Quick Details
-
Design Style:
-
Eclectic
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
QINGYING
-
Model Number:
-
P4000 Series
-
Material:
-
30%Polyester, 70%PVC
-
Power Supply:
-
AC
-
Usage:
-
Outdoor Windproof
-
Control Mode:
-
Remote Control
-
Product Name:
-
Windproof Roller Blinds
-
Keyword:
-
Zip Rail Windproof Roller Blinds
-
Feature:
-
Waterproof Blackout
-
Composition:
-
30%Polyester, 70%PVC
-
Thickness:
-
0.7mm±5%
-
Function:
-
Weather Resistant
-
Weight per sqm:
-
550g/sqm±5%
-
UV Blockage:
-
97%
-
Control:
-
Remoto Control
Quick Details
-
Applicable Window Type:
-
French Window
-
Opening and Closing Method:
-
Upper Open
-
Installation Type:
-
Ceiling Installation, Exterior Installation, Side Installation, built-in
-
Design Style:
-
Eclectic
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
QINGYING
-
Model Number:
-
P4000 Series
-
Material:
-
30%Polyester, 70%PVC
-
Power Supply:
-
AC
-
Usage:
-
Outdoor Windproof
-
Control Mode:
-
Remote Control
-
Product Name:
-
Windproof Roller Blinds
-
Keyword:
-
Zip Rail Windproof Roller Blinds
-
Feature:
-
Waterproof Blackout
-
Composition:
-
30%Polyester, 70%PVC
-
Thickness:
-
0.7mm±5%
-
Function:
-
Weather Resistant
-
Weight per sqm:
-
550g/sqm±5%
-
UV Blockage:
-
97%
-
Control:
-
Remoto Control
Detailed video for easy understanding of the product.
Products Description
|
Model
|
QY101
|
QY131
|
|
|
Minimum Width
|
≥0.5M
|
≥0.5M
|
|
|
Maximum Width
|
≤4.0M
|
≤6.0M
|
|
|
Minimum Height
|
≥0.5M
|
≥0.5M
|
|
|
Maximum Height
|
≤3.5M
|
≤6.0M
|
|
|
Note
|
When Width＞3m height≤3.0M
|
When Width＞3m height≤3.0M
|
|
|
Suggestion
|
When width≤0.5m，maximum height need to＜3m;
When width≤1.2m，maximum height need to＜5m
|
|
|
|
Specification
|
P4000 Series
|
A4000 Series
|
1000 Series
|
|
Composition factor
|
30%Polyester, 70%PVC
|
30%Polyester, 70%PVC
|
25%Polyester, 75%PVC
|
|
Openness factor
|
3%
|
1%
|
40%
|
|
Thickness(mm)
|
0.7±5%
|
0.7±5%
|
0.54±5%
|
|
Width(cm)
|
183/250/300
|
183/250/300
|
183/250/300
|
|
Mesh weight(g/㎡)
|
550±5%
|
615±5%
|
235±5%
|
|
Mesh/In(inch)
|
38*36
|
40*36
|
17*16
|
|
Breaking strength(N)
|
≥2600, ≥2500
|
≥2500, ≥2200
|
≥1100/5cm, ≥1000/5cm
|
|
Color fastness
|
ISO 105 BO2, GRADE 8
|
ISO 105 BO2, GRADE 8
|
ISO105 bo2, grade 8
|
|
Anti-ultraviolet
|
97%
|
99%
|
60%
|
|
Fire classification
|
NFPA 701-2004 TM#1,
California Administrative Code, Title19,
BS 5867 Part2 TypeB
|
GB 17591-95 Grade B1,
GB 20286-2006 Flame Retardant Grade 2
|
GB 17591-95 Grade B1,
GB 20286-2006 Flame Retardant Grade 2 |
