Quick Details
-
Internal Dimensions(l x W x H)(mm):
-
5898*2350*2390
-
Place of Origin:
-
Denamrk
Quick Details
-
Type:
-
Dry Container
-
Capacity:
-
20ft 40ft 10ft
-
External Dimensions(l x W x H)(mm):
-
6058*2438*2591
-
Internal Dimensions(l x W x H)(mm):
-
5898*2350*2390
-
Place of Origin:
-
Denamrk
Product Description
Type
|
Dry Container
|
Length (feet)
|
20'
|
40
|
|
12032 x 2345 x 2385
|
|
12032 x 2352 x 2698
|
|
Place of Origin
|
China
|
One Trip Shipping Container 40 ft China
|
|
Product Name
|
20ft 40ft Storage Containers
|
Product Type
|
40' High Cube Used Container
|
Application
|
Storge Cargoes Transport
|
Size
|
20'GP/40'GP/40'HQ/45'
|
Certification
|
ISO 9001
|
Standard
|
ISO9001 Standard
|
Condition
|
Clean Second Hand Container
|
Quality
|
Cargo-worthy Sea Worthy Standard
|
Feature
|
Corrosion Resistant
|
Keyword
|
40ft Dry Containers
|
Packaging & Shipping
Weight | Around 2000kg | |
Roof type | Flat roof, with internal drainage | |
Story | ≤3 story | |
Design parameter | Life time of steel frame | 20 years |
Earth live load | 2.0KN/m2 | |
Roof live load | 0.5KN/m2 | |
Wind load | 0.6KN/m2 | |
Earthquake resistance | grade 8 | |
Steel structure | Corner column | Galvanized cold rolled steel, t=3.0mm, material: Q235B |
Roof beam | Galvanized cold rolled steel, t=3.0mm, material: Q235B | |
Roof secondary beam | C channel steel, t=1.6mm, material: Q235B | |
Earth beam | Galvanized cold rolled steel, t=3.0mm, material: Q235B | |
Earth secondary beam | C channel steel, t=2.0mm, material: Q235B | |
Paint | Graphene powder spraying(static electricity spray process) | |
Roof | Roof panel | 0.5mm thickness galvanized steel sheet, color: white grey |
Insulation |
100mm fiberglass wool insulation with one side aluminum film, density≥14kg/m³, combustion performance: grade A non-combustible |
|
Ceiling | 0.5mm thick steel sheet, color white grey |
Our Services
These containers are also perfect for conversions. You can build attractive shops, exhibition stalls, cafes, bars, operating rooms for boilers and generators, and even portable stages.
However, open-sided containers often cost twice as much as a standard container. They are scarce in the market, and you'll seldom find second-hand side opening shipping containers.
Open-side containers are also ideal for building secure storage and warehouse units. Instead of searching through a dark container and unloading the items inside to make room for access, you can quickly open the side doors and get what you need. The side-door arrangement also gives hassle-free entry to forklifts and works well for palletized storage.
Types of Side-Opening Shipping Containers
Open-sided shipping containers are most commonly available in 20-foot and 40-foot sizes. Depending on the height of your cargo, you can choose the standard height (8'6") or the high cube (9' 6") options in both sizes.
The dimensions of the standard containers with open-sided cargo doors are as follows:
20-Foot Open-Sided Storage Containers
A standard side-opening container has the following dimensions:
* Exterior Dimensions: 20' Length x 8' Width x 8' 6" Height
* Interior Dimensions: 19' Length x 7'8" Width x 7'10" Height
* Door Dimensions: 7'8" Width x 7'5" Height
* Weight: 2,300 kg (5,072 lbs.)
Similarly, a high-cube open-sided storage container comes in the following size:
* Exterior Dimensions: 20' Length x 8' Width x 9' 6" Height
* Interior Dimensions: 19'4" Length x 7'6" Width x 8'6" Height
* Door Dimensions: 8'2" Width x 7'4" Height
* Weight: 3,550 kg (7,385 lbs.)
