Quick Details
-
Place of Origin:
-
Shandong, China
-
Machine Weight:
-
3500 kg
-
Bucket capacity:
-
0.03
-
Product name:
-
Mini Skid Steer Loader
-
Engine:
-
yunnei
-
Color:
-
Customer's Requiement
-
Drive type:
-
4x4 Wheel Drive
-
Brand:
-
China Famous Brand
-
Origin:
-
China
-
Load capacity:
-
0.03
-
Attachments:
-
Quick Hitch
Quick Details
-
Engine Brand:
-
KAMA
-
Power:
-
75 KW, 37 KW, 15.7 kw
-
Brand Name:
-
Elite
-
Place of Origin:
-
Shandong, China
-
Machine Weight:
-
3500 kg
-
Bucket capacity:
-
0.03
-
Product name:
-
Mini Skid Steer Loader
-
Engine:
-
yunnei
-
Color:
-
Customer's Requiement
-
Drive type:
-
4x4 Wheel Drive
-
Brand:
-
China Famous Brand
-
Origin:
-
China
-
Load capacity:
-
0.03
-
Attachments:
-
Quick Hitch
Specifications
|
Machine Rating |
Dimensions |
||
|
ITEMS |
SPECIFICATIONS |
ITEMS |
SPECIFICATIONS |
|
Engine Brand |
LONCIN/RATO/KOOP |
Height at Maximum Extension/mm |
2450 |
|
Rated Power/HP |
15-18KW |
Height To the the bucket pin /mm |
1870 |
|
Rated Speed/rpm |
3600 |
Vehicle height |
1350 |
|
Number of cylinders |
2 |
Maximum Height as Lay the bucket flat/mm |
1810 |
|
Air intake way |
Naturally Aspirated |
Total length without appendages/mm |
1680 |
|
Displacement/cc |
639 |
Length With standard bucket /mm |
2206 |
|
Emissions Standards |
EUR 5 |
Maximum height unloading Angle |
34 |
|
Rated Operating Capacity/Kg |
300 |
Dumping Height/mm |
1510 |
|
Maximum Operating Capacity/Kg |
400 |
Discharge Distance/mm |
450 |
|
Maximum Breakout Force/KN |
450 |
The flip Angle of the bucket on the ground |
27 |
|
Bucket Capacity/m3 |
0.12 |
Bucket flip Angle at highest Pos. |
114 |
|
Driving Speed/ km/h |
0-6 |
Wheel Base/mm |
850 |
|
Total Cycling Time/s |
9 |
Ground Clearance/mm |
150 |
|
System Operating Pressure /bar |
17-21 |
Tail Length/mm |
280 |
|
Fuel Tank Capcity/L |
10 |
Wheel base
|
720 |
|
Operating Weight/Kg |
1200 |
Vehicle width
|
960 |
|
Tyre Size |
18*72 |
Bucket width/mm |
1000 |
The Engine optional
Application
