Quick Details
-
Brand Name:
-
kaichuang Flowmeter
-
Model Number:
-
MF
-
Product Name:
-
Ultrasonic digital level electromagnetic water flow meter china
-
Application:
-
Power, chemical, food and other fields
-
Accuracy:
-
±0.3%;±0.5%
-
Power supply:
-
100--240VAC,50/60Hz
-
Color:
-
customer demand
-
Detectable conductivity:
-
than 5μS/cm conductive liquid
-
The lining material:
-
neoprene,polyurethane,PTFE,F46,PFA
-
Protection grade:
-
IP65 / IP 68(optional)
-
Environment temperature:
-
-20℃~+60℃
-
Output:
-
4-20mA/Pulse
Quick Details
-
Type:
-
Variable Area Air & Gas Flowmeters, Variable Area Petrolum Flowmeters, Variable Area Water Flowmeters, Electromagnetic meters
-
Warranty:
-
1 year
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
kaichuang Flowmeter
-
Model Number:
-
MF
-
Product Name:
-
Ultrasonic digital level electromagnetic water flow meter china
-
Application:
-
Power, chemical, food and other fields
-
Accuracy:
-
±0.3%;±0.5%
-
Power supply:
-
100--240VAC,50/60Hz
-
Color:
-
customer demand
-
Detectable conductivity:
-
than 5μS/cm conductive liquid
-
The lining material:
-
neoprene,polyurethane,PTFE,F46,PFA
-
Protection grade:
-
IP65 / IP 68(optional)
-
Environment temperature:
-
-20℃~+60℃
-
Output:
-
4-20mA/Pulse
|
Nominal Diameter(mm)
|
DN3~DN3000
|
|
Structure type
|
Integrated/Separate type
|
|
Flow velocity measurement range
|
0.1m/S~15m/s
|
|
Flow rate resolution
|
0.5mm/S
|
|
Measurement accuracy
|
(±0.2%);±0.3%;±0.5%
|
|
Liquid conductivity
|
≥5μ S/cm
|
|
Nominal pressure (MPa)
|
0.6, 1.0, 1.6, 2.5, 4.0, 6.3, 10.0~42.0
|
|
Lining material
|
Neoprene, polyurethane rubber, polytetrafluoroethylene (PTFE), polyperfluoroethylene (F46), Teflon (PFA)
|
|
Signal electrode and ground electrode materials
|
Molybdenum-containing stainless steel, Hastelloy B, Hastelloy C, Titanium, Tantalum, Platinum-iridium alloy, Stainless steel coated with tungsten carbide
|
|
Flange material
|
Carbon Steel / Stainless Steel
|
|
Ground ring material
|
Stainless steel 1Cr18Ni9.
special materials will be negotiated separately.
|
|
Imported protective flange materials
|
Stainless steel 1Cr18Ni9
|
|
Environmental temperature
|
-20℃~+60℃
|
|
Maximum fluid medium temperature
|
Integral flowmeter: 70 ℃
|
|
|
Separate type flowmeter: Neoprene rubber: 80 ℃. Polyurethane rubber: 70 ℃.
|
|
|
Polytetrafluoroethylene: 120 ℃; Polyperfluoroethylene (F46): 150 ℃; Teflon (PFA): 180 ℃.
|
|
Protection class
|
IP65 Dust Tight, Water Spray Proof, All sensors and transducers.
|
|
|
IP67 Dust Tight, Can be immersed in water for short periods of time, Neoprene and polyurethane lined sensors.
|
|
|
IP68 Dust Tight, Continuously submersible, Separate neoprene and polyurethane lined sensors.
|
|
Explosion-proof symbol
|
ExdmbibⅡCT4Gb, Explosion-proof certificate number: CNEx17.0744.
|
|
Power supply
|
AC: 220VA.C, 50Hz, ≤20VA; DC: 24VD.C, ≤20VA; 3.6V battery power supply;
|
|
Output signals and communication
|
Current output: 4~20mA; pulse/frequency output; RS485, HART, Modbus, profibus-DP/Ap, wireless GPRS;
|
|
Cable length
|
Separate type flowmeter: the length of the signal cable between the sensor and the converter does not exceed 100m.
|
|
China product standard
|
JB/T 9248-2015
|
|
China Certification Standards
|
JJG1033-2007
|
Piping standards may be different in different countries, please provide the pipe diameter, pipe wall thickness and nominal pressure, our company can customize the products according to the demand.
|
Partial Wooden Case Specifications
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Nominal Diameter
(DN)
|
PN16、PN25(mm)
|
|
|
PN40
(mm)
|
|
|
PN63
(mm)
|
|
|
|||||||||
|
|
L
|
W
|
H
|
L
|
W
|
H
|
L
|
W
|
H
|
|||||||||
|
15
|
400
|
300
|
250
|
400
|
300
|
250
|
420
|
300
|
350
|
|||||||||
|
20
|
|
|
|
|
|
|
|
|
|
|||||||||
|
25
|
|
|
|
|
|
|
|
|
|
|||||||||
|
32
|
460
|
300
|
250
|
460
|
300
|
250
|
460
|
300
|
350
|
|||||||||
|
40
|
|
|
|
|
|
|
|
|
|
|||||||||
|
50
|
|
|
|
|
|
|
|
|
|
|||||||||
|
65
|
|
|
|
|
|
|
|
|
|
|||||||||
|
80
|
|
|
|
|
|
|
|
|
|
|||||||||
|
100
|
520
|
300
|
280
|
520
|
300
|
280
|
520
|
300
|
380
|
|||||||||
|
125
|
|
|
|
|
|
|
|
|
|
|||||||||
|
150
|
560
|
360
|
320
|
560
|
360
|
320
|
560
|
380
|
430
|
|||||||||
|
200
|
620
|
390
|
380
|
640
|
420
|
380
|
640
|
450
|
580
|
|||||||||
|
250
|
690
|
450
|
480
|
690
|
500
|
480
|
690
|
520
|
580
|
|||||||||
|
300
|
720
|
500
|
530
|
740
|
560
|
530
|
760
|
580
|
630
|
|||||||||
|
350
|
820
|
560
|
580
|
820
|
610
|
580
|
840
|
650
|
680
|
|||||||||
|
400
|
870
|
650
|
630
|
870
|
720
|
630
|
890
|
720
|
730
|
|||||||||
|
450
|
940
|
700
|
680
|
940
|
750
|
680
|
|
|
|
|||||||||
|
500
|
980
|
800
|
680
|
1020
|
850
|
680
|
|
|
|
|||||||||
|
Export packaging wooden box to meet the provisions of SN/TO273-93 ("Export Commodity Transportation Packaging Wooden Box Inspection Regulations").