40-Foot Open-Sided Storage Containers
A standard 40-foot full side-access container has the following dimensions:
* Exterior Dimensions: 40' Length x 8' Width x 8' 6" Height
* Interior Dimensions: 39' 5" Length x 7' 5" Width x 7' 6" Height
* Door Dimensions: 7' 8 " Width x 7' 6 Height
* Weight: 6,100 kg (13,448 lbs.
Similarly, typical 40-foot high-cube side-opening containers have the following size:
* Exterior Dimensions: 40' Length x 8' Width x 9'6" Height
* Interior Dimensions: 39'5" Length x 7'6" Width x 8'1" Height
* Door Dimensions: 7'3" Width x 7'10" Height
* Weight: 6,582 kg (14,510 lbs.)
Custom Made Side-Opening Containers
You can ask your manufacturer to convert the side walls of a used container into standard doors of varying sizes that open at the side of the container. You can also replace the original container doors in open-sided containers with personnel doors if you're building an office unit.
Custom-made containers have the same features as side-opening storage containers. The main difference between the two is that you can select the door size to match your chosen design.
Features of Open-Side Containers
Open-sided containers have the following features, similar to a standard container:
* High-Strength, Corrugated Steel Construction
* Ground-Level Access
* Wind and Weatherproof
* Forklift Pockets for Easy Movement
Additionally, an open-side storage container also offers:
* 180-270 Degree Swing Side Doors
* Full access to the container through the side walls
* Quick sorting without unloading the container
You can also customize an open-side container with:
* Lock Box on door handles
* Interior and Exterior Coloring
* Durable Flooring
* Custom made personnel doors
What are the Alternatives to an Open-Side Shipping Container?
If you're unable to find an open-side container for your project, you can use the following alternatives:
* Factory Built Containers
* Converted Shipping Containers
* Curtain-sided Shipping Containers
Let's take a closer look at these popular alternatives.
Factory Built Containers
Factory-built container units are one of the most abundantly available alternatives since they have a standard size and function.
Typically, these are the types of factory-built container boxes you can use:
Double Door/Tunnel Containers
Just as the name suggests, double-door containers have two doors-one on each end of the container. Although they do not open as much as open-side containers, they make loading and unloading significantly easier. Shipping service providers sell tunnel containers for a fraction of the price of side-opening containers.
End Opening Containers
Most standard containers have doors at one end with the opposite end closed. Most shipping lines use standard end-opening containers, which means it’s relatively easy to find containers with doors on one end.
You can purchase as many as three used 20 ft. containers for the price of a single one-trip, side-opening container.
If you're not planning a significant overhaul or intend to store standard cargo, end-opening containers can be highly
cost-effective.
Converted Shipping Containers
If you have a custom design in mind or plan on building on location, you can look into shipping container conversions. You can contact a container design specialist or DIY the process if you have the will and skill. Here are some ideas for converted shipping container units:
Shipping Container with Additional Side Doors
You can remove one entire side and install multiple additional doors on any of the long sides without affecting the operationality of the end doors. Alternatively, you can weld a single lightweight, prefabricated door on the side that you've cut open.
Storage Containers with Roller Shutters
You can also convert the container's side into a manually or electrically operated roller shutter. The roller door can function as a secondary entry point as well as provide easy access to goods inside the container. Roller shutters are particularly beneficial for quickly accessing hand tools and power equipment at construction sites.
Curtain-Sided Storage Containers
If you've cut open the container and are looking for a quick and cost-effective door, curtains can be a great option. Curtains are
much easier to open and shut than heavy metal doors. You can also latch the curtain fully to close the unit.
Conclusion
Open-sided containers offer several unique benefits that make them an excellent choice for storing, loading, and unloading
oversized equipment. As specially engineered units, they are few in number and much costlier than standard cargo containers that open on one end.
You can select from several alternatives to side-opening containers to cut down your expenses and wait time for the container. Mobile Modular Portable Storage is one of the top suppliers of ISO-grade storage containers and offices. We also offer double doors and high-security units for sale and rent that can function as efficient alternatives to open-side containers. Our fleet of highly-trained drivers and specialised vehicles provide delivery at all the major locations in the United States.
Get in touch with us to learn more about shipping container pricing, offers, and discounts.
