Quick Details
-
Table Travel (Z) (mm):
-
1400 mm
-
Max. Table Load(kg):
-
4000
-
Travel (W-axis) (mm):
-
600 mm
-
Range of Spindle Speed(r.p.m):
-
1000 r.p.m
-
Spindle Motor Power(kW):
-
7.5
-
Place of Origin:
-
Yunnan, China
-
Brand Name:
-
GT
-
Dimension(L*W*H):
-
5215*3200*3000
-
Weight (T):
-
16.2 T
Quick Details
-
Table Size (mm):
-
1200*1100
-
Table Travel (X) (mm):
-
1300 mm
-
Table Travel (Y) (mm):
-
1100 mm
-
Table Travel (Z) (mm):
-
1400 mm
-
Max. Table Load(kg):
-
4000
-
Travel (W-axis) (mm):
-
600 mm
-
Range of Spindle Speed(r.p.m):
-
1000 r.p.m
-
Spindle Motor Power(kW):
-
7.5
-
Place of Origin:
-
Yunnan, China
-
Brand Name:
-
GT
-
Dimension(L*W*H):
-
5215*3200*3000
-
Weight (T):
-
16.2 T
PRODUCT DETAILS
|
Spindle diameter
|
mm
|
110
|
|
Spindle taper
|
|
ISO 50
|
|
Spindle speed
|
rpm
|
9-1000(18steps)
|
|
Max. spindle torque
|
N.m
|
1000
|
|
Max.drilling diameter of spindle
|
mm
|
65
|
|
Max.boring diameter of spindle
|
mm
|
300
|
|
Power of main drive motor
|
kW
|
7.5
|
|
Ma.torque of facing head
|
N.m
|
1500
|
|
Facing head speed
|
rpm
|
6-221(14 steps)
|
|
Table cross movement X
|
mm
|
1300
|
|
Spindle movement Y
|
mm
|
1100
|
|
Table longitudinal movement Z
|
mm
|
1400
|
|
Spindle movement W
|
mm
|
600
|
|
Facing head slide movement U
|
mm
|
170
|
|
Table rotation B
|
°
|
4×90
|
|
Table size
|
mm
|
1200x1100
|
|
Max.load of table
|
kg
|
4000
|
|
Overall dimension
|
mm
|
5215x3200x3000
|
|
Machine weight approx.
|
kg
|
16200
|
COMPANY PROFILE
Exhibition review
Customer Photos
PACKING&SHIPPING
CERTIFICATIONS
FAQ
|
1. Is your company a factory or trading company ?
|
|
We are factory and DMTG was founded in 1935.
|
|
2. Can we pay by L/C or others ？
|
|
Yes ,you can make the payment by T/T , l/C etc.
|
|
3. What is your payment terms ?
|
|
30% down-payment after contract ,and 70% payment before shipment, Meanwhite it
can
be discussed according
to your situation.
|
|
4. What is your delivery time ?
|
|
The delivery depends on different machines with different configurations. Please
contact
us to confirm it is in stock or not.
|
|
5. Do you have CE certificate?
|
|
Yes , we have CE certification, machine quality is guaranteed.
|
|
6. What is the warranty period ?
|
|
The warranty period is general 13 monthes after B/L date. During the warranty period,
we
will provide free replacement parts (EXW) which are easy damaged.
|
|
7. Can you send the service engineer to our company ?
|
|
When the machine arrive the destination, we timely send service engineers to install
machine according to buyer's schedule, the buyer shall bear all expenses.
|
