Quick Details
-
Product Name:
-
Aluminum adjustable stage /layer stage platform for sale
-
Material:
-
Aluminum Alloy 6061-T6
-
Color:
-
Silver or other
-
Shape:
-
Square ,Circle, Arch ,Triangle Ladder Truss
-
Size:
-
1.2*1.2m,1.2*2.4m
-
Certification:
-
CE,ISO,TUV
-
Length:
-
available
-
Welding:
-
smooth
-
Connection way:
-
Spigot or Bolt Aluminum stage
-
Warranty:
-
2 Years
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
LIAN SHENG
-
Model Number:
-
LS-S1.2*1.2 stage
-
Product Name:
-
Aluminum adjustable stage /layer stage platform for sale
-
Material:
-
Aluminum Alloy 6061-T6
-
Color:
-
Silver or other
-
Shape:
-
Square ,Circle, Arch ,Triangle Ladder Truss
-
Size:
-
1.2*1.2m,1.2*2.4m
-
Certification:
-
CE,ISO,TUV
-
Length:
-
available
-
Welding:
-
smooth
-
Connection way:
-
Spigot or Bolt Aluminum stage
-
Warranty:
-
2 Years
|
Length
|
2 meters (6.56 ft)
|
|
|
Outer diameter tube
|
2 in (50 mm). Dimensions: 11.42 x 11.42 in (290 x 290 mm)
|
|
|
Diagonal bracing
|
0.75 in (20 mm). Center point load: 4,568 lbs (2,072 kg).
|
|
|
Distributed load
|
6,093 lbs (2,764 kg)
|
|
|
Wall thickness
|
0.08 in (2 mm).Weight: 26.45 lbs (12 kg)
|
|
|
Approvals
|
TUV, CE, SGS
|
|
|
Aluminum Alloy 6061-T6/6082-T6
|
|
|
|
Size
|
Main tube
|
Vice tube
|
Diagonal bracing
|
Maximum span
|
Average load
|
|
200*200mm
|
32*2.0mm
|
25*2.0mm
|
15*1.5mm
|
8m
|
80kg
|
|
250*250mm
|
32.2.0mm
|
25*2.0mm
|
15*1.5mm
|
10m
|
100kg
|
|
300*300mm
|
50*3.0mm
|
32*2.0mm
|
25*2.0mm
|
12m
|
300kg
|
|
350*350mm
|
50*3.0mm
|
32*3.0mm
|
25*2.0mm
|
13m
|
400kg
|
|
400*400mm
|
50*3.0mm
|
32*3.0mm
|
25*2.0mm
|
15m
|
500kg
|
|
450*450mm
|
50*3.0mm
|
40*2.0mm
|
25*3.0mm
|
17m
|
600kg
|
|
400*600mm
|
50*3.0mm
|
40*2.0mm
|
25*2.0mm
|
18m
|
700kg
|
