Quick Details
-
After Warranty Service:
-
Video technical support
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Application:
-
mosquito repellent and killing
-
Pressure:
-
160KN
-
Power:
-
26KW
-
Capacity:
-
23760pcs/h
-
Weight:
-
5 ton
-
Size:
-
5500*6000*1700 mm
-
Workers:
-
4
-
Mould numbers:
-
18pcs
Quick Details
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Tenhui
-
Weight (KG):
-
5000
-
After Warranty Service:
-
Video technical support
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Application:
-
mosquito repellent and killing
-
Pressure:
-
160KN
-
Power:
-
26KW
-
Capacity:
-
23760pcs/h
-
Weight:
-
5 ton
-
Size:
-
5500*6000*1700 mm
-
Workers:
-
4
-
Mould numbers:
-
18pcs
Product Overview
Mosquito-repellent incense machine production line/full automatic mosquito coil making machine/wood powder mosquito coil machine
Automatic Mosquito Coil Machine Production Line
Part 1. Mosquito Coil Mixing Machine
Model: THJB -2000A
Machine set Includes:Screw elevator ,Screening power machine, Spiral discharging machine (Pneumatic Valve Switch ), Electronic Metering Tank (Pneumatic Valve Switch ).
Size:6000mmx3500mmx3500mm
Weight: 5tons
Power: 20KW
Operator:1 person
Machine set Includes:Screw elevator ,Screening power machine, Spiral discharging machine (Pneumatic Valve Switch ), Electronic Metering Tank (Pneumatic Valve Switch ).
Size:6000mmx3500mmx3500mm
Weight: 5tons
Power: 20KW
Operator:1 person
Part 2. Mosquito Coil Making Machine
The wet billet into the molding machine squeeze material facilities, through two extrusion, into the fine billet body into a strip shape, and then by the punching into mosquito-coated wet blank. (Configuration: feeder machine feeding trough for extrusion
machine)
Model : THWXJ -18
Size :5300mmx5500mmx1700mm
Power :26.5KW
Stamping Frequency :20-22 times/minute
Operator:3-4 person
machine)
Model : THWXJ -18
Size :5300mmx5500mmx1700mm
Power :26.5KW
Stamping Frequency :20-22 times/minute
Operator:3-4 person
Part 3 Drying room
Push the mosquito coil into the drying room, drying time of each cart is about 4-6 hours. Drying room contains three types : coal wood drying, natural gas drying, air electricity drying, etc.
Part 4. Mosquito coil collecting machine
Model : THSXJ -3.5
Size :3900mmx300mmx1500mm
Power :3.5KW
Closed Screen Frequency: 20-30screen/minute
Operator:3-4 person
Size :3900mmx300mmx1500mm
Power :3.5KW
Closed Screen Frequency: 20-30screen/minute
Operator:3-4 person
Part 5. Mosquito coil dispatching machine
Type: THFPJ-300
Gauge case: 1600mmx600mmx1500mm
Work rate: 1.8 KW
Release frequency: 9000-12000 disks/hour
Operator: 1 person
Part 6. Mosquito coil spraying machine
Connect with the tablet machine, and the mosquito coil is automatically put into the spray machine and sprayed with a layer of medicine on the surface of the mosquito coil.
Model : THPYJ -1.5
Size : 1600mmx600mmx1200mm
Power :1.5KW
Power :1.5KW
SALES AND SERVICE NETWORK
FAQ
Q1. Are you manufacturer or Trader?
A1: We are professional in designing and producing mosquito coil machineries for over 14 years, We have our own designer, and the
machines have been patented.
Q2. How to get an accurate quotation?
A2: The customer should provide the related requirement of production capacity, working hours and number of employees, etc.
Q3. What if I use this machine for the first time and know nothing of it ?
A3: We will have our engineers to be dispatched for installation and training you how to operate it, you can just inform us some
details of the product you need then we can customize as your special order.
Q4. How does your factory do regarding quality control?
A4:Longyan Tenhui has been regard quality as the priority. We always attach great importance to quality controlling from the very
beginning to the very end, so all machineries are tested before shipment, and our engineers will be sent to your factory site to
assist for installation and trial run.
Q5. How about your delivery time?
A5: Generally, it will take 50 working days for 1 production line after receiving your deposit payment. The specific delivery time
depends on the items and the quantity of your order.
Q6. What is the warranty period of the machine?
A6: We can supply 1 year warranty for our machines, we can provide internet or calling service at any time.
Q7. What is the after-sales service of your factory?
A7: 1.Installation on site: abroad expense is on foreign customer.(Including round ticket and accommodation cost, etc.)
2.Personnel training: Our engineers will give your employees free machine training when they come to your company to assemble the
machines, and welcome to our factory to learn how to operate our machine.
Contact Info:
Ms. Eiffel Deng
Ph/Whatsapp: +86 1831 999 8795
Email: sales@tenhuimachinery.com
A1: We are professional in designing and producing mosquito coil machineries for over 14 years, We have our own designer, and the
machines have been patented.
Q2. How to get an accurate quotation?
A2: The customer should provide the related requirement of production capacity, working hours and number of employees, etc.
Q3. What if I use this machine for the first time and know nothing of it ?
A3: We will have our engineers to be dispatched for installation and training you how to operate it, you can just inform us some
details of the product you need then we can customize as your special order.
Q4. How does your factory do regarding quality control?
A4:Longyan Tenhui has been regard quality as the priority. We always attach great importance to quality controlling from the very
beginning to the very end, so all machineries are tested before shipment, and our engineers will be sent to your factory site to
assist for installation and trial run.
Q5. How about your delivery time?
A5: Generally, it will take 50 working days for 1 production line after receiving your deposit payment. The specific delivery time
depends on the items and the quantity of your order.
Q6. What is the warranty period of the machine?
A6: We can supply 1 year warranty for our machines, we can provide internet or calling service at any time.
Q7. What is the after-sales service of your factory?
A7: 1.Installation on site: abroad expense is on foreign customer.(Including round ticket and accommodation cost, etc.)
2.Personnel training: Our engineers will give your employees free machine training when they come to your company to assemble the
machines, and welcome to our factory to learn how to operate our machine.
Contact Info:
Ms. Eiffel Deng
Ph/Whatsapp: +86 1831 999 8795
Email: sales@tenhuimachinery.com
