Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
DM
-
Weight:
-
1200 kg
-
Dimension(L*W*H):
-
2050*1060*2000mm
-
Product name:
-
Crawler Photovoltaic pile driver
-
Diesel engine:
-
25HP single cylinder (optional)
-
Chassis:
-
Engineering rubber track chassis
-
Power head:
-
Hydraulic pneumatic type
-
Drilling diameter:
-
50-300mm
-
Depth:
-
1m to 30m(custom)
-
Pile driving height:
-
1-3 m
-
Adapt to rock types:
-
Medium hard hard rock f=8-163
-
Drilling speed:
-
F=8-12...100-200mm/min
Quick Details
-
Marketing Type:
-
Hot Sale Product
-
Efficiency:
-
F=8-12...100-200mm/min
-
Piling Speed(m/min):
-
F=8-12...0.1-0.2m/min
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
DM
-
Weight:
-
1200 kg
-
Dimension(L*W*H):
-
2050*1060*2000mm
-
Product name:
-
Crawler Photovoltaic pile driver
-
Diesel engine:
-
25HP single cylinder (optional)
-
Chassis:
-
Engineering rubber track chassis
-
Power head:
-
Hydraulic pneumatic type
-
Drilling diameter:
-
50-300mm
-
Depth:
-
1m to 30m(custom)
-
Pile driving height:
-
1-3 m
-
Adapt to rock types:
-
Medium hard hard rock f=8-163
-
Drilling speed:
-
F=8-12...100-200mm/min
Products Description
Crawler pile drivers are suitable for slope protection industry projects. This machine is equipped with a crawler travel device and uses hydraulic travel motor technology. The technology is relatively advanced, the maneuverability is good, and it can adapt to harsh construction environments such as swamps, quagmires, and potholes. The brand engine has strong power, reliable performance and stable operation for a long time. The overall structure of the drill frame is reasonable. It uses thickened steel plates and incorporates secondary welding technology to ensure that the machine body does not shake or tilt during operation, improving construction safety performance.
|
Crawler Photovoltaic pile driver
|
|
|
|
Diesel engine
|
25HP single cylinder (optional)
|
|
|
Chassis
|
Engineering rubber track chassis
|
|
|
Power head
|
Hydraulic pneumatic type
|
|
|
Drilling diameter
|
50-300mm
|
|
|
Depth
|
1m to 30m(custom)
|
|
|
Pile driving height
|
1-3 m
|
|
|
Adapt to rock types
|
Medium hard hard rock f=8-163
|
|
|
Air consumption
|
6 square meters per minute
|
|
|
Drilling speed
|
F=8-12…100-200mm/min
|
|
|
Walking speed
|
7-15km/h
|
|
|
Way of walking
|
Crawler gearbox walking
|
|
|
Heat dissipation method
|
Hydraulic radiator
|
|
|
Pressurization system
|
Hydraulic cylinder chain booster
|
|
|
Carriage stroke
|
2.6 meters or customized
|
|
|
Weight
|
1200KG
|
|
|
Oil pump
|
Single pump
|
|
|
Torque Single
|
1800/2000 torque
|
|
|
Machine size
|
2050*1060*2000mm
|
|
|
Hoist power
|
Full hydraulic
|
|
Product Display
Powerful function
Drilling depth up to 30m, drilling diameter 50-200mm.
Accurate drilling positioning
The drilling angle is adjustable from 45° to 90°, easy to operate, and the drilling efficiency is fast.
New hydraulic technology
Advanced hydraulic system, excellent hydraulic components, long service life of hydraulic system.
Details Images
Product Application
Small crawler piling rig is suitable for high-speed railway contact network support piles, slope protection piles, solar photovoltaic power station foundation support piles, power grid renovation, civil construction, new rural construction, municipal engineering construction, landscaping and other projects.
Applicable to various geological conditions.
Suitable for soil layer, clay layer, filler layer, clay layer, powder layer, silt layer, sand layer and part of the strata containing pebbles.
