PC terminal
|
|
bronze, tin plated
|
|
|
||||
