Quick Details
-
Rated Power:
-
50W
-
Dimension(L*W*H):
-
81Lx 43Wx 54H cm
-
Year:
-
2020
-
After-sales Service Provided:
-
Field installation, commissioning and training, Field maintenance and repair service, Online support, Video technical support
-
After Warranty Service:
-
Online support
-
Local Service Location:
-
United States
-
Size of sample stage:
-
80 x 51 mm
-
Wire traveling speed:
-
0-3m/sec
-
Rotate speed:
-
50-900rpm
-
Stage travel distance:
-
Max. 50.8 mm (2") travel length
-
warranty:
-
one year
-
Cutting thickness:
-
Up to 50 mm
-
Diamond Wire:
-
One piece loop type diamond wire
-
Weight:
-
50kg
-
Certification:
-
ce
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
CYKY
-
Voltage:
-
AC 110~220 50/60Hz
-
Rated Power:
-
50W
-
Dimension(L*W*H):
-
81Lx 43Wx 54H cm
-
Year:
-
2020
-
After-sales Service Provided:
-
Field installation, commissioning and training, Field maintenance and repair service, Online support, Video technical support
-
After Warranty Service:
-
Online support
-
Local Service Location:
-
United States
-
Size of sample stage:
-
80 x 51 mm
-
Wire traveling speed:
-
0-3m/sec
-
Rotate speed:
-
50-900rpm
-
Stage travel distance:
-
Max. 50.8 mm (2") travel length
-
warranty:
-
one year
-
Cutting thickness:
-
Up to 50 mm
-
Diamond Wire:
-
One piece loop type diamond wire
-
Weight:
-
50kg
-
Certification:
-
ce
Precision endless diamond wire saw for cutting Photovoltaic pv silicon wafer
CY-STX-201 is a CE Certified precision endless wire saw, designed to provide a very smooth cutting for almost all kinds of materials by using either a diamond impregnated or a plain wire blade with an abrasive slurry. It is an ideal tool suitable for cutting valuable delicate and fragile crystals such as SrTiO3, YVO4, and GaAs etc.
Technical parameters:
|
|
|
|
Size of sample stage |
80 x 51 mm |
|
Wire traveling speed |
0-3m/sec |
|
Rotate speed |
|
|
Diamond Wire
|
|
|
Stainless Steel Wire (optional) |
0.25mm Dia. stainless steel wire is available. The stainless wire is used with the abrasive slurry that can provide more efficient cutting in terms of the cutting speed and surface finish comparing to the diamond impregnated wire in some cases.
|
|
Cutting thickness |
Up to 50 mm |
|
Power Supply |
AC 110~220 50/60Hz, 50W |
|
Product dimension
|
With saw closed: 81Lx 43Wx 37H cm
|
|
Package dimension |
40" x 25" x 30" |
|
Shipping Weight |
150 Lbs |
|
Warranty
|
One year limited manufacturer warranty with lifetime support (cutting wire is not covered by the warranty)
|
|
Certification
|
CE certified. With additional certification fee, MTI can arrange NRTL to perform UL/CSA inspection and label the machine per customer's request.
|
| Application Note |
Diamond wire is very easy broken. Please carefully install the wire and balance gravity before cutting.
|
Product diaplay
Founded in 2005, Zhengzhou CY Scientific Instrument Co., Ltd. is a company specializing in the development and production of laboratory technology research equipment. The products are mixed, pressed, burned, cut, ground, polished, coated, analytical equipment and related consumables. Products include laboratory sintering equipment, coating equipment and so on. At present, it has been exported to 25 countries and regions such as the United States, Europe, and Southeast Asia, and has been well received by various scientific research units.
We have a mature technology research and development team, the number of technicians is 33, the company has 150 people, more than 500 square meters of office space, the factory covers an area of about 1,500 square meters located in Zhengzhou High-tech Zone Electronic Industrial Park. The products are mainly located in the research market, serving scientific research in the labs of universities and colleges, and can also customize products according to your needs.
Q. Are you a manufacturer or a trading company?
A. We are professional laboratory instrument manufacturers, have their own design team and factory, have mature technical experience, and can guarantee the quality of products and the optimal price.
Q. How is your company's product after-sales service system?
A. The product warranty period is 12 months, we can provide lifetime maintenance. We have professional pre-sales and after-sales departments that can respond to you within 24 hours to resolve any technical issues.
Q. How long is your delivery time? If I want to customize the instrument, how long does it take?
A. 1. If the goods are in stock, it is 5-10 days. 2. We can provide customized services for our customers. It usually takes 30-60 days depending on the specifications of the custom instrument.
Q. Our country's power supply and plug are different. How do you solve it?
A. We can supply a transformer and plug according to your local requirements according to the power plug of different countries.
Q. How to pay?
A. T / T, L / C, D / P, etc., it is recommended to use Alibaba Trade Guarantee.
Q. How is the package of goods? Delivery methods?
A. 1. Standard export fumigation sign wooden box packaging 2. Express, air, sea shipping according to customer requirements, find the most suitable way.
More questions, please contact customer service
