Quick Details
-
Brick size:
-
400*100*200 mm, 400*120*200 mm, 200*100*60 mm, 300*150*100 mm, 400*150*200 mm, 240*115*90 mm, 200*200*60 mm, 150*150*100 mm, 400*200*200 mm, 230*220*115 mm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
KAIDONG
-
Voltage:
-
220/240/380/440V(custormed)
-
Dimension(L*W*H):
-
2060*1730*2580mm
-
Marketing Type:
-
New Product 2022
-
Weight (KG):
-
3000 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product Name:
-
concrete block machine
-
Moulding period:
-
24S
-
The size of the pallet:
-
850*550*25mm
-
Vibration force:
-
35.5KN
-
Mixer model:
-
JQ350
-
NAME:
-
interlocking stabilized soil block machine
-
model:
-
paving block machine
-
Advantage:
-
Low Investment
-
Brick type:
-
Hollow+Interlocking+Paver+Curbstone
Quick Details
-
Type:
-
Hollow Block Making Machine, Paving Block Making Machine, Interlock Block Making Machine, Curbstone Block Machine
-
Brick Raw Material:
-
Cement
-
Production Capacity (Pieces/8 hours):
-
4480 pcs/8hours, 2500 pcs/8hours, 3400 pcs/8hours, 1920 pcs/8hours, 5760 pcs/8hours, 1500 pcs/8hours, 1280 pcs/8hours, 3000 pcs/8hours, 12000 pcs/8hours, 3200 pcs/8hours, 2560 pcs/8hours, 1000 pcs/8hours, 800 pcs/8hours, 2880-3600pcs/day
-
Brick size:
-
400*100*200 mm, 400*120*200 mm, 200*100*60 mm, 300*150*100 mm, 400*150*200 mm, 240*115*90 mm, 200*200*60 mm, 150*150*100 mm, 400*200*200 mm, 230*220*115 mm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
KAIDONG
-
Voltage:
-
220/240/380/440V(custormed)
-
Dimension(L*W*H):
-
2060*1730*2580mm
-
Marketing Type:
-
New Product 2022
-
Weight (KG):
-
3000 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Product Name:
-
concrete block machine
-
Moulding period:
-
24S
-
The size of the pallet:
-
850*550*25mm
-
Vibration force:
-
35.5KN
-
Mixer model:
-
JQ350
-
NAME:
-
interlocking stabilized soil block machine
-
model:
-
paving block machine
-
Advantage:
-
Low Investment
-
Brick type:
-
Hollow+Interlocking+Paver+Curbstone
Products Display
|
QT4-23A SEMI-AUTOMATIC MACHINE TECHNICAL PARAMETERS
|
|
|
|
|
|
|||||
|
1
|
Dimension of host machine
|
2060×1730×2580mm
|
6
|
Host machine power
|
13.45KW
|
|||||
|
2
|
Moulding period
|
25S
|
7
|
Vibration force
|
33KN
|
|||||
|
3
|
The size of the pallet
|
850×550×25mm
|
8
|
Capacity
|
22.05KW
|
|||||
|
4
|
Weight of the machine
|
About 3T
|
9
|
Mixer model
|
JQ350
|
|||||
|
5
|
Voltage
|
220V/240V/380V/415V/440V
|
10
|
Workers
|
3
|
|||||
|
QT4-25 Main technical parameter
|
|
|
|
|
|
|||||
|
1
|
Dimension of host machine
|
3700x2100x2300
|
5
|
total machine power
|
18KW
|
|||||
|
2
|
mould period
|
20-24s
|
6
|
Vibration force
|
35.5KN
|
|||||
|
3
|
Pallet size
|
850x550x25mm
|
7
|
Mixer model
|
JQ500
|
|||||
|
4
|
workshop area
|
160m²
|
8
|
Voltage
|
380V/415V/220V
|
|||||
|
QT4-35B SEMI-AUTOMATIC MACHINE TECHNICAL PARAMETERS
|
|
|
|
|
|
|||||
|
1
|
Dimension of host machine
|
1350X1460X1800mm
|
6
|
Host machine power
|
12KW
|
|||||
|
2
|
Moulding period
|
40S
|
7
|
Vibration force
|
30KN
|
|||||
|
3
|
The size of the pallet
|
850×450×25mm
|
8
|
Capacity
|
2600PCS
|
|||||
|
4
|
Weight of the machine
|
About 1.2T
|
9
|
Mixer model
|
JQ350
|
|||||
|
5
|
Voltage
|
220V/240V/380V/415V/440V
|
10
|
Workers
|
3
|
|||||
|
QT4-40 Main technical parameter
|
|
|
|
|
|
|||||
|
1
|
Dimension of host machine
|
1350x1460x1700mm
|
5
|
total machine power
|
16.3KW
|
|||||
|
2
|
mould period
|
40S
|
6
|
Vibration force
|
30KN
|
|||||
|
3
|
Pallet size
|
850x450x25mm
|
7
|
Mixer model
|
JQ350
|
|||||
|
4
|
workshop area
|
60m²
|
8
|
Voltage
|
220V/380V/415V
|
|||||
