Quick Details
-
Type:
-
Flight Controller
-
Main Processor:
-
STM32H743IIK6
-
Coprocessor:
-
STM32F103
-
Accelerometer / Gyro:
-
BMI088 / ICM20689
-
Electronic Compass:
-
IST8310
-
Barometer:
-
MS5611
-
Compatible Model:
-
PX4 / Ardupilot Firmware
-
External interface:
-
UART/CAN/PWM/SBus/USB/SD
-
Working Temperature:
-
-20 ~ 65 ℃
-
Dimension:
-
47 x 68 x 19 mm
-
Weight:
-
57 g
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
SIYI
-
Model Number:
-
N7
-
Type:
-
Flight Controller
-
Main Processor:
-
STM32H743IIK6
-
Coprocessor:
-
STM32F103
-
Accelerometer / Gyro:
-
BMI088 / ICM20689
-
Electronic Compass:
-
IST8310
-
Barometer:
-
MS5611
-
Compatible Model:
-
PX4 / Ardupilot Firmware
-
External interface:
-
UART/CAN/PWM/SBus/USB/SD
-
Working Temperature:
-
-20 ~ 65 ℃
-
Dimension:
-
47 x 68 x 19 mm
-
Weight:
-
57 g
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
Brand Name
|
SIYI
|
|
Model Number
|
N7
|
|
Private Mold
|
NO
|
|
Type
|
Flight Controller
|
|
Main Processor
|
STM32H743IIK6 (32 Bit Arm® Cortex®-M7, 480 MHz, 2 MB memory, 1 MB RAM)
|
|
Coprocessor
|
STM32F103(32 Bit Arm® Cortex®-M3, 72 MHz, 20 KB SRAM)
|
|
Accelerometer / Gyro
|
BMI088 / ICM20689
|
|
Electronic Compass
|
IST8310
|
|
Barometer
|
MS5611
|
|
|
UART Serial Port: 4
|
|
|
I2C:3
|
|
|
CAN:1
|
|
|
PWM Output:
- 8 x Standard PWM IO - 5 x Programmable IO |
|
|
RC Input (SBus): 1
|
|
|
Power Module Input: 1
|
|
|
GPS & Safety: 1
|
|
|
USB (Type-C): 1
|
|
|
TF Slot: 1
|
|
Compatible Model
|
PX4 / Ardupilot Firmware(Planes / Multirotors / Helicopters / VTOL / UGV / USV)
|
|
Power Module Voltage Input
|
4.5 ~ 5.5 V
|
|
USB Voltage Input
|
5 V ( ± 0.25 V)
|
|
Servo Voltage
|
0 ~ 10 V
|
|
Working Temperature
|
-20 ~ 65 ℃
|
|
Dimension
|
47 x 68 x 19 mm
|
|
Weight
|
57 g
|
