Quick Details
-
Model Number:
-
SW-6310A
-
Product Name:
-
Digital Paint Meter Car Coating Thickness Gauge
-
Measuring Range:
-
0~1700
-
Resolution:
-
0.1 μm / 1μm
-
Application:
-
Thickness Gauge
-
Fuction:
-
car paint coating thickness gauge
-
Certificate:
-
CE FCC
-
Keyword:
-
Paint Thickness Meter
-
Keyword 1:
-
coating thickness gauge
-
Type:
-
Iron and non-ferrous Metals Thickness Measure
Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SNDWAY
-
Model Number:
-
SW-6310A
-
Product Name:
-
Digital Paint Meter Car Coating Thickness Gauge
-
Measuring Range:
-
0~1700
-
Resolution:
-
0.1 μm / 1μm
-
Application:
-
Thickness Gauge
-
Fuction:
-
car paint coating thickness gauge
-
Certificate:
-
CE FCC
-
Keyword:
-
Paint Thickness Meter
-
Keyword 1:
-
coating thickness gauge
-
Type:
-
Iron and non-ferrous Metals Thickness Measure
Iron and non-ferrous Metals Thickness Measure Digital Paint Meter Car Coating Thickness Gauge
Iron (F) and on non-ferrous metals (N) dual usage SW-6310A Features:
1. 2.0 inches large segment screen
2. Rotatable display screen for different views of user during measuring of process.
3. Easy to use , directly attach to the coating and on screen shows the property and thickness.
4. Provide Zero and Multi-spots calibration , calibrating reliably and rapidly.
5. Saving the measured datum up to 30 sets, power-off will not obliterate datum.
6. Warning function of upper/lower limits
7. Press for power-on, and auto power-off with no operation .
8. Indication of low power
Iron and non-ferrous Metals Thickness Measure Digital Paint Meter Car Coating Thickness Gauge
Any question on the thickness meter specs, please contact us.
|
Model NO. |
SW-6310A |
|
Measuring range |
Magnetic and n on magnetic material 0~1700µm |
|
Resolution |
0.1μm @ (0~99.9μm); 1μm @ (100~1700μm) |
|
Indication error |
±(2+2%*H)μm @ (0~500μm) ±(2.5%*H)μm @ (500~1700μm) |
|
Min measuring area |
Magnetic and n on magnetic material 25×25mm |
|
Min curvature |
Convexity 5mm; concave 30mm |
|
Min substrate thickness |
Magnetic material 0.2mm; Non magnetic material 0.05mm |
|
Screen |
2.0 inches large segment screen |
|
Memory |
0 unit s |
|
Units |
mil/µm 1mil=25.4µm;1µm=0.03937mil |
|
Battery |
2×1.5V AAA |
|
Basic measurement |
Single /Continuous measurement |
|
Memory/Delete record |
yes |
|
The screen rotation |
yes |
|
Calibration |
Zero-spot calibration ; Calibration-film calibration |
|
Limiting value measurement |
yes |
|
Dimension |
120x52x26mm |
Package contents:
1
x
Coating Thickness Gauge
1
x
tool box
1
x
sling
1
x Chinese+
English manual
1
x outer
color-box package
1
x
iron substrate
1
x
aluminium substrate
5
x
calibration film
1
x
small PP box(for storing the substrates and the calibration films)
