- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Xangshi
-
Model Number:
-
XS97 K2 BT
-
Features:
-
NEW desgn low price
-
GPU:
-
G31 OPenGL3.2
-
RAM:
-
2GB
-
ROM:
-
8GB
-
Support:
-
H.265 Decoder
-
HD:
-
4K2K
-
OEM/ODM:
-
Support
-
Network Function:
-
KO-DI 17.6/18.2
-
Certification:
-
CE ROHS
-
Warranty:
-
1 Year
Quick Details
-
Processor Core:
-
Quad Core
-
Support Resolution:
-
4k
-
WiFi:
-
802.11n 2.4G/5GHz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Xangshi
-
Model Number:
-
XS97 K2 BT
-
Features:
-
NEW desgn low price
-
GPU:
-
G31 OPenGL3.2
-
RAM:
-
2GB
-
ROM:
-
8GB
-
Support:
-
H.265 Decoder
-
HD:
-
4K2K
-
OEM/ODM:
-
Support
-
Network Function:
-
KO-DI 17.6/18.2
-
Certification:
-
CE ROHS
-
Warranty:
-
1 Year
Specification
|
CPU
|
Allwinner H313 Quad Core ARM Cortex A53
|
|
|
|
|
|
|
|
|||||||
|
GPU
|
G31 OPenGL3.2
|
|
|
|
|
|
|
|
|||||||
|
Memory
|
DDR3：2GB
|
|
|
|
|
|
|
|
|||||||
|
Flash
|
eMMC：8GB
|
|
|
|
|
|
|
|
|||||||
|
WiFi&BT
|
2.4G/5G dual wifi with BT
|
|
|
|
|
|
|
|
|||||||
|
Moudle
|
Plastic : Black Color
|
|
|
|
|
|
|
|
|||||||
|
I/O
|
1*HDMI
|
|
4K*2K UHD Output, HDMI 2.0A
|
|
|
|
|
|
|||||||
|
|
1*AV OUT
|
|
480i/576i standard definition output
|
|
|
|
|
|
|||||||
|
|
2*USB
|
|
1* USB Host Port ,1*USB Device
|
|
|
|
|
|
|||||||
|
|
1*IR Reciver
|
|
Remote Reciver Connect
|
|
|
|
|
|
|||||||
|
|
1*RJ45
|
|
Ethernet Interface
|
|
|
|
|
|
|||||||
|
|
1*TF CARD
|
|
Support 4GB/8GB/16GB/32GB/64GB
|
|
|
|
|
|
|||||||
|
Power
|
DC 5V/2A；LED indicator，Working ：Blue; Standby：Red
|
|
|
|
|
|
|
|
|||||||
|
OS
|
Android 10.0
|
|
|
|
|
|
|
|
|||||||
|
Video
|
AllwinnerVideo Engine (AVE) with dedicated hardware decoders and encoders
Support multi-video decoder up to 4K@60fps Supports multiple “secured” video decoding sessions and simultaneous decoding and encoding Video/Picture Decoding - VP9 Profile-2 up to 4K@30fps - H.265 Main10@L5.1 up to 4K@60fps - AVS2 JiZhun 10bit Profile up to 4K@60fps - H.264 BP/MP/HP@L4.2 up to 4K@30fps - H.263 BP up to 1080P@60fps - MPEG-4 SP/ASP@L5 up to 1080P@60fps - MPEG-2 MP/HL up to 1080P@60fps - MPEG-1 MP/HL up to 1080P@60fps - Xvid up to 1080P@60fps - Sorenson Spark up to 1080P@60fps - VP8 up to 1080P@60fps - AVS/AVS+ JiZhun Profile up to 1080P@60fps - WMV9/VC1 SP/MP/AP up to 1080P@60fps - JPEG HFIF file format up to 45M PPS - Multiple language and multiple format sub-title video support - MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918) - Supports JPEG thumbnail, scaling, rotation and transition effects - Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats |
|
|
|
|
|
|
|
|||||||
|
Audio
|
Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing
Built-in serial digital audio SPDIF/IEC958 input/output and PCM input/output • Two DAC channels • Supports 1 audio output interface (differential LINEOUTP/N or single-end LINEOUTL/LINEOUTR) • One Audio HUB, supporting internal mixing function • Embedded 3 I2S/PCM (I2S0 for extended audio codec, I2S2 for BT, I2S3 for digital power amplifier) • Supports Left-justified, Right-justified, Standard I2S mode, PCM mode, and TDM mode • I2S mode supports 8 channels, and 32-bit/192kbit sample rate • I2S and TDM modes support maximum 16 channels, and 32-bit/96kbit sample rate • One OWA OUT interface, supporting 16-/20-/24-bit inputs and outputs • Integrated digital microphone(DMIC), supporting maximum 8 digital PDM microphones |
|
|
|
|
|
|
|
|||||||
|
|
HD JPEG、BMP、GIF、PNG、TIF
|
|
|
|
|
|
|
|
|||||||
|
Language
|
English French German Spanish Italian etc multilateral languages
|
|
|
|
|
|
|
|
|||||||