1. The above table is the wooden box specification of one-piece pipeline flowmeter, other products wooden box specification please consult customer service.
2. After sealing the box, the height of the box is increased by 120mm (increase the base), the length of the box is increased by 20mm, and the width of the box is increased by 20mm.
3. The steel belt nailless box, enclosure, cover, bottom and base are made of composite board.
4. The composite plate with thickness of 9mm to 15mm is adopted to meet the export requirements of the inspection-free plate. 5. The seams of the box board should be tight, the combination of box board should be flat without misalignment, and the cloth nails should be reasonable.
6.Nomenclature, PN:nominal pressure, PN16: nominal pressure 16MPa, L: Wooden box length, W: Wooden box width, H: Wooden box height.
7. Our company supports the customization of wooden box, please contact customer service staff for special requirements of wooden box
.
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Partial Wooden Crate Weight Chart
|
|
|
|
|
|
|
|
|
|
|||||||||
|
Nominal Diameter
(DN)
|
15
|
20
|
25
|
32
|
40
|
50
|
65
|
80
|
100
|
|||||||||
|
Wooden box weight
（KG）
|
6
|
6
|
6
|
6
|
6
|
6
|
7
|
8
|
8
|
|||||||||
|
Nominal Diameter
(DN)
|
125
|
150
|
200
|
250
|
300
|
350
|
400
|
500
|
600
|
|||||||||
|
Wooden box weight
（KG）
|
8
|
10
|
11
|
12
|
14
|
18
|
22
|
33
|
35
|
|||||||||
|
The weight of this wooden crate is for reference only, the final weight of
the
product, after the completion of the warehouse crating, the actual weighing shall prevail.
|
|
|
|
|
|
|
|
|
|
|||||||||
Founded in 2010,
KAIFENG INITIATIVE MEASUREMENT & CONTROL TECHNOLOGY CO.,LTD.
is a modernized and comprehensive science and technology enterprise focusing on the production, sales, installation, construction and technical services of flow meters, intelligent agriculture, information system integration services, computer network engineering and development of water treatment equipments and high-standard farmland irrigation equipments. Since its inception, the company has actively invested in product research and development and innovation, has made a number of technical achievements, was awarded the national high-tech enterprises, Henan Province, "specializing in new" small and medium-sized enterprise honorary title, and successfully applied for the establishment of Kaifeng City, intelligent agriculture irrigation flow meter engineering technology research center.
The company has been engaged in foreign trade industry since
2017
, and its products are exported to Russia, India, Vietnam, five Central Asian countries, etc. It has rich export experience, complete export qualification and perfect international after-sales service system. The company's products in the comprehensive agricultural development projects, small farmland water conservancy projects, water resources monitoring, food, pharmaceuticals, papermaking, environmental protection and urban heating and water supply, gas supply, water treatment and other fields, a number of core technologies are fully applied to obtain a wide range of domestic and foreign customers praise.
Kaifeng Initiative Measurement & Control Technology Co.,Ltd.
Address：
No.11, South Section of Third Street,Kaifeng Development Zone, Henan Province, China.
Enterprise Email:
kfkc@kfkc.cn
Company Website:
www.kfkc.cn
Open Google Maps, fill in
"china
"
and click search, then fill in
"开封开创计装仪表有限公司"
and click search, then you will know the location of our company.
FAQ
Q1. What is your terms of packing?
A: OEM-branded products come in wooden boxes with tin-covered edges.
Q2. What is your trade terms & payment terms can you accept?
A: Trade terms : EXW, FOB, CFR, CIF for your convenient; Payment terms: 100% T/T or credit card or paypal advance before shipment
Q3. How about your delivery time?
A: Generally, standard type : 6-7 working days after confirm the order.non-standard type: 8-10 working days after confirm the order.
Q4. What's your MOQ?
A: We have no MOQ demand, 1 piece for test purpose at first is acceptable.
Q5. How do you ensure good product quality?
A: We have a complete quality control system; All of our products are fully checked by IQC, OQC departments before ship to our clients.
Q6.How long your quotation valid?
A: Our quotation valid for 12 months.
Q7. Can you accept OEM brand?
A: Yes, we can accept the OEM brand without extra charge.
Q8. How long is your product warranty?
A: 7 days replacement and 12 months repair free of charge for quality problem.
Q9. How delivery the goods?
A: We can send goods by DHL, TNT, UPS, SF, EMS for freight prepaid, also canuse your own courier account to do the freight collect, just for your convenience.
Q10. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings.
