Quick Details
-
Surface Treatment:
-
Anodized, Brushed, Foil Decoration, Mirror, PE Coated, PVDF Coated
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Alumetal
-
Model Number:
-
Alumetal PVDF
-
Standard width:
-
1220mm
-
Panel thickness:
-
3mm 4mm
-
coil thickness:
-
0.03-0.5mm
-
Certification:
-
CE ,ISO ,SGS certificate
-
MOQ:
-
500Sqms
-
Coating:
-
PVDF PEVE PE
-
Application:
-
Decorative Material
-
Aluminum Alloy Grade:
-
1100 3003 5005
-
Brand:
-
Alumetal or OEM
-
Type:
-
Building Material Wall Decorative
Quick Details
-
Warranty:
-
More than 5 years
-
Size:
-
1220x2440mm
-
Project Solution Capability:
-
total solution for projects
-
Surface Treatment:
-
Anodized, Brushed, Foil Decoration, Mirror, PE Coated, PVDF Coated
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Alumetal
-
Model Number:
-
Alumetal PVDF
-
Standard width:
-
1220mm
-
Panel thickness:
-
3mm 4mm
-
coil thickness:
-
0.03-0.5mm
-
Certification:
-
CE ,ISO ,SGS certificate
-
MOQ:
-
500Sqms
-
Coating:
-
PVDF PEVE PE
-
Application:
-
Decorative Material
-
Aluminum Alloy Grade:
-
1100 3003 5005
-
Brand:
-
Alumetal or OEM
-
Type:
-
Building Material Wall Decorative
Alumetal High Strength
4mm alucobond with aluminium composite panel for door and boat with packaging design
| Introduction | ||
| Aluminum Composite Panels are flexible, formable, compact and stable which allows them to be used in various applications but mostly they are used in architecture and designing. They are used in external and internal architectural cladding or partitions, false ceilings, signage, machine coverings, container constructions, etc. Most of the time you will find Aluminum Composite Material panels used in making signs which you can see outside stores and such, and that is due to the Aluminum Composite Material being weather proof in addition to being light and durable. |
| Specifications Of Aluminum Composite Panel | |
| Normal Width | 1220mm, 1250mm, specially 1500mm custom accepted |
| Panel Length | 2440mm ,5000mm,5800mm ,normally within 5800mm. |
| for 20ft container custom accepted | |
| Panel Thickness | 2mm 3mm 4mm 5mm 6mm 8mm ... |
| Aluminum Alloy | AA1100,AA3003,AA5005 ...(Other Grade On Requirement) |
| Aluminum Thickness | 0.05mm to 0.50mm |
| Coating | PE coating , PVDF coating, NANO, Brush surface, mirror surface |
| PE Core | Recycle PE Core/Fireproof PE Core/Unbreakable PE Core |
| Color |
Metal/Matt/Glossy/Nacreous/Nano/Spectrum/Brushed/Mirror/ Granite/Wooden |
| Core Material | HDP LDP Fire-proof |
| Delivery | Within two weeks after receiving deposit |
| MOQ | 500 Sqm per color |
| Brand/OEM | Alumetal/Customized |
| Payment Terms | T/T, L/C at sight, D/P at sight,Western Union |
| Packing |
FCL:In bulk;LCL:In Wooden pallet Package;according customers’ requirement |
Welcome to send your details to ask for best price !
| Raw Material of Alumetal aluminium composite panel | |
| Front side |
Aluminum-alloy sheet coated with flour-carbon resin (PVDF) OR PE roasting painting |
| Core | Nontoxic polyethylene |
| Back side | Aluminum-alloy sheet coated with polyester resin painting |
| Surface finish | Treated with PVDF OR PE resin rolling roasting coating |
| Outside | Protective carrier tape with brand logo |
Welcome to send your details to ask for best price !
| Characteristics of Alumetal aluminium composite panel |
| Superior strength-to-weight ratio. |
| Life expectancy of up to 20 years. |
| Surface smoothness. |
| Easy Installation. |
| Attractive Finishes. |
| Reduces heat and sound transmission. |
1.What is your MOQ(Minimum Order Quantity)?
500m2 for one color and one specification and the color needs to be on our color chart ,and it can be less if there is the same color coils in stock .
2.What is the production time ?
The production time is within 2 weeks after receiving the deposit .
3.What about your payment terms ?
It can be TT(30% deposit in advance and 70% needs to be paid according to the copy of BL),LC at sight ,DP at sight and other payment ,such as Paypal ,West Union ,Wechat Pay ect .
4.What is the panel size and thickness?
4.1. Width: 1000-2000mm; 1220mm, 1250mm, 1500mm are recommended.
4.
2. Length: accept custom length, 2440mm, 3050mm, 4050mm, 5000mm are recommended .
4.
3 Panel Thickness:2mm-6mm; 3 and 4mm are recommended and 3mm is usually used in the signage and interior wall and 4mm is usually used in the exterior wall .
4.
4Aluminum thickness:0.05-0.5mm,and different application use different thickness ,
What is the application for your required panels ?
5.
Do you have any test certificates?
Yes, stable good quality is important for long time business cooperation.SGS,CE and ISO:9001 has been passed in our factory.
6.Do you service OEM?
Yes, OEM accept. Custom
size
,custom
color (Ral color , Pantone color,the color can be matched as your sample )
,custom
protective film
and custom
shape
ect .
7.Do you offer sample?
Yes, Free samples are available with our Alumetal Color Chart ,
please tell your address .
8.How about the warranty for the ACP panels ?
PE coated ACP warranty is 5 years and PVDF coated ACP warranty is 15 years ,Alumetal warranty letter will be provided with the documents if needed .
9.Do you have the fire proof ACP panels ?
Both B1 and A2 fire proof ACP panels are provided , which one do you prefer ,our test report can be send to you if needed .
