Quick Details
-
Warranty:
-
3months-1year
-
Brand Name:
-
Bluetti
-
Model Number:
-
SP120/SP200
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
411*1708mm/520*2200mm
-
Application:
-
Solar Power System
-
Keyword:
-
Foldable Solar Panel
-
Power:
-
120W/200W
-
Packing:
-
Protable
-
Solar Cell Lamination:
-
Monocrystalline Silicon
-
Weight:
-
4.3KG/6.5KG
-
Folding number:
-
4
-
Operating Temperature:
-
-10℃~+65℃
-
Voltage at max power (Vmp):
-
19.8V
-
Current at max power (Imp):
-
6.06A
-
Certificate:
-
CE
Quick Details
-
Cell size:
-
125mmx125mm
-
Type:
-
BIPV, Flexible, Overlapping
-
Panel Efficiency:
-
Up to 23%
-
Warranty:
-
3months-1year
-
Brand Name:
-
Bluetti
-
Model Number:
-
SP120/SP200
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
411*1708mm/520*2200mm
-
Application:
-
Solar Power System
-
Keyword:
-
Foldable Solar Panel
-
Power:
-
120W/200W
-
Packing:
-
Protable
-
Solar Cell Lamination:
-
Monocrystalline Silicon
-
Weight:
-
4.3KG/6.5KG
-
Folding number:
-
4
-
Operating Temperature:
-
-10℃~+65℃
-
Voltage at max power (Vmp):
-
19.8V
-
Current at max power (Imp):
-
6.06A
-
Certificate:
-
CE
Products Description
|
Model:
|
SP120
|
SP200
|
|
Peak Power(Pm):
|
120W
|
200W
|
|
Solar Cell Lamination:
|
Monocrystalline Silicon
|
Monocrystalline Silicon
|
|
Cell efficiency:
|
Up to 23%
|
≥23.5%
|
|
Voltage at max power (Vmp)
|
19.8V
|
20V
|
|
Current at max power (Imp)
|
6.06A
|
10A
|
|
Open circuit voltage(Voc):
|
23.7V
|
24V
|
|
Short circuit current(Isc):
|
6.66A
|
11A
|
|
Operating Temperature:
|
-10℃～+65℃
|
-10℃～+65℃
|
|
Best working temperature:
|
+25℃
|
+25℃
|
|
Folding number:
|
4
|
4
|
|
Dimension(unfolded):
|
411*1708mm/16*67inch
|
520*2200mm/20.5*86.6 inch
|
|
Dimension(folded):
|
411*427mm/16*16.8inch
|
525*520mm/20.7*20.5 inch
|
|
Weight:
|
4.3kg/9.48lb
|
6.5kg/14.3lb
|
More models are available
