Model 2V025-06 2V025-08
Working Medium Air, Water, Oil, Gas
Motion Pattern Direct Drive Type
Type Normal Close Type
Aperture Flow Rate 2.5mm
CV Value 0.23
Port Size G1/8''(NPT) G1/4''(NPT)
Operation Fluid Viscosity 20CST(Below)
Working Pressure 0~0.7Mpa
Max. Pressure Resistance 1.0Mpa
Operation Temp Range -5~+80'C
Voltage Range 10% up and down
Material of Body Alloy
Material of Oil Seal NBR or FKM
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
EPSolid
-
Standard or Nonstandard:
-
Standard
-
Color:
-
Black & Silver
-
Supply Voltage:
-
12~240V AC/DC
-
Body Material:
-
Alloy
-
Seal Material:
-
NBR or FKM
-
Coil:
-
Wire Lead
Quick Details
-
Port Size:
-
1/4'', 1/8'' or 1/4''
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
2V025-08
-
Brand Name:
-
EPSolid
-
Standard or Nonstandard:
-
Standard
-
Color:
-
Black & Silver
-
Supply Voltage:
-
12~240V AC/DC
-
Body Material:
-
Alloy
-
Seal Material:
-
NBR or FKM
-
Coil:
-
Wire Lead
Product Description
