Quick Details
-
Weight (KG):
-
850 KG
-
Power (kW):
-
5.5
-
Application:
-
Woodworking Process
-
Dimension(L*W*H):
-
3200 x 1100 x 1200 mm
-
Power (KW):
-
5.5+1.1
-
Saw Angle:
-
0-45/90
-
After-sales Service Provided:
-
Video Technical Support
-
After-sales Service:
-
Free Spare Parts
-
Certification:
-
ISO
Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
MKW
-
Core Components:
-
Other
-
Weight (KG):
-
850 KG
-
Power (kW):
-
5.5
-
Application:
-
Woodworking Process
-
Dimension(L*W*H):
-
3200 x 1100 x 1200 mm
-
Power (KW):
-
5.5+1.1
-
Saw Angle:
-
0-45/90
-
After-sales Service Provided:
-
Video Technical Support
-
After-sales Service:
-
Free Spare Parts
-
Certification:
-
ISO
Product Introduction
|
Model
|
2800
|
Max.cutting length
|
2800mm
|
|
Max.cutting Width
|
1250mm
|
Max.cutting thickness
|
80mm
|
|
Main saw diameter
|
300mm(inner30)mm
|
Scoring saw diameter
|
120mm(inner20mm)
|
|
Main saw speed
|
4000-6000R/min
|
Scoring saw speed
|
7000-8000R/min
|
|
Saw Angle
|
90°-45°
|
Main bearing diameter
|
30mm
|
|
Overall size
|
2800 x 1100 x 1200mm
|
Voltage
|
380V/60hz
|
|
Main Motor
|
4kw
|
Push table
|
double-layer
|
|
Motor
|
0.75kw
|
Push table size
|
2800*375mm
|
|
Machine weight
|
About 450KG
|
Dimensions
|
2800*1100*1200mm
|
Introduction:
The double-layer upper and lower double-round rod guide rail precision push table has extremely high straightness stability, high precision and low noise imported bearings from Japan, no error in the flatness of the cast iron surface grinding table, and pull-out push table with ruler processing plane and hollow The baffle has high positioning accuracy, the chrome-plated main shaft does not rust, the double bearing increases the smoothness of the swing arm, and the swing arm is highly smooth to withstand the gravity. Electrical appliances use genuine contactors and air switches to protect motor operation.
|
Model
|
3000
|
Max.cutting length
|
3000mm
|
|
Max.cutting Width
|
1250mm
|
Max.cutting thickness
|
80mm
|
|
Main saw diameter
|
300mm(inner30)mm
|
Scoring saw diameter
|
120mm(inner20mm)
|
|
Main saw speed
|
4000-6000R/min
electric lift |
Scoring saw speed
|
7000-8000R/min
|
|
Saw Angle
|
90°-45°digital display
|
Main bearing diameter
|
30mm
|
|
Overall size
|
3200 x 1100 x 1200mm
|
Sliding table size
|
3000*375mm
|
|
Motor
|
5.5kw+1.1kw
|
Voltage
|
380V/50hz
|
|
Machine weight
|
About 800KG
|
Push table size
|
double-layer push table
|
Introduction:
European seat double layer with supplementary lock, upper and lower double round bar guide rail precision sliding table with high straightness and stability, bearing imported from Japan with high precision and low noise, cast iron surface grinding treatment table flatness without error, 1.75 meters pull-able sliding table The processing plane by the ruler and the hollow baffle have high positioning accuracy, the 1.3m chrome-plated female shaft is not rusty, the double bearings increase the swing arm, the smoothness is high, the gravity is strong, the 5mm cold steel plate square tube structure is thick and stable, and the plastic spraying machine The body does not fade and the paint quality is guaranteed. The electrical appliances use genuine contactors and air switches to protect the operation of the motor. The motor is made of branded pure copper.
|
Model
|
3200
|
Max.cutting length
|
3200mm
|
|
Max.cutting Width
|
1250mm
|
Max.cutting thickness
|
80mm
|
|
Main saw diameter
|
300mm(inner30)mm
|
Scoring saw diameter
|
120mm(inner20mm)
|
|
Main saw speed
|
4000-6000R/min
electric lift |
Scoring saw speed
|
7000-8000R/min
|
|
Saw Angle
|
90°-45°
|
Main bearing diameter
|
30mm
|
|
Overall size
|
3200 x 1100 x 1200mm
|
Sliding table size
|
3200*388mm
|
|
Motor
|
5.5kw+1.1kw
|
Voltage
|
380V/50hz
|
|
Machine weight
|
About 850KG
|
Push table size
|
double-layer push table
|
Introduction:
Double up and down double round rod guide, the straightness stability of precision pushing platform is extremely high, imported SKF bearing, the precision is high, with low noise, cast iron flat with grinding processing, the table is flatness with no error, 1.75 meters can be pulled pushing platform by the ruler processing plane and hollow baffle’s positioning accuracy is high, 1.4 meters chrome plated by the master shaft is not rusty, double bearings increase swing arm high smoothness withstand strong gravity, 6mm cold steel plate + square tube, the main body is thick and stable, the spray of the machine does not fade color, does not drop paint, quality assurance. Electrical equipment adopts authentic contactor and air switch to protect the motor operation, the motor adopts Qingdao brand pure copper national standard.
