Quick Details
-
Size:
-
6200*3700*3000mm
-
Material:
-
PP+Aluminium
-
Warranty:
-
1 year
-
Output Power:
-
15KW
-
Design Style:
-
without touching
-
Model:
-
ZG-002
-
Product name:
-
Car Washer Machine
-
Rotating arm:
-
SS304 with rubber encased and foam
-
Plunger pump:
-
PINFL Germany brand
-
Ultrasonic detector:
-
P+F Germany brand
-
Sprinkler head:
-
Sprinkler head
-
Motor:
-
waterproof quality
-
Air dryer:
-
waterproof quality
-
Cable:
-
National standard quality
-
Main frame:
-
100*100*3 galvanized tube
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
ZhiGong
-
Model Number:
-
ZG-9-002
-
Size:
-
6200*3700*3000mm
-
Material:
-
PP+Aluminium
-
Warranty:
-
1 year
-
Output Power:
-
15KW
-
Design Style:
-
without touching
-
Model:
-
ZG-002
-
Product name:
-
Car Washer Machine
-
Rotating arm:
-
SS304 with rubber encased and foam
-
Plunger pump:
-
PINFL Germany brand
-
Ultrasonic detector:
-
P+F Germany brand
-
Sprinkler head:
-
Sprinkler head
-
Motor:
-
waterproof quality
-
Air dryer:
-
waterproof quality
-
Cable:
-
National standard quality
-
Main frame:
-
100*100*3 galvanized tube
Descriptions: Type:ZG-002
l Name: Car washer machine
l Workshop area requirements : 7000*4000*3200mm
l Assembly size:6200*3700*3000mm ,this size can be customized .
l Other accessories assembly size : 2000*1500mm
l (includes water tank, high pressure system box, wash liquid proportioning system box,electricity control box)
l Host size:2807*932*385mm(L*W*H)
l MAX washing height:2000mm
l MAX washing width:2000mm
l MAX washing length:6000mm
l Water consumption for car washing: 120L-160L
l Power supply:380V/16KW
Main accessories list:
² Sprinkler head: SPRAY USA brand
² Plunger pump: PINFL Germany brand
² Ultrasonic detector: P+F Germany brand
² Motor: waterproof quality
² Air dryer: waterproof quality
² Cable: National standard quality
² Water pipe: high pressure water pipe
² Main frame: 100*100*3 galvanized frame
² Rotating arm: SS304 with rubber encased and foam
² Ground nozzle: SS304
² Power distribution cabinet ; Wash system;
|
|
|||
| Parameter comparison | |||
| Serial No. | Type ZG-001 | Type ZG-002 | Type ZG-003 |
| 1 | Cleaning chassis and hub | Cleaning chassis and hub | Cleaning chassis and hub |
| 2 | 360 degree Spraying car Wash ,no need scrubbing | 360 degree Spraying car Wash ,no need scrubbing | 360 degree Spraying car Wash ,no need scrubbing |
| 3 | Spraying high foam wash | Spraying high foam wash | |
| 4 | Spraying was polish | Spraying was polish | |
| 5 | 360degree washing with high pressure water | 360degree washing with high pressure water | 360degree washing with high pressure water |
| 6 | Air dryer with high pressure | Air dryer with high pressure | |
| 7 | LED tip screen with invoice | LED tip screen with invoice | LED tip screen with invoice |
| 8 | Proportioning car wash:1 type | Proportioning car wash:3 types | Proportioning car wash:3 types |
| 9 | Ultrasonic three-dimensional inspection | Ultrasonic three-dimensional inspection | Ultrasonic three-dimensional inspection |
| 10 | Intelligent electronic collision avoidance | Intelligent electronic collision avoidance | Intelligent electronic collision avoidance |
| 11 | rubber surface on arm with collision avoidance | rubber surface on arm with collision avoidance | rubber surface on arm with collision avoidance |
| 12 | Adjust car wash process freely | Adjust car wash process freely | Adjust car wash process freely |
| 13 | Standard cleaning, enhanced clarity, manual assisted cleaning | Standard cleaning, enhanced clarity, manual assisted cleaning | Standard cleaning, enhanced clarity, manual assisted cleaning |
| 14 | Scan code+ intelligent guide | ||
| 15 | Detecting wash quantity | ||
| 16 | Pause or start freely | Pause or start freely | Pause or start freely |
| 17 | Control:remote control or touch screen | Control:remote control or touch screen | Control:remote control or touch screen |
| 18 | leakage protector | leakage protector | leakage protector |
| 19 | Water level detection, automatic water, water shortage protection | Water level detection, automatic water, water shortage protection | Water level detection, automatic water, water shortage protection |
| 20 | Remind to add car wash liquid | ||
| 21 | Breakdown self check | Breakdown self check | Breakdown self check |
| 22 | Failure alarm and recording | Failure alarm and recording | Failure alarm and recording |
| 23 | Water consumption for car washing: 120L-160L | Water consumption for car washing: 120L-270L | Water consumption for car washing: 120L-270L |
| 24 | Cost for washing: USD0.5/Set | Cost for washing: USD0.5-USD0.8/Set | Cost for washing: USD0.5-USD0.8/Set |
| 25 | washing speed: 2mintues | washing speed: 2-7mintues | washing speed: 2-7mintues |
| 26 | Total weight:200kgs | Total weight:400kgs | Total weight:400kgs |
1. who are we?
We are ZhiGong machinery based in Shandong Province, China, started from 2015,sell to Southern Europe(10.00%),Western Europe(10.00%),Southeast Asia(10.00%),Eastern Europe(10.00%),Eastern Asia(10.00%),Mid East(10.00%),Domestic Market(5.00%),South Asia(5.00%),Oceania(5.00%),Northern Europe(5.00%),Central America(5.00%),Africa(5.00%),South America(5.00%),North America(5.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
we produce three types of car washer machines and some conveyors.
4. why should you buy from us not from other suppliers?
we are an enterprise specializing in designing, developing. We can offer OEM service and welcome to visit us,and we supply best service with experience.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,DDP,DDU;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,Credit Card,Western Union,Cash;
6.Language
Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian,you can buy our products by alibaba directly .
