Bending and shear reinforcement of concrete beams, reinforcement of concrete floors and Bridge Slabs, reinforcement of concrete,
reinforcement of piers, piles and other columns, reinforcement of chimneys, tunnels, water pools, concrete pipes and so on. In
addition, it is also widely used in the production of multi rotor UAV fuselage, such as traversing aircraft, aerial photography
UAV and so on.
- Product Details
- {{item.text}}
Quick Details
-
H Content (%):
-
0%
-
Ash Content (%):
-
0%
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Horyen
-
Model Number:
-
CF-sheet
-
Dimensions:
-
Consumer
-
Working Temperature:
-
Max 150 Degree
-
Volatile:
-
Non-volatile
-
Feature:
-
High strength, high modulus, lightweight, best quality, etc.
Quick Details
-
C Content (%):
-
100%CF
-
S Content (%):
-
0%
-
N Content (%):
-
0%
-
H Content (%):
-
0%
-
Ash Content (%):
-
0%
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Horyen
-
Model Number:
-
CF-sheet
-
Dimensions:
-
Consumer
-
Working Temperature:
-
Max 150 Degree
-
Volatile:
-
Non-volatile
-
Feature:
-
High strength, high modulus, lightweight, best quality, etc.
More orders, More discount !
If any questions or sample request, please Contact us
If any questions or sample request, please Contact us
Product Description
UD carbon fiber sheet is formed by infiltrating and hardening carbon fibers arranged in the same direction with resin. With good reinforcement effect and convenient construction, it can effectively solve the problems of difficult construction and large quantities of multi-layer carbon fiber cloth.
Using high-quality carbon fiber raw materials and good basic resin, UD carbon fiber sheet has good properties such as high tensile strength, corrosion resistance, earthquake resistance and impact resistance, etc.
Using high-quality carbon fiber raw materials and good basic resin, UD carbon fiber sheet has good properties such as high tensile strength, corrosion resistance, earthquake resistance and impact resistance, etc.
|
Product Name
|
Pultrusion Carbon fiber plate/board/strips/panels/sheets
|
|
Material
|
Carbon fiber yarn and Epoxy resin
|
|
Thickness
|
1.0mm, 1.2mm, 1.4mm, 2.0mm, 3.0mm
|
|
Width
|
50mm,100mm,200mm...
|
|
Length
|
100 Meters per roll
|
|
Application
|
Building repair,construction,bridge reinforcement
|
|
Tensile strength
|
2000Mpa or 2400Mpa
|
|
Modulus
|
140Gpa or 160Gpa
|
Feature:
1. High strength and high efficiency
2. Light weight and good flexibility
3. Convenient construction
4. Good durability and corrosion resistance
2. Light weight and good flexibility
3. Convenient construction
4. Good durability and corrosion resistance
Application & Construction process
Application
Construction process
1.Concrete surface treatment.
2.
Remove all dirt (dust, grease and surface covering) from the bonding surface of carbon fiber board by grinding or other methods until the solid base surface is exposed, and ensure the flatness of the base surface. After treatment, clean the surface with industrial vacuum cleaner or acetone.
3.
Apply a layer of 4-5mm structural adhesive on the concrete base surface with a scraper, and then apply 1-2mm thick structural adhesive on the carbon plate.
4.
Gently press and paste the carbon fiber board coated with bonding resin on the position to be pasted. Use rubber roller to compact evenly and stably along the fiber direction, so that the resin overflows from both sides to ensure compactness and no cavity. When multiple carbon fiber boards are pasted in parallel, the gap between the two boards shall not be less than 5mm.
5.
Finally, remove the excess adhesive and clean the edge part (carbon fiber boardcan’t be rolled or dragged on the ground without a protective layer to avoid damage to the carbon fiber board surface).
