Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Reacher/OEM
-
Model Number:
-
RT2835
-
Torque:
-
0.9
-
Application:
-
RC 300-600mm Boat
-
Motor Size:
-
Diameter 28mm, Length 35mm
-
KV (RPM/V):
-
3000/3300/3800 kv
-
Max Voltage:
-
14/16/18v
-
Max Amps:
-
30/42/48A
-
Mounting Screw:
-
Diameter 16/19 M3*4
-
Shaft Diameter:
-
3.175mm
-
Shaft length:
-
12mm
-
Plug:
-
3.5mm
-
Net weight:
-
83g
Quick Details
-
Speed(RPM):
-
3000-3800KV
-
Continuous Current(A):
-
30-48A
-
Efficiency:
-
IE 4
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Reacher/OEM
-
Model Number:
-
RT2835
-
Torque:
-
0.9
-
Application:
-
RC 300-600mm Boat
-
Motor Size:
-
Diameter 28mm, Length 35mm
-
KV (RPM/V):
-
3000/3300/3800 kv
-
Max Voltage:
-
14/16/18v
-
Max Amps:
-
30/42/48A
-
Mounting Screw:
-
Diameter 16/19 M3*4
-
Shaft Diameter:
-
3.175mm
-
Shaft length:
-
12mm
-
Plug:
-
3.5mm
-
Net weight:
-
83g
Products Description
We have different working voltage, different KV optional, details specifications for your reference below：
|
Model
|
RT2835
|
|
|
||
|
Max Voltage
|
14V
|
16V
|
18V
|
||
|
KV
(RPM/V) |
3800KV
|
3500KV
|
3300KV
|
||
|
Max Power
|
600W
|
600W
|
600W
|
||
|
Max Amps
|
48A
|
42A
|
30A
|
||
|
Suggested ESC
|
50A
|
50A
|
50A
|
||
|
Mounting Screw
|
Φ16/19 M3*4
|
Φ16/19 M3*4
|
Φ16/19 M3*4
|
||
|
Shaft Diameter
|
3.175mm
|
3.175mm
|
3.175mm
|
||
|
Shaft Length
|
12mm
|
12mm
|
12mm
|
||
|
Diameter*Length
|
Φ28X35mm
|
Φ28X35mm
|
Φ28X35mm
|
||
|
Plug
|
3.5mm
|
3.5mm
|
3.5mm
|
||
|
Weight
|
83g
|
83g
|
83g
|
||
|
Box size
|
112*62*32mm
|
112*62*32mm
|
112*62*32mm
|
||
|
For R/C models
|
300-600mm
Boat
|
|
|
||
