Quick Details
-
Application:
-
construction
-
Rated Lifting Moment:
-
962kN-m, 962kN-m
-
Place of Origin:
-
China
-
Marketing Type:
-
New Product 2022
-
Weight (KG):
-
26400 kg
-
Max Lifting Capacity:
-
25Ton
-
Max Boom Length:
-
48.1m
-
Model Number:
-
STC250
-
Maximum gradeability:
-
40%
-
Brand:
-
famous
-
Overall length:
-
12800mm
-
Overall width:
-
2500mm
-
Overall height:
-
4000mm
-
Span:
-
5.3*6.2m
Quick Details
-
Rated Loading Capacity:
-
25 ton
-
Max. Lifting Height:
-
48.1m
-
Engine Brand:
-
top brand
-
Application:
-
construction
-
Rated Lifting Moment:
-
962kN-m, 962kN-m
-
Place of Origin:
-
China
-
Marketing Type:
-
New Product 2022
-
Weight (KG):
-
26400 kg
-
Max Lifting Capacity:
-
25Ton
-
Max Boom Length:
-
48.1m
-
Model Number:
-
STC250
-
Maximum gradeability:
-
40%
-
Brand:
-
famous
-
Overall length:
-
12800mm
-
Overall width:
-
2500mm
-
Overall height:
-
4000mm
-
Span:
-
5.3*6.2m
Contact Info
Products Description
Good quality
It is adopted with international advanced distributed integrated bus data communication network, allowing processing of large amounts of data, fast speed and high stability. With streamlined full-width cab, it provides wider vision and more comfortable operation.
High safety and reliability
It is equipped with voice alarm system to prevent misoperation and ensure the safety of operation and personnel. The load moment limiter system with high precision, high stability and high intellectualization is applied to provide a full protection for lifting operations.
GCP system
The remote monitoring and management system can monitor equipment operating condition, collect operation parameter, and implement remote fault diagnosis and management. Customers can master the operating conditions of the crane, and inquire and order parts at home.
It is adopted with international advanced distributed integrated bus data communication network, allowing processing of large amounts of data, fast speed and high stability. With streamlined full-width cab, it provides wider vision and more comfortable operation.
High safety and reliability
It is equipped with voice alarm system to prevent misoperation and ensure the safety of operation and personnel. The load moment limiter system with high precision, high stability and high intellectualization is applied to provide a full protection for lifting operations.
GCP system
The remote monitoring and management system can monitor equipment operating condition, collect operation parameter, and implement remote fault diagnosis and management. Customers can master the operating conditions of the crane, and inquire and order parts at home.
Product Paramenters
|
Capacity
|
Max. lifting capacity
|
25t
|
|
Dimensions
|
Overall length
|
12750mm
|
|
|
Overall width
|
2500mm
|
|
|
Overall height
|
3550mm
|
|
|
Axles
|
3
|
|
|
Axle distance-1,2
|
4325mm
|
|
|
Axle distance-2,3
|
1350mm
|
|
Weight
|
Overall weight
|
30000kg
|
|
|
Front axle load
|
6500kg
|
|
|
Rear axle load
|
23500kg
|
|
Engine
|
Model
|
Cummins
|
|
|
Rated power
|
213kW/2100rpm
|
|
|
Rated torque
|
1050N·m/1200~1400rpm
|
|
|
Emission standard
|
Euro III
|
|
Traveling
|
Max. traveling speed
|
80 km/h
|
|
|
Min.turning radius
|
10 m
|
|
|
Min.turning radius of boom head
|
12 m
|
|
|
Drive train
|
6×4
|
|
|
Min. ground clearance
|
220mm
|
|
|
Approach angle
|
17 °
|
|
|
Departure angle
|
12 °
|
|
|
Max. Gradeability
|
38%
|
|
|
Fuel consumption per 100km
|
≤ 37L
|
|
Main Performance
|
Temperature range
|
- 30 ºC~ + 60 ºC
|
|
|
Min.lifting radius
|
3m
|
|
|
Tail swing radius of superstructure
|
3.37m
|
|
|
Boom section
|
4
|
|
|
Boom shape
|
U-shaped
|
|
|
Max. lifting moment-Base boom
|
962kN·m
|
|
|
Max. lifting moment-Full-extend boom
|
544kN·m
|
|
|
Max. lifting moment-Full-extend boom+jib
|
341kN·m
|
|
|
Length-Base boom
|
10.65m
|
|
|
Length-Full-extend boom
|
33.5m
|
|
|
Length-Full-extend boom+jib
|
41.5m
|
|
|
Outrigger span(Longitudinal/Transversal)
|
5.3m × 6.2m
|
|
|
Jib offset
|
0 ° 15 ° 30 °
|
|
|
|
|
|
Working Speed
|
Max. single rope lifting speed of main winch(no load)
|
>=120m/min
|
|
|
Max. single rope lifting speed of auxiliary winch(no load)
|
>=120m/min
|
|
|
Full extend/retract time of boom
|
70 / 50s
|
|
|
Full raise/lower time of boom
|
70 / 55s
|
|
|
Swing speed
|
0~2 r/min
|
|
Aircondition
|
HVAC in up cab
|
Cooling and Heating
|
|
|
HVAC in low cab
|
Cooling and Heating
|
